- Page 1 Lantech IPOA-1000H User Manual Ver.1.01 Apr-2015...
- Page 2 Recommendation for Shielded network cables STP cables have additional shielding material that is used to reduce external interference. The shield also reduces the emission at any point in the path of the cable. Our recommendation is to deploy an STP network cable in demanding electrical environments. Examples of demanding indoor environments are where the network cable is located in parallel with electrical mains supply cables or where large inductive loads such as motors or contactors are in close vicinity to the camera or its cable.
- Page 3 FCC MARKING This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits designed provide reasonable protection against harmful interference when equipment operated commercial environment.
- Page 4 NOTE: Always make sure the total length of the TX cable DOES NOT exceed 100meter. Total length is defined as length A + length B Maximum total cable length is 100meter. During 100Mbps transmission, the maximum total cable length is 100 meter. During 1000Mbps speed transmission, recommend maximum cable length less than 90 meter is more desired.
- Page 5 Installation package This unit can be installed by din-rail mounted or wall-mounted. Din-rail brackets and wall-mounted bracket are included. Wall mount bracket x 2 DIN Rail Kit x 1 Terminal Block x 1 Power connection This unit is equipped with Voltage booster feature which allow low input voltage 12/24VDC to be boost up to 55VDC for 30w POE power.
- Page 6 STEP 2 – Connect power wire to +V1- or Connect +V2- (SW) as shown above STEP 3 – Plug into terminal block socket shown above. Polarity needs to match the V+ and V- WARNING -- Always SHUTS OFF power source to connect power wire. WARNING –...
- Page 7 Dip Switch setting This unit is equipped with 4 pin dip switches which allow users to set the desired POE power setting to meet your desired POE network. Refer to the setting shown below: 2 Pair** 2 pair 30W is selected 4 Pair** 4 pair 60W is selected (DEFAUT) Mode A...
- Page 8 Specification Standards IEEE802.3 10Base-T IEEE802.3u 100Base-TX/100Base-FX IEEE802.3ab 1000Base-T IEEE802.3x Flow Control and Back pressure IEEE802.3at PoE/PSE Switch Architecture Store and Forward DIP Switch Select 2 pair or 4 pair (only on 24V/48V model) Mode A or B Standard power budget High Power budget Connectors RJ-45 Socket: CAT-5 (10/100/1000Mbps) Twisted Pair cable Auto MDI/MDI-X...
