Extractor hood LI97SA561S,LI97SA561B,LI67SA561S,LI97RA561,LI67RA561 User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
en Safety provided that they are supervised or have Table of contents been instructed on how to use the appliance safely and have understood the resulting dangers. USER MANUAL Children must not play with the appliance. Children must not perform cleaning or user Safety ..............
Safety en ▶ It is only possible to safely operate the ap- ▶ Select the highest fan setting. pliance if the pressure in the room in which ▶ Never operate two gas hobs simultan- the heating appliance is installed does not eously on the highest flame for longer than drop more than 4 Pa (0.04 mbar) below at- 15 minutes.
en Avoiding material damage in the interior of the appliance may cause ex- An ingress of moisture can cause an electric plosions. shock. ▶ Never use highly caustic alkaline or highly ▶ Before cleaning, pull out the mains plug or acidic cleaning agents. In particular, do not switch off the fuse in the fuse box.
Operating modes en 4 Operating modes 4.1 Air extraction mode The air which is drawn in is cleaned by the grease fil- ters and conveyed to the exterior by a pipe system. The air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the...
en Familiarising yourself with your appliance 5 Familiarising yourself with your appliance 5.1 Controls The controls are used to configure all functions of your appliance and to obtain information about the operat- ing status. Switching the appliance on or off Increasing the fan setting/ Intensive mode 1, 2 Switching the lighting on or off/ Switching on the boost function...
Cleaning and servicing en 6.12 Resetting the saturation indicator 6.13 Setting the saturation indicator After cleaning the grease filter or after changing the The saturation indicator must be adjusted depending odour filter, the saturation indicator can be reset. on the filter used. Requirement: The appliance is switched off. Requirements ¡...
en Troubleshooting Observe the information regarding the cleaning ATTENTION! Falling grease filters may damage the hob below. agents. Grip below the grease filter with one hand. → "Cleaning products", Page 7 ▶ Place the grease filters loosely into the dishwasher. Note: Remove the grease filter in the filter pull-out Do not clean heavily soiled grease filters with first, then remove the grease filters in the appliance.
Customer Service en 8.1 Malfunctions Fault Cause and troubleshooting The appliance is not The mains plug of the power cord is not plugged in. working. Connect the appliance to the power supply. ▶ The circuit breaker is faulty. Check the circuit breaker in the fuse box. ▶...
You will find a comprehensive range of products for your appliance in our online shop or from our after- your appliance in our brochures and online: sales service. www.siemens-home.bsh-group.com 11 Disposal Find out here how to dispose of old appliances cor- This appliance is labelled in accord- rectly.
Page 11
Installation instructions en shaft are sucked back into the living space. ing operated together, the largest specified clearance applies. ▶ The appliance must be installed with no more than one side directly next to a high- sided unit or a wall. The distance between the appliance and wall or high-sided unit must be at least 50 mm.
Page 12
en Installation instructions ▶ Only use genuine spare parts when repair- ¡ Diameter of 120 mm corresponds to ap- prox. 113 cm². ing the appliance. ¡ Use sealing strips for different pipe diameters. ▶ If the power cord of this appliance is dam- ¡ Do not use any flat ducts with sharp bends. aged, it must be replaced by the manufac- turer, the manufacturer's Customer Service 12.6 Instructions for the electrical...
Page 13
Installation instructions en Use the enclosed mounting part to mark the fasten- 12.8 Installation ing points on the inside of the cabinet and use a Checking the unit bradawl to make indentations where the holes are Check whether the fitted unit is level and has suffi- to be.
Page 14
en Installation instructions Preparing the appliance Appliance width 90 cm: Pull the filter pull-out out completely towards the front. Also use two screws Insert the holders for the wall edging strip on the each on the left and right to screw the appliance to outside rear of the appliance into the cut-outs and the side upper cabinets from below.
Page 15
Installation instructions en Shorten the spacers to the required dimension and Push in the fastening bolts using a flat-blade screw- insert them into the slot specified. driver and rotate by 90° until the fastening bolts un- clip. Removing the appliance Push in and turn the fastening bolts gently with your Cover the hob to prevent damage.
Page 16
Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001527798* 9001527798 (010715)
