• Công suất ngõ ra: 1 kênh/5A – I Max = 10A. • Công suất không tải: 0.1W. • Số nút điều khiển: 6 Nút điều khiển. • LED báo trạng thái: Có. • LED nền hỗ trợ ban đêm: Có. www.acis.com.vn...
Page 3
*Khuyến cáo: ngắt nguồn điên khi lắp đặt để tránh nguy hiểm do thao tác khi lắp đặt. *Phải chắc chắn dây lửa (L) và nguội (N) đúng thứ tự, việc lắp ngược có thể dẫn đến lỗi không sáng đèn hoặc gây hư hỏng thiết bị. www.acis.com.vn...
Page 4
THIẾT LẬP ĐỊA CHỈ ID THIẾT BỊ Chắc chắn đã vào chế độ “học thiết bị”, nếu thành công thiết bị tự thoát ra. Nếu thiết “1” lập không thành công, đèn sẽ chớp liên “1” tục, nhấn lại nút để thiết lập lại. www.acis.com.vn...
Page 5
Mỗi khi chọn lại loại thiết bị thì cũng giống như thiết bị đã được khôi phục về lại cài đặt gốc. Phải tiến hành thiết lập lại cho thiết bị vào hệ thống đồng thời thiết lập lại các kịch bản và liên kết với remote. www.acis.com.vn...
Page 6
Để hệ thống hoạt động ổn định nên bật chỉ 1 repeater ở một cụm nhiều công tắc gần nhau. [5] - ĐỔI TRẠNG THÁI LED Đèn “1” nếu sáng thì là đảo trạng thái Led, mặc định đèn “1” tắt. www.acis.com.vn...
Page 7
(6 đèn trên công tắc nhấp nháy) Chạm [4] REBOOT THIẾT BỊ Chạm và giử [5] LƯU VÀ THOÁT Chạm [6] LIÊN THÔNG THIẾT BỊ Chọn phím “1,2,3,4” để liên thông. Muốn xóa liên thông thì chạm nhanh phím muốn xóa 3 lần www.acis.com.vn...
• Suppling power to run. *Recommendation: remembering turn off electric power to make sure the safety . **Make sure live wire (L) and neutral wire are in the correct position. Setting up in the wrong direction lead to damage devices. www.acis.com.vn...
Page 11
SETTING THE ID ADDRESS Make sure MCE in status scan device. If it is completed successfully, the device will back to home screen status. If it not completed successfully, light "1" will blink continuously. Press "1" again to setting. www.acis.com.vn...
Page 12
[4] RE4: include channels 1,2,3,4. The scenario is 5,6. When you select the device type again, the same as the device has been restored back to factory settings. Must make the device reset to the system simultaneously reset the scripts and associated with the remote. www.acis.com.vn...
Page 13
For stable operation system should turn on only one repeater in a cluster multiple switches together. [5] - CHANGE LED STATUS Lamp “1” if light is reversed Led state, default lamp "1" off. www.acis.com.vn...
Touch REBOOT DEVICE Touch & Hold [5] SAVE AND EXIT Touch COMMUNICATION DEVICE Select Key "1, 2, 3, 4" to connect. If you want to delete a link, quickly tap the DELETE key 3 times www.acis.com.vn...
