Summary of Contents for Photon Systems Instruments SL 3500
- Page 2 Manual Version: 2021/12 © PSI (Photon Systems Instruments), spol. s r.o. www.psi.cz This document and its parts can be copied or provided to a third party only with the express permission of PSI. The contents of this manual have been verified to correspond to the specifications of the device. However, deviations cannot be ruled out.
-
Page 3: Table Of Contents
ABLE OF ONTENT Warnings and Safety Precautions ......................4 General Description ..........................5 Standard Versions ............................5 2.1.1 Version SL 3500-A ............................5 2.1.2 Version SL 3500-B ............................5 2.1.3 Version SL 3500-C ............................5 2.1.4 Version SL 3500-D ............................6 2.1.5... -
Page 4: Warnings And Safety Precautions
Never cover the power supply (control unit) or the light panel! Low ventilation can cause an irreversible damage to the device. WARNING: The LED Light Source SL 3500 is considered Class 1M* LED Product. LED radiation may be harmful to eye. Avoid direct and strongly reflected exposure. It is recommended to use protective glasses. -
Page 5: General Description
Different versions of the device are available with LEDs spanning the spectrum from blue to far-red. The SL 3500 panels can be used as stand-alone units, or they can be integrated into cultivation areas and to provide lighting for growth rooms. -
Page 6: Version Sl 3500-D
Stand-alone operation: manual intensity control • Supplied with a stand and holder 2.1.5 SL 3500-E ERSION Fig. 4 Version SL 3500-D • Panel size: 30 × 20 cm • Number of high-power LEDs: 240 (3 × 80) • 4 added Far red LEDs •... -
Page 7: Light Controller Lc 100
(seconds to hours) and maintains also generation of short pulses (micro-seconds). It can control up to 4 lights/colors in SL 3500; each light /color can be configured and controlled independently. Light Controller LC 100 supports light modulation according to... -
Page 8: Modular Stand
2.3.5 ODULAR TAND Allows many spatial possibilities in arrangement and attachment of scientific instrumentation. Fig. 8 Modular stand 2.3.6 DDITIONAL ROTECTIVE LASSES Radiation safety glasses protecting against excessive LED radiation – equipped with side cover and protective filters. One pair of glasses is provided with the device free of charge. Fig. -
Page 9: Technical Specification
ECHNICAL PECIFICATION PPFD Up to 3,000 µmol.m at the distance of 20 cm • Model A: 17.5 × 17.5 × 11 cm (with holder screws: 17.5 × 28 × 11 cm) Panel External Dimension • Model B and C: 25 × 22.5 × 11 cm (with holder screws: 25 × 33 × 11 cm) (W ×... - Page 10 Step 2: Connect the Light Panel to the Power Supply (control unit) (Fig. 11). Connect the Light Panel to the Power Supply (control unit) using the LED PANEL connector. For the external control, connect the communication cable of the Light Controller LC 100 or of a PC to the Power Supply –...
-
Page 11: Device Operation
Step 5: Switch on the device. Switch on the power switch of the Power Supply control unit) (Fig. 13). When using your LED Light Source with the Light Controller, first switch on the Power Supply. Then, switch on the Light Controller LC 100 (Fig. -
Page 12: Manual Control
ANUAL ONTROL The light intensity can be set on the front panel of the Power Supply (control unit) in the range of 0 – 100 %. When using a multiple channel version of the device, each channel controls a different color. Each color’s intensity can be controlled independently. -
Page 13: Warranty Conditions
ONDITIONS Photon Systems Instruments, Ltd. (PSI) warrants all its instruments to be free from defects in materials or workmanship for a period of one year from the date of invoice/shipment from PSI. Warranty term for the European Union member states is two years.
