PedalPCB Terrarium Platform Wiring Diagram page 2

LOCATION VALUE
R1 1M
R2 1M
R3 1M
R4 100R
R5 1K
R6 100K
R7 1K
R8 1K
R9 1M
C1 100p
C2 1u
C3 1u
C4 100n
C5 100n
C6 1u
C7 1n
C8 100n
C9 100n
C100 100u
D100 1N5817
IC1 TL072
IC2 L78L05
SEED1
POT1 B10K
POT2 B10K
POT3 B10K
POT4 B10K
POT5 B10K
POT6 B10K
SW1
SW2
SW3
SW4
FS1
FS2
PINHEADER
Terrarium Platform
Terrarium Platform
Parts List (Page 1 of 1)
TYPE
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Resistor, 1/4W
Ceramic capacitor
MLCC capacitor, 7.2 x 2.5mm
MLCC capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
MLCC capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Film capacitor, 7.2 x 2.5mm
Electrolytic capacitor, 5mm
Schottky diode, DO-41
Dual op-amp, DIP8
Linear voltage regulator, 5V
Electro-Smith Daisy Seed Module
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
16mm right-angle PCB mount pot
Toggle switch, SPDT
Toggle switch, SPDT
Toggle switch, SPDT
Toggle switch, SPDT
Foot switch, SPST
Foot switch, SPST
20-pin Female 2.54mm Pinheader Quantity: 2
Copyright © 2022 - PedalPCB.com
NOTES
2-position (ON/ON)
2-position (ON/ON)
2-position (ON/ON)
2-position (ON/ON)
Momentary SPST
Momentary SPST
Page 2 of 5
