Photon Systems Instruments LED Light Source SL 3500 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the LED Light Source SL 3500 and is the answer not in the manual?

Questions and answers

Related Manuals for Photon Systems Instruments LED Light Source SL 3500

Summary of Contents for Photon Systems Instruments LED Light Source SL 3500

  • Page 2: Table Of Contents

    Table of Contents Table of Contents ......................... 2 1. List of Equipment ........................3 2. General Information ........................ 4 3. Safety Precautions ........................6 3. Device Installation ........................7 6. Device Operation ........................10 7. Statement of Limited Warranty .................... 11...

  • Page 3: List Of Equipment

    1. List of Equipment Carefully unpack the carton, which contains: • LED Light Panel with attached power and communication cable(s). • Power Supply (control unit). • Detachable mains cable. • Adjustable stand. • This Instruction Manual (on a CD or a printed version). •...

  • Page 4: General Information

    2. General Information LED Light Sources can be used as stand-alone devices powered by autonomous electronics and manually controlled from the Power Supply front panel. If supplied with the Light Controller LC 100 or with the Light Studio software, the LED Light Sources can be programmed and precisely controlled in the light mode, intensity and timing.
  • Page 5 C) Based on the panel size: 1) 13 x 13 cm 2) 20 x 20 cm 3) 30 x 20 cm...

  • Page 6: Safety Precautions

    3. Safety Precautions • The LED radiation may be harmful to eyes, avoid direct and strongly reflected exposure. 365 nm through 390 nm LEDs can be considered Class 1M LED Product. Wear protective glasses! • The device has a built-in temperature control and safety temperature fuse. The Light Panel switches off automatically when the Power Supply (control unit) gets heated above 70 ºC and/or the Light Panel gets heated above 60 ºC.

  • Page 7: Device Installation

    3. Device Installation REMEMBER! • FIRST connect all device parts with cables. • THEN connect the device to an electrical power source and switch it on. FIVE STEPS FOR EASY AND SAFE DEVICE INSTALLATION: Step l: Mount the Light Panel onto the adjustable stand. [1] Insert the rod into the fitting of the stand base.
  • Page 8 Important note: In the three-channel device version (e.g., Red-Green-Blue), the Light Panel and the Power Supply must be always connected by both supplied cables – [1] and [2] in the picture. Step 3: Connect the mains cable to the Power Supply (control unit). [1] Connect the mains cable to the connector on rear part of the Power Supply (control unit).
  • Page 9 Step 5: Switch on the device. [1] Switch on the power switch of the Power Supply (control unit). [2] When using your LED Light Source with the Light Controller, first switch on the Power Supply. Then, switch on the Light Controller LC 100.

  • Page 10: Device Operation

    6. Device Operation The device can be controlled either in the manual mode or in the external mode: • The manual control mode allows permanent lighting that can be controlled in the intensity. • The external control mode provides the possibility of creating sophisticated protocols for precise control of the light mode, intensity, and timing.

  • Page 11: Statement Of Limited Warranty

    7. Statement of Limited Warranty • This Limited Warranty applies only to the LED Light Source SL 3500. It is valid one year from the date of shipment. • If at any time within this warranty period the instrument does not function as warranted, return it and the manufacturer will repair or replace it at no charge.
