NEASURING AND SWITCHING DEVICE
ROSSMA IIOT-AMS PULSE
OPERATION MANUAL
The ROSSMA IIOT-AMS PULSE switching device is designed to count pulses coming from control
and measuring devices (liquid, gas, pulse meters, industrial flow meters), to measure the
output frequency of industrial mass meters, as well as to monitor the condition of equipment
connected to one or more discrete inputs of the ROSSMA IIOT-AMS switching device. Provides
offline operation and wireless data transfer in LoRaWAN or NBiOT network.
www.rossma.ru
Advertisement
Table of Contents
Related Manuals for ROSSMA IIOT-AMS Pulse
Summary of Contents for ROSSMA IIOT-AMS Pulse
- Page 1 ROSSMA IIOT-AMS PULSE OPERATION MANUAL The ROSSMA IIOT-AMS PULSE switching device is designed to count pulses coming from control and measuring devices (liquid, gas, pulse meters, industrial flow meters), to measure the output frequency of industrial mass meters, as well as to monitor the condition of equipment connected to one or more discrete inputs of the ROSSMA IIOT-AMS switching device.
- Page 2 ROSSMA IIOT-AMS PULSE/ OPERATION MANUAL DATA ON THE DOCUMENT Title Measuring and switching device ROSSMA IIOT-AMS Pulse Document type Operation manual Document code MAN-RIAP-01 Last revision number and date 04.09.2019 THIS DOCUMENT IS VALID FOR THE FOLLOWING DEVICES LINE NAME...
-
Page 3: Table Of Contents
ROSSMA IIOT-AMS PULSE/ OPERATION MANUAL CONTENTS INTRODUCTION ..............................3 1. DESCRIPTION AND OPERATION PRINCIPLE ....................4 SWITCHING DEVICE DESCRIPTION ..........................4 DATA COLLECTION AND TRANSMISSION ALGORITHM ..................... 4 FUNCTIONALITY ................................ 5 MARKING .................................. 5 DATA ON CERTIFICATION ............................6 2. TECHNICAL CHARACTERISTICS ......................... 7 WORKING WITH THE SWITCHING DEVICE .................... -
Page 4: Introduction
ROSSMA IIOT-AMS PULSE/ OPERATION MANUAL INTRODUCTION This manual applies to ROSSMA IIOT-AMS PULSE measuring and switching device (hereinafter switching device) and defines installation and connection procedure, as well as control commands and functional description. The manual is intended for specialists familiar with the installation rules in the field of various electronic and electrical equipment. -
Page 5: Description And Operation Principle
The switching device is manufactured with a 3.6 V power supply. The power cell of the ROSSMA IIOT-AMS PULSE... -
Page 6: Functionality
1 time/min. 1 time/2 min. 1time/10 min. 1time/hour When connecting active CMD Autonomous operation time of ROSSMA IIOT-AMS Pulse 55 days 110 days 1,5 days 9 days If the Request Confirmation parameter is disabled, the switching device sends the current data to the network with the specified frequency. -
Page 7: Data On Certification
Number of inputs: X1-single channel, X4-four inputs, etc. Switching device version: specifies the hardware platform and firmware version. Manufacturer OUI: Unique identifier of ROSSMA in IEEE. Region of delivery: RU-Russian Federation, EU-European Union. DATA ON CERTIFICATION Manufactured according to УАБИ.001.83301259.2017 ТУ specification. -
Page 8: Technical Characteristics
ROSSMA IIOT-AMS PULSE/ OPERATION MANUAL 2. 2. TECHNICAL CHARACTERISTICS THE MAIN Multichannel Up to 8 – upon request (by default 1) connection interface Pulse (frequency) input Operation temperature range -55…+85°С Built-in temperature sensor Yes (sends data every time you connect) -
Page 9: Contacts Description
Indicator Lora Reset button Socket of battery power supply Fig.1 ROSSMA IIOT-AMS PULSE АСТ indicator– data reading Lora indicator – data transfer INITIAL START-UP Before using the switching device, you must connect the battery plug to the terminal on the board. -
Page 10: Communications Protocol
LoRaWAN network. 5. 5. STORAGE AND TRANSPORTATION RULES ROSSMA IIOT-AMS switching devices shall be stored in the factory package in heated rooms at temperature from 5 ° С to 40 ° С and with relative humidity not more than 85%. -
Page 11: Delivery Set
- Switching devices with traces of oxidation or other signs of liquids ingress into the device housing. If a warranty case occurs, contact the service center of the ROSSMA manufacturer at: 614064, Perm, Chkalova Str., 9 Lit. "И". Phone: 7 (342) 233-93-99. - Page 12 Operation manual LLC ROSSMA , 2019. www.rossma.ru...
