AXIOMTEK ICO300-83M User Manual

Robust din-rail fanless embedded system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ICO300-83M
Robust Din-rail Fanless Embedded
System
User's Manual
V 1.0.0.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICO300-83M and is the answer not in the manual?

Questions and answers

Related Manuals for AXIOMTEK ICO300-83M

Summary of Contents for AXIOMTEK ICO300-83M

  • Page 1 ICO300-83M Robust Din-rail Fanless Embedded System User’s Manual V 1.0.0.0...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice.

  • Page 3: Safety Precautions

    Disconnect the power cord from the ICO300-83M before making any installation. Be sure both the system and the external devices are turned OFF. Sudden surge of power could ruin sensitive components. Make sure the ICO300-83M is properly grounded. Make sure the voltage of the power source is correct before connecting the equipment to the power outlet.

  • Page 4: Classification

    Classification Degree of production against electric shock: not classified Degree of protection against the ingress of water: IP40 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxid e. Mode of operation: Continuous Type of protection against electric shock: Class I equipment General Cleaning Tips...
  • Page 5 Cleaning Tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals. Below is a listing of items you may need or want to use while cleaning your computer or computer peripherals.

  • Page 6: Scrap Computer Recycling

    For the computers that are no longer useful or no longer working well, please contact your Axiomtek distributor for recycling and we will make the proper arrangement. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation. ® ®...

  • Page 7: Table Of Contents

    Table of Contents Safety Precautions ....................iii Classification ......................iv General Cleaning Tips ..................iv Scrap Computer Recycling ................... vi SECTION 1 INTRODUCTION .................. 1 General Description ................1 System Specifications ............... 2 1.2.1 CPU ........................2 1.2.2 BIOS ........................2 1.2.3 System Memory ....................

  • Page 8: Section 1 Introduction

    E3930(1.3GHz) processors supporting industrial temperature range of -40℃ to +75℃. Its front accessible I/O cabling is very convenient for wiring and maintenance. ICO300-83M offers a HDMI output, making it particularly well-suited for communication control, SCADA and industrial automation. Its compact size with Din-rail mounting allows for easy installation into control cabinet. Pre- ®...

  • Page 9: System Specifications

    ICO300-83M not only supports Windows 10, but also supports embedded OS, ® such as Windows 10 embedded and Linux package support. For storage device, ICO300-83M supports one SATA SSD (or HDD) and one mSATA. System Specifications 1.2.1 ⚫ Onboard Intel® ATOM® E3930 (1.3GHz) 1.2.2...

  • Page 10: Ethernet Ports

    ICO300-83M Series User’s Manual 1.2.5 Ethernet Ports ⚫ LAN Chip: Intel Ethernet Controller I210-IT. ⚫ LAN 1 ~3 support 10/100/1000 Base-T with 1.5KV magnetic isolated protection. 1.2.6 Storages ⚫ 1 x 2.5” SATA drive bay. ⚫ 1 x mSATA. 1.2.7 ⚫...

  • Page 11: Power

    ICO300-83M Series User’s Manual 1.2.9 Power ⚫ This product is intended to be supplied by a Listed Power Adapter or DC power source, rated minimum 24 Vdc, minimum 2.43 A, Tma = minimum 75 degree C, output complies with LPS/PS2.

  • Page 12: Digital I/O Connector And Pin Definition

    ICO300-83M Series User’s Manual 1.2.11 Digital I/O Connector and Pin Definition ⚫ 8bit DI and 8bit DO with 2KV optical isolation Digital Input Input Channels 8 source type Input Voltage 0 to 30VDC Input Digital Input Levels for Logic level 0: Close to GND.

  • Page 13: Restore Bios Optimal Defaults (Clear Cmos)

    ICO300-83M Series User’s Manual 1.2.12 Restore BIOS Optimal Defaults (Clear CMOS) ⚫ Press the tact switch can restore BIOS optimal defaults. (The buttom is next to the HDMI connector) 1.2.13 System LED ⚫ There are showed the LED’s indicators and functional descriptions.

