ETC System Maintenance CUE 2017
System Inspection and Maintenance Checklist
Power Controls- Cleaning and Inspection-Energized
Note:
2" Paintbrush dry, clean, never used with paint.
Oil and moisture-free, low pressure compressed air.
Any site specific required safety gear (Eye and hearing protection, NFPA-70E clothing, etc).
Rack Exterior
Step 1:
Confirm there are no obstructions affecting airflow.
Step 2:
Confirm door closes properly.
Step 3:
Turn on a dimmer so the fan activates and listen to the fan or hold hand over vent to confirm
airflow.
Step 4:
Confirm the beacon or error indicators are working properly.
Rack Interior
Step 1:
Run a dimmer check and confirm signal lights turn on for each power control module.
Step 2:
Confirm rack labels are legible and affixed properly.
Step 3:
Inspect door foam and replace as needed.
Rack Filter
Step 1:
Remove filter from rack and move to another location.
Step 2:
Using a clean, dry, low pressure air source, blow dirt from both sides of filter.
Step 3:
Vacuum debris between filter and door.
Step 4:
Replace filter.
WARNING:
Control Electronics
Step 1:
Confirm exterior is dust free.
Step 2:
Make sure screen is readable.
Step 3:
Confirm there are no errors indicated.
Step 4:
If possible, save configuration.
Power Control Modules
Step 1:
With fan off, dust fronts.
Step 2:
Make sure breakers are on.
Step 3:
Check for lockout/tagout as site safety documents indicate.
Step 4:
No error or fault lights.
These steps are safe to perform while power is on.
a: Front
b: Top
c: Bottom
a: If filter is extremely dirty, it can be washed with tap water.Clean rack door
Make sure filter is dry before installing into racks.
Tools needed

Advertisement

Table of Contents
loading

Summary of Contents for ETC CUE 2017

  • Page 1 Tools needed 2" Paintbrush dry, clean, never used with paint. Oil and moisture-free, low pressure compressed air. Any site specific required safety gear (Eye and hearing protection, NFPA-70E clothing, etc). Rack Exterior Step 1: Confirm there are no obstructions affecting airflow.

  • Page 2: Control Electronics

    ETC System Maintenance CUE 2017 Power Controls Cleaning and Inspection- De-Energized WARNING: RISK OF DEATH BY ELECTRIC SHOCK! Failure to disconnect all power to the panel before working inside the panel could result in serious injury or death. De-energize main feed to the breaker panel and follow appropriate Lockout/Tagout procedures as described in NFPA Standard 70E.

  • Page 3: Cleaning The Outside

    ETC System Maintenance CUE 2017 System Inspection and Maintenance Checklist Fixture Cleaning Checklist- All Fixture Types Note: This is best done with the fixture mounted to a pipe and base at a good working height. Tools needed Optional tools: 2" Paintbrush dry, clean, never used with paint.
  • Page 4 ETC System Maintenance CUE 2017 Fixture Cleaning Checklist- Incandescent Fixtures Note: This is best done with the fixture mounted to a pipe and base at a good working height. Follow both lamp and reflector instructions below before replacing lamp housing on fixture.

  • Page 5: Clean The Exterior

    Apply a few drops of isopropyl alcohol into faders and run fader up and down several times. Step 6: Inspect console ports (USB, DMX, video, etc…) for damage. Step 7: Using glass cleaner and lint free cloth, clean displays and touchscreens.
  • Page 6 Step 5: Apply a short burst of DeOxit into faders and run fader up and down several times. Step 6: Inspect console ports (DMX, video, etc…) for damage. Step 7: Using glass cleaner and lint free cloth, clean displays. Clean the Interior...
  • Page 7 ETC System Maintenance CUE 2017 System Inspection and Maintenance Checklist Equipment Rack Cleaning and Inspection As equipment racks contain gear that is custom so it is difficult to detail everything you should to. Follow the recommended maintenance for each item in the rack based on its user...

  • Page 8: General System Inspection

    ETC System Maintenance CUE 2017 General System Inspection Lighting systems contain a wide variety of auxiliary and peripheral items, testing and inspecting them should be part of your annual maintenance DMX Nodes and Gateways • Connect all portable nodes and verify their ports work.

  • Page 9: Control Enclosures

    ETC System Maintenance CUE 2017 System Inspection and Maintenance Checklist Architectural Control Systems Tools needed 2" Paintbrush dry, clean, never used with paint. Oil and moisture free source of low pressure compressed air Lint Free Cloth Distilled Water Any site specific required safety gear Isopropyl alcohol (80% or better) or goo gone Alcohol based ammonia free glass cleaner.
