Parts List (Page 1 Of 2) - PedalPCB Resinite Overdrive Wiring Diagram

LOCATION VALUE
R1 1M
R2 47K
R3 100K
R4 470K
R5 100R
R6 15K
R7 470R
R8 8K2
R9 100K
R10 470K
R11 100R
R12 12K
R13 8K2
R14 100K
R15 470K
R16 150R
R17 15K
R18 22K
R19 1M
R20 68K
R21 6K8
R22 2K
R23 14K7
R100 4K7
R101 100R
C1 15n
C2 1u
C3 47n
C4 470p
C5 100n
C6 100n
C7 330p
C8 1u
C9 100n
C10 10n
C11 220n
C12 10u
C13 1u
C100 100u
D1 1N4007
D2 1N4007
D100 1N5817
Resinite Overdrive
Resinite Overdrive

Parts List (Page 1 of 2)

TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Ceramic capacitor
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Ceramic capacitor
Electrolytic capacitor, 5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 5.0mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Electrolytic capacitor, 5mm
Signal diode, DO-35
Signal diode, DO-35
Schottky diode, DO-41
Continued on next page...