  • Page 14: Dimensions

    ICO300-83M Series User’s Manual 1.2.18 Dimensions 66mm (2.60”) (W) x110mm (4.33”) (D) x155mm (6.10”) (H) ⚫ 1.2.19 System I/O Outlets ⚫ One DC Power Input with terminal block. ⚫ Five Antenna holes. ⚫ One HDMI ⚫ Two USB 3.0 connectors ⚫...

  • Page 15: Non-Sparking Low Power Equipment

    ICO300-83M Series User’s Manual Non-sparking low power equipment The Robust Din-rail Fanless Embedded System ICO300-83M(ATEX&CID2) is designed according to EN IEC 60079-0:2018 and EN IEC 60079-7:2015+A1:2018 will be used in Zone 2 and Class I Division 2 (CID2). 1.3.1 General information for use Types of protection: ⚫...
  • Page 16 ICO300-83M Series User’s Manual The I/O ports of non-sparking equipment will be possible connected instruments or equipments as below examples: ⚫ Four isolated Terminal Block connectors support RS232/RS422/RS485 (COM1~COM6) It will be possibled linked the temperature s ensor, wet sensor, meters.

  • Page 17: Field Installation

    ICO300-83M Series User’s Manual 1.3.2 Field Installation ⚫ Power Terminal Block suitable for 28-16 AWG (0.0804-1.318 mm²) wire size, torque value 1.7 lb-in (0.1921 Nm). ⚫ COM Port Terminal Block suitable for 28-16 AWG (0.0804-1.318 mm²) wire size, torque value 1.7 lb-in (0.1921 Nm).

  • Page 18: Dimensions

    ICO300-83M Series User’s Manual Dimensions The following diagrams show you dimensions and outlines of the ICO300-83M. Introduction...
  • Page 19 ICO300-83M Series User’s Manual Introduction...

  • Page 20: I/O Outlets

    ICO300-83M Series User’s Manual I/O Outlets The following figures show you I/O outlets on front view and top view of the ICO300- 83M. Introduction...
  • Page 21 ICO300-83M Series User’s Manual This page is intentionally left blank. Introduction...

  • Page 22: Section 2 Hardware Installation

    ICO300-83M Series User’s Manual SECTION 2 HARDWARE INSTALLATION The ICO300-83M is convenient for your various hardware configurations, such as Memory Module and Hard Disk Drive. The chapter 2 will show you how to install the hardware. It includes: Installing the Memory Module Step 1 Turn off the system.
  • Page 23 ICO300-83M Series User’s Manual Step 4 The memory module is locked by two latches on the sides. We strongly recommend using “LDC737” silicone on the two sides of the memory for good ability of vibration. Step 5 Put the cover back, and fasten screws tightly to lock the chassis.

  • Page 24: Installing The Msata Module

    ICO300-83M Series User’s Manual Installing the mSATA module Step 1 Turn off the system. Step 2 Loosen all screws of the cover and remove the cover from the system. Step 3 Install the mSATA as below socket. Insert the module to the socket and fasten with the screw.

  • Page 25: Installing The Hard Disk Drive

    ICO300-83M Series User’s Manual Installing the Hard Disk Drive Step 1 Turn off the system. Step 2 Loosen all screws of the cover and remove the cover from the system. Step 3 Loosen 4pcs screws of the HDD tray, and fix the HDD into tray with screws.

  • Page 26: Installing Din-Rail Mounting

    ICO300-83M Series User’s Manual Installing Din-rail Mounting The ICO300-83M provides Din-rail Mount for customers can install as below: Step 1 Prepare Din-rail Mount assembling components (screws and bracket) ready. Step 2 Assembly the bracket to the system and fasten screws tight.
  • Page 27 ICO300-83M Series User’s Manual This page is intentionally left blank. Hardware Installation...

  • Page 28: Section 3 Ami Uefi Bios Utility

    ICO300-83M Series User’s Manual SECTION 3 AMI UEFI BIOS UTILITY The AMI UEFI BIOS provides users with a built-in Setup program to modify basic system configuration. All configured parameters are stored in a flash-backed-up to save the Setup information whenever the power is turned off...

