Parts List (Page 2 Of 2) - PedalPCB Resinite Overdrive Wiring Diagram

LOCATION VALUE
Q1 BC550C
Q2 BC550C
Q3 2N3819
Q4 2N3819
Q5 BC550C
Q6 2N5485
VOLUME B100K
TONE B100K
DRIVE A100K
Resinite Overdrive
Resinite Overdrive

Parts List (Page 2 of 2)

TYPE
BJT transistor, NPN TO-92
BJT transistor, NPN TO-92
JFET transistor, N-channel
JFET transistor, N-channel
BJT transistor, NPN TO-92
JFET transistor, N-channel
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Copyright © 2021 - PedalPCB.com
NOTES
Page 3 of 6
