- Page 1 UNIVERSAL AUTONOMOUS WIRELESS MEASURING AND SWITCHING DEVICE ROSSMA IIOT-AMS ESD (Equipment Security Device) OPERATON MANUAL www.rossma.ru...
- Page 2 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL DATA ON THE DOCUMENT Heading UNIVERSAL AUTONOMOUS WIRELESS MEASURING AND SWITCHING DEVICE ROSSMA IIOT-AMS ESD Document type Operation manual Document code MAN-RIAESD-04 Last revision number and date №4,16.04.2021 THIS DOCUMENT IS VALID FOR THE FOLLOWING DEVICES...
-
Page 3: Table Of Contents
ROSSMA IIOT-AMS ESD/ OPERATON MANUAL CONTENTS INTRODUCTION ....................ERROR! BOOKMARK NOT DEFINED. DESCRIPTION AND OPERATION PRINCIPLE ..........ERROR! BOOKMARK NOT DEFINED. SWITCHING DEVICE DESCRIPTION ................E RROR OOKMARK NOT DEFINED ENSURING EXPLOSION-PROOF ................... E RROR OOKMARK NOT DEFINED DATA COLLECTION AND TRANSMISSION ALGORITHM ..........E... -
Page 4: Introduction
ROSSMA IIOT-AMS ESD/ OPERATON MANUAL INTRODUCTION This manual applies to ROSSMA IIOT-AMS ESD measuring and switching device (hereinafter switching device) and defines installation and connection procedure, as well as control commands and functional description. To ensure proper functioning, the switching device must be installed and adjusted by qualified personnel. -
Page 5: Switching Device Description
1. DESCRIPTION AND OPERATION PRINCIPLE SWITCHING DEVICE DESCRIPTION The ROSSMA IIOT-AMS ESD measuring and switching device registers the tilt of the device housing by an angle of more than 15 degrees along the horizontal axis and records vibration and impacts on the device housing, transmitting the received data from sensors in a wireless network. -
Page 6: Data Collection And Transmission Algorithm
ROSSMA IIOT-AMS ESD/ OPERATON MANUAL ROSSMA IIOT-AMS ESD device uses the built-in ER34615M battery with a capacity of 13000- 20000 mAh calculated for service life up to 10 years. WARNING: The switching device is equipped with a built-in power cell - a non- rechargeable lithium-thionyl chloride (LiSOCL2) battery. -
Page 7: Functionality
ROSSMA IIOT-AMS ESD/ OPERATON MANUAL FUNCTIONALITY The device is a class A device (according to classification LoRaWAN) and provides the following functionality: • Adaptive Data Rate (ADR) support • Wireless configurable LoRaWAN type of activation in LoRaWAN network - OTAA, ATS. Default: •... -
Page 8: Data On Certification
X1-single channel, X4-four inputs, etc. Switching device version: specifies the hardware platform and firmware version. Manufacturer OUI: Unique identifier of ROSSMA in IEEE. Region of delivery: RU-Russian Federation, EU-European Union. DATA ON CERTIFICATION Manufactured according to УАБИ.001.83301259.2017 ТУ specification. Certificate of compliance No. РОСС RU.HB32.Н04125/20 MAN-RIAESD-04 Revision No. - Page 9 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL Declaration ЕАЭС N RU Д-RU.АБ93.B.08697 on Compliance with the Technical Regulation Requirements of the Customs Union ТР ТС 020/2011 "Electromagnetic Compatibility of Technical Means" meets industrial safety requirements. Certificate of conformity No С-RU.МТЭ.OC.001.Н.0003 The design of explosion-proof switching device complies with the requirements of the Technical Regulation of Customs Union TR TS 012/2011 "On equipment safety for operation in explosive...
- Page 10 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL 2. TECHNICAL SPECIFICATIONS THE MAIN Number of sensitive sensors up to 6 - request (default 3) Operation temperature range -55…+85°С Built-in temperature sensor Yes (sends data every time you connect) Built-in power supply charge measuring...
-
Page 11: Contacts Description
Data is being exchanged No data exchange Data communication indicator in LoRaWAN network(green) Data is being exchanged No data exchange Connector "On" Impact sensor Tilt sensor Vibration sensor Fig.1 Description of ROSSMA IIOT-AMS ESD device MAN-RIAESD-04 Revision No. 4 of 04.16.2021... -
Page 12: Structure Description
ROSSMA IIOT-AMS ESD/ OPERATON MANUAL STRUCTURE DESCRIPTION The device consists of a plastic housing in which a printed circuit board with a lithium 3,6V power element is installed. The PCB is attached using stainless steel screws. Silicone seal is installed between body base and cover. -
Page 13: Initial Start-Up
1 mm) to the end device via terminals (Fig. 1, Fig. 2, Fig. 3) • Install the jumper on the activating pins (Fig.2, Fig. 3). The switching device ROSSMA IIOT-AMS ANAlOG X4 PWR is connected to the power supply 220V (Fig.1) • Check LED indication •... -
Page 14: Replacement Of Power Supply
ROSSMA IIOT-AMS ESD/ OPERATON MANUAL REPLACEMENT OF POWER SUPPLY To replace the power supply, perform the following steps: • Turn off the device (disconnect the connector of the power element from the connector on the board). • Unscrew the screw fixing the bracket inside the housing. - Page 15 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL • Install a new power element into the housing. Install the bracket on the power element and fix it with a screw. • Connect the power element to the power connector on the board. Check indication of LEDs.
-
Page 16: Data Package Format
The switching device is configured using special control commands that are sent to the switching device in wireless network. DATA PACKAGE FORMAT Data package format for ROSSMA IIOT-AMS ESD switching device: Decoding: dd0e00000015001000140000000000000000000000000000000000000000000000000ccc14 dd - package type (dd - data, aa - alert, 21 - response) 0e - presence of security inputs actuation (reset when sending of two alerts). - Page 17 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL CONTROLING THE SWITCHING DEVICE Port 1 (Device Management): 0x02 - Confirmed Message Mode (LoraWAN Confirmed messages on/off) 0x03 - Full frequency range for ABP (device restart required) 0xBB - version request Response: bb040400010001 Where: bb - package type 0104 - device type 0200 - Software Version (v2.0)
- Page 18 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL 01 - command 003C - time in seconds (60 seconds) Request, option 2: 010000003C 01 - command 0000003C - time in seconds (60 seconds) Response: 21030300 Where: 21 - package type (0x21 - response) 03 - Request Port...
- Page 19 " ROSSMA IIOT-AMS switching device should be stored in the factory package in heated rooms at temperature from + 5 ° С to + 40 ° С and relative humidity not more than 85%.
- Page 20 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL 6. DISPOSAL A failed switching device does not pose a danger to human health and the environment. Disposed according to the procedure established by Federal Law No. 89 "On Waste of Production and Consumption." MAN-RIAESD-04...
- Page 21 ROSSMA IIOT-AMS ESD/ OPERATON MANUAL 7. КОМПЛЕКТ ПОСТАВКИ The standard delivery set of ROSSMA IIOT-AMS ESD switching device includes: • Switching device ROSSMA IIOT-AMS ESD – 1 шт. • Certificate – 1 шт. • Operation manual – 1 шт. • Packing – 1 шт.
- Page 22 • Switching devices with traces of oxidation or other signs of liquids ingress into the device housing. If a warranty case occurs, contact the service center of the ROSSMA manufacturer at: 614064, Perm, Chkalova Str., 9 Lit. "И". Phone: 7 (342) 233-93-99.
- Page 23 Operation manual www.rossma.ru...