  • Page 29: Advanced Features

    ICO300-83M Series User’s Manual Advanced Features This Advanced section allows users to configure and improve your system, to set up some system features according to your preference. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 30 ICO300-83M Series User’s Manual ⚫ eMMC Configuration Scroll to this item and press <Enter> to view the eMMC Configuration informations. (Please refer below graphics.) AMI UEFI BIOS Utility...
  • Page 31 ICO300-83M Series User’s Manual ⚫ CPU Configuration Scroll to this item and press <Enter> to view the CPU Configuration informations. (Please refer below graphics.) AMI UEFI BIOS Utility...
  • Page 32 ICO300-83M Series User’s Manual ⚫ SATA Configuration Scroll to this item and press <Enter> to view the SATA Configuration informations. (Please refer below graphics.) AMI UEFI BIOS Utility...
  • Page 33 ICO300-83M Series User’s Manual ⚫ USB Configuration Scroll to this item and press <Enter> to view the USB Configuration information. (Please refer below graphics.) AMI UEFI BIOS Utility...
  • Page 34 ICO300-83M Series User’s Manual ⚫ H/W Monitor Scroll to this item and press <Enter> to view the monitor hardware status. (Please refer below graphics.) AMI UEFI BIOS Utility...
  • Page 35 ICO300-83M Series User’s Manual ⚫ F81804 Super IO Configuration The default setting for all serial ports are RS232. You can change the setting by selecting the value you want in each COM Port Type. Supports RS422 & RS485 mode. (Please refer below graphics.)
  • Page 36 ICO300-83M Series User’s Manual You can enable COM port High-speed mode to support higher speed com port buard rate. AMI UEFI BIOS Utility...
  • Page 37 ICO300-83M Series User’s Manual AMI UEFI BIOS Utility...
  • Page 38 ICO300-83M Series User’s Manual ⚫ Device Configuration You can change the COM3~6 setting in this section. AMI UEFI BIOS Utility...
  • Page 39 ICO300-83M Series User’s Manual AMI UEFI BIOS Utility...
  • Page 40 ICO300-83M Series User’s Manual AMI UEFI BIOS Utility...

  • Page 41: Chipset Feature

    ICO300-83M Series User’s Manual Chipset Feature AMI UEFI BIOS Utility...
  • Page 42 ICO300-83M Series User’s Manual AMI UEFI BIOS Utility...

  • Page 43: Security

    ICO300-83M Series User’s Manual Security The default setting for Administrator Password is “Not setting passwords”. The Security menu allows users to change the security settings for the system. You can set the password for both Administrator Password and User Password.

  • Page 44: Boot Type

    ICO300-83M Series User’s Manual Boot Type The default setting of boot mode is [UEFI], UEFI – support to boot any UEFI-capable OS and option rom Legacy - support to boot any legacy-capable OS and option rom Compitable – customize boot mode of uefi/legacy of specific item...
  • Page 45 ICO300-83M Series User’s Manual The default setting boot from onboard LAN PxE Rom is [Disabled] (Please refer below graphics.) AMI UEFI BIOS Utility...
  • Page 46 ICO300-83M Series User’s Manual AMI UEFI BIOS Utility...
  • Page 47 ICO300-83M Series User’s Manual The Boot Option Priorities can select by Boot Option #1, #2…, If user is using a USB Device. (Please refer below graphics.) AMI UEFI BIOS Utility...

  • Page 48: Save & Exit

    ICO300-83M Series User’s Manual Save & Exit This section allows you to determine whether or not to accept your modifications. Type “Y” to quit the setup utility and save all changes. Type “N” to bring you back to the Previous Setup utility.
  • Page 49 ICO300-83M Series User’s Manual This page is intentionally left blank. AMI UEFI BIOS Utility...

  • Page 50: Appendix Awatchdog Timer

    ICO300-83M Series User’s Manual APPENDIX A WATCHDOG TIMER About Watchdog Timer After the system stops working for a while, it can be auto-reset by the watchdog timer. The integrated watchdog timer can be set up in the system reset mode by program.
  • Page 51 ICO300-83M Series User’s Manual Disable WDT  Enable configuration: O 2E 87 ; Un-lock super I/O O 2E 87  Select logic device: O 2E 07 O 2F 08  WDT device disable: O 2E 30 O 2F 00 Watchdog Timer...
