Frigidaire GALLERY GDPP4517AF Getting Started

GETTING
WITH YOUR
FRIGIDAIRE GALLERY DISHWASHER
BEFORE YOU START
Set up your dishwasher
Make sure the top rack, bottom rack and silverware basket are in place prior to
operating the dishwasher. See OPERATING INSTRUCTIONS in the Use & Care Manual.
Fill Rinse Aid dispenser
Rinse aid greatly improves drying and reduces water spots. Twist off the rinse aid
dispenser cap and fill until the indicator reaches full, then replace the cap.
If installed with a garbage disposal
Ensure the knock-out plug is removed so the dishwasher can properly drain. See the Installation
Instructions for further details.
YOU'RE IN CONTROL
Your dishwasher controls
To begin using your dishwasher, open the door and select one of the cycle options from the control panel. The
Wash and Dry settings can be adjusted based on the cycle chosen. Indicator lights
illuminate as each cycle or option is selected.
1 2 3 4
1. Select HEAVY WASH† for heavily soiled loads of pots, pans,
casserole dishes and dinnerware.
2. Select NORMAL WASH† for light to heavily soiled loads.
3. Select QUICK WASH (34 minutes) for lightly soiled loads only.
4. Select CHINA CRYSTAL for lightly soiled China, Crystal or
other delicate items.
5. Select TOP RACK† for light to heavily soiled small loads in the
upper rack.
6. ENERGY SAVER† uses less energy by washing lightly soiled
loads with less water and the air dry setting.
7. Select RINSE ONLY for rinsing dishware that will be washed later.
8. The FAVORITE CYCLE program saves preferred cycle and
options to a one touch control. See Use & Care Manual for more
information.
† Cycle uses a soil sensing feature to determine the best wash
performance. The soil sensing feature automatically engages
when selecting the HEAVY, NORMAL, TOP RACK or ENERGY
SAVER wash cycles.
REMEMBER
• Select cycles and options with the door open. Press
START immediately before closing the door.
• To add an item, press START again immediately
before closing the door to resume the cycle.
• Load rack so large items do not block the spray
arm or detergent dispenser.
5 6 7 8
9
9. START/Cancel starts or cancels a cycle. To start the cycle,
press START/Cancel button and immediately close the
dishwasher door. To cancel the cycle, open the dishwasher
door and press the START/Cancel button until the cycle and
option LEDs turn off.
10. The STATUS WINDOW displays remaining time in cycle, delay
time setting or "close door" reminder.
11. The INDICATOR LIGHTS provide cycle status information
showing Delayed (delay start)/, Clean (clean non-sanitized) and
Sanitized (clean with sanitized option).
12 13
12. WASH PRESSURE provides the choice of Scour (extra heavy
soil), Surge (heavy to normal soil) or Spray (light soil).
13. WASH TEMP provides the choice of Sanitize, High or Normal
water temperature.
14. DRY provides the choice of MaxBoost™ (extended dry time),
Heat (normal dry time) or Air (air dry only). Press and hold
the Dry button until the lock icon comes on to lock the
dishwasher controls. Press and hold the Dry button until the
lock icon goes off to unlock the controls.
15. DELAY TIME sets a delayed starting time to begin the wash
cycle from 1-24 hours.
10 11
14 15
A23320501A (2110)
