Casio CTK-573 Service Manual page 23

PARTS PRICE LIST
CTK-573
N ITEM
MAIN PCB
1
LSI1
LSI2
LSI3
LSI4
IC1
IC2
IC3
IC4
IC5
IC6
Q1
X1
SUB PCB ASSY
2
IC101
IC102
Q102,Q104-Q108
Q101,Q103
D101
D105
D103,D106-D108
D104
J101
J102
J103
J104
DISPLAY PCB
3
LSI401
TH401
VR401
CONSOLE PCB
4
5
D301-D344
LED301
VR301
KEYBOARD PCB
6
7
D501~D564
D565~D622
KEYBOARD UNIT
8
9
10
11
12
CODE NO. PART NAME
1005 3885 PCB ASSY(MA1M)
2012 5572 LSI
1004 5604 LSI
1004 5603 LSI
2012 4998 LSI
2105 4746 LSI
1002 9549 IC/C-MOS
2101 0294 IC/C-MOS
1004 6049 IC/C-MOS
2105 6631 IC/C-MOS
1004 7049 IC/C-MOS
1001 5566 TRANSISTOR
2590 2742 OSCILLATOR/CRYSTAL
1005 3886 PCB ASSY(MA2M)
1004 3474 IC/MONOLITHIC
2114 1421 IC/PHOTO COUPLER
2250 1627 TRANSISTOR
2250 1591 TRANSISTOR
2390 3021 DIODE
2390 3018 DIODE
2315 3132 DIODE
2360 1939 DIODE/ZENER
3501 7049 JACK/DC
3612 0665 JACK/PHONE
3612 0789 JACK
3501 4816 JACK/DIN
1005 6773 PCB ASSY(LCD1M)
1000 6502 LSI
2590 2177 THERMISTOR
2775 3286 POTENTIOMETER/TRIMER
1005 3887 PCB ASSY(CN1)
1005 3888 PCB ASSY(CN2)
2315 3132 DIODE
1004 6705 LED
2765 2213 VOLUME
1005 3891 PCB ASSY(KY1M)
1005 3893 PCB/ASSY(KY2M)
2301 0101 DIODE
2301 0101 DIODE
6922 2721 WHITE KEY SET/LT
6922 2731 WHITE KEY SET/LT
6906 8482 BLACK KEY SET 10P
6906 8592 BLACK KEY SET 5P
6927 4260 RUBBER/KEY LT SET
Notes:N- New parts
Q- Quantity used per unit
R- Rank
SPECIFICATION
TK-M241539*1(M702)
TC55257DFL-70L(EL)
MSM538002E1FGSKDR1
MSM531602F35GSKDR1
GT913F
UPD6379GR-E1
S-816A50AMC-BAZ-T2
TC74HC74AF-TP1
TC74VHC00FT(EL)
TC74VHC08FT(EL)
S-80940ANMP-DD4-T2
2SB1181TLR
AT-49-30M
TK-M241540*1(M702)
LA4635A
PC900V
2SC1740STPS
2SB1237TV2R
SRT14
1T2
1SS133T-77
MTZJ5.1C-T77-T
HEC2305-01-330
YKB21-5006
YKB21-5010
YKF51-5051
TK-M241539*2(M702)
ML9040-B02GA
TBPS1R103J440H5Q
EVM3SSX50B53
TK-M241541*1(M702)
TK-M341421*1(M702)
1SS133T-77
EL-204HD-TR4-7(A)
RS20H121-2KB
TK-M140687*9(M702)
TK-M140688*9(M702)
1S2473-T-77-T
1S2473-T-77-T
M312118A*1
M312118A*2
M140369B-3
M140369B-4
M340985*1
- 22 -
Q PRICE CODE R
1 DQ A
1 AS A
1 AZ A
1 BH A
1 BP A
1 AO A
1 AD A
1 AD A
1 AC A
1 AC A
1 AC A
1 AC B
1 AG B
1 CO B
1 AN A
1 AK B
6 AA A
2 AB A
1 AF B
1 AA B
4 AA B
1 AA B
1 AC A
1 AG B
1 AC B
1 AH B
1 CC B
1 AU A
1 AD B
1 AC B
1 BL B
1 AP B
44 AA A
1 AA B
1 AD A
1 BK B
1 BJ B
64 AA B
58 AA B
4 AP A
1 AP A
2 AM A
1 AI A
1 BJ B
