Thank you for choosing the Light-On CLR® 3 Tripod Tab-Tension model. This product is a portable tripod projection
screen with ceiling ambient light rejecting technology for portable projector presentations on the go.
The screen material included is our CLR® 3, which is an optical lens front projection material precisely formulated for
environments with minimal control over room lighting. It was designed to filter and absorb overhead light while
directing tabletop mounted projectors. It best for family rooms, educational facilities, conference rooms or any
applications in which incident light is a factor.
THE PROJECTION FABRIC IS A DELICATE OPTICAL/LENTICULAR SCREEN MATERIAL AND SHOULD NOT BE
FOLDED, BENT, OR CREASED. ALWAYS MAINTAIN SCREEN MATERIAL FLAT AND TAUT DURING SETUP AND
DISASSEMBLY. IT IS VERY IMPORTANT ALL INSTRUCTIONS ARE FOLLOWED TO AVOID DAMAGING THE
MATERIAL. ANY DAMAGES RESULTING FROM NEGLIGANCE OR MISHANDLING WILL VOID YOUR WARRANTY.
Screen maintenance
Dust, dirt, and scratches on the projection screen surface will affect the quality and performance of the projection
image. Follow the instructions below to properly maintain the screen.
1) The screen surface has a horizontal linear structure. DO NOT wipe the screen up and down or in a circular
motion. Wipe gently from left to right only.
2) Clean the dust on the screen surface with a soft brush or microfiber cloth. A rough/coarse towel or cloth may
damage the screen's surface.
3) Gently wipe the screen with a lightly moistened white lint free cloth with water or with a neutral detergent
(1mL/0.33 oz) mixed with water (1000 mL/33.8 oz).
4) Avoid putting pressure on the screen material when wiping the screen. If dust or other debris is on the surface,
we recommend using an air sprayer to blow them away.
Notes: The following precautions should always be followed to avoid damaging the material, which is not covered
under warranty.
• Don't touch the screen material to avoid leaving fingerprints.
• Use gloves when handling the material.
• Don't scratch the material, as it will leave permanent markings on the screen's surface.
• Don't point to the screen material with a fingertip or other sharp objects to prevent damage to the material.
• Don't use acetone, benzene, alcohol and any other organic solvents to clean the screen material. Using such
chemicals will permanently damage the screen.
Rev.09072021-JA
Tripod Tab-Tension model # TT55V-CLR3
Indoor Ceiling Ambient Light Rejecting Portable Screen
For tabletop mounted ultra/short-throw projectors
CAUTION!
www.elitescreens.com
Light-On CLR® 3 Series
User's Guide – Z Type
1
Advertisement
Table of Contents
Related Manuals for Elite Screens Light-On CLR 3 Series
Summary of Contents for Elite Screens Light-On CLR 3 Series
- Page 1 Light-On CLR® 3 Series Tripod Tab-Tension model # TT55V-CLR3 Indoor Ceiling Ambient Light Rejecting Portable Screen For tabletop mounted ultra/short-throw projectors User’s Guide – Z Type _____________________________________________________________________________________________ Thank you for choosing the Light-On CLR® 3 Tripod Tab-Tension model. This product is a portable tripod projection screen with ceiling ambient light rejecting technology for portable projector presentations on the go.
- Page 2 Tripod Screen Parts Identification Tripod drape skirt A. Tripod Screen Setup Follow the steps below and Fig. 1 & 2. 1. Place the screen in an upright position (Fig.1) with the legs toward the ground. 2. Deploy the Tripod Support legs by pushing down on the Tripod Junction. 3.
- Page 3 B. Preparing the tripod screen for projection: Follow the steps below and Fig. 3. 1. Pull the screen handle up vertically and hook the screen handle on the Top Hook. NEVER PULL THE SCREEN MATERIAL TO RAISE IT. Note: Use the Keystone Eliminator to prevent “Keystone Effect” from occurring.
- Page 4 Notice to Installer: PROPER PROJECTOR PLACEMENT ® The CLR 3 is exclusively for tabletop mounted ultra-short throw projectors. See illustrations for limits and criteria. 1) Tabletop mounted Ultra-short throw projection illustration IMPROPER PROJECTOR PLACEMENT Overhead placement or a standard projector will make the image very dark, on account of the screen’s absorbent layer deflecting light that is not aligned with its reflective angle...
- Page 5 Do not fold the screen or allow any sharp objects to touch the screen’s surface. • Clean the screen surface often when needed. • Careful use will extend the lifetime of this product For more information, technical support or your local Elite Screens contact, www.elitescreens.com please visit Rev.09072021-JA www.elitescreens.com...
