- Page 1 User Manual 20V CORDLESS STRING TRIMMER BBT-YOM02 Please scan the QR CODE for more services. Read all safety rules and instructions carefully before operating this tool.
-
Page 2: Table Of Contents
CONTENTS ....................................Contents ......................................Symbols ................................. Safety warnings Machine information ................................. Assembly ..................................10-13 Operation ..................................... 13-15 Maintenance ..................................... Warranty .................................... -
Page 3: Symbols
SYMBOLS The following symbols are used in the user manual or on the product: Dispose of packaging and appliance Observe caution and safety notes. in an environmentally friendly way! Caution - electric shock! Attention! The blade continues to Danger to life. turn after releasing the switch. -
Page 4: Safety Warnings
SAFETY WARNINGS GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, re or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 3) Personal safety Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the in uence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. Use personal protective equipment.
- Page 6 5) Battery tool use and care Recharge only with the charger speci ed by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of re when used with another battery pack. Only use power tools with speci cally designated battery packs. Use of any other battery packs may create a risk of injury and re.
- Page 7 • Keep all parts of the body away from the cutter blades. Do not remove cut material or hold material to be cut when blades are moving. Make sure the switch is o when clearing jammed material. A moment of inattention while operating the string trimmer may result in serious personal injury.
- Page 8 • Protect the battery pack from impacts, and don’t attempt to open it. • Never discharge the battery pack completely, and recharge occasionally if not used for a prolonged period. Charge only BBT-DC20A and BBT-DC40A type rechargeable battery packs with the charger. Other types of batteries may burst causing personal injury and damage.
-
Page 9: Machine Information
MACHINE INFORMATION Technical Speci cations Model Number BBT-DC20A Model No. BBT-YOM02 Battery type Lithium-ion Voltage Rated voltage Capacity 2.0 Ah Recommended charger BBT-YFT20V Weight 0.3 kg No load speed 8500 rpm Model Number BBT-YFT20V Charger input 100-120V~60Hz 65W Charger output 2.5A... -
Page 10: Assembly
ASSEMBLY • •... - Page 12 1. Hand Grip 9. Handle Clamp Screw 17. Blade (20pcs supplied) 2. Switch Lock 10. Telescopic Shaft 18. Edging Guide 3. ON/OFF Switch 11. Head Swivel Lock 19. Battery Release Button 4. Battery level indicator 12. Shaft Lock Sleeve 20. Charger 5.
-
Page 13: Operation
Insert and remove the Battery: • To insert the Battery Pack 6, press the Battery Release Button 19 and slide it into the Battery Holder 5 on the handle 1 (see Fig. E). It will clip into place. • To remove the Battery Pack, press the Release Button and pull it out of the Battery Holder. Li-ion Battery Pack: Note: •... - Page 14 • Never operate the trimmer when you are tired, ill, or under the in uence of alcohol, drugs or medicine. • Use the trimmer for cutting grass and light weeds only. Do not use it for any other purpose. • Keep in mind that the user is responsible for accidents or hazards occurring to other people or their property.
-
Page 15: Maintenance
Replacement of cutting blades: The cutting blades are attached to the cutter head by placing the large keyhole molded into each blade over the pins on the bottom of the cutter head. Pull the blades outwards to snap the smaller portion of the keyhole tightly onto the pin. -
Page 16: Warranty
WARRANTY Ningbo Babytec Technology Co., Ltd (Hereinafter referred to as Babytec) warrants this product against defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by the original purchaser (’Warranty Period’). The following circumstances are excluded from this guarantee: •...
