LOCATION
VALUE
R1
1M
R2
1M
R3
560R
R4
1K
R5
47R
R6
1K
R7
1K5
R8
1M
R9
10K
R100
10K
R101
10K
R102
4K7
C1
22n
C2
4u7
C3
2u2
C4
1n
C5
100p
C6
30p
C7
4u7
C8
3n3
C9
22n
C10
1u
C100
100u
C101
100n
C102
100u
D1
1N4148
D2
1N4148
D3
Red
D4
Red
D100
1N5817
Q1
J202
IC1
OP07
VOLUME
A100K
FILTER
C100K
DIST
A100K
GAIN
SPDT
Triad Distortion
Triad Distortion
Parts List (Page 1 of 1)
TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Ceramic capacitor
Ceramic capacitor
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Signal diode, DO-35
Signal diode, DO-35
3mm Red LED, Diffused
3mm Red LED, Diffused
Schottky diode, DO-41
JFET transistor, N-channel
Single op-amp, DIP8
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Toggle switch, SPDT
Copyright © 2020 - PedalPCB.com
NOTES
Alternate: MMBFJ202 (SMD)
2-position (ON/ON)
Page 2 of 5
