Getting Started
1.
Using a small screwdriver, ball point pen, etc. set the four switches on the side of the unit (see
Input Programming and Output Programming on page 2).
2.
Mount unit into panel (see Mounting on page 3).
3.
Connect unit to input signal, output signal, and power wiring (see Wiring on page 4).
4.
Check calibration (see Calibration on page 4).
Specifications are on page 4.
Dimensions
22.5
(0.886)
Dimensions shown in mm (inches)
LOVE CONTROLS DIVISION
DWYER INSTRUMENTS, INC.
P.O. BOX 373 • MICHIGAN CITY,
INDIANA 46361, U.S.A.
Iso Verter
Model SC4380/SCL4380
Installation Instructions
75
(2.950)
®
II
98.5
(3.880)
Phone: 219/879-8000
www.love-controls.com
Fax: 219/872-9057
e-mail: lit@dwyer-inst.com
Bulletin 949-0527
35.5
(1.40)
Advertisement
Table of Contents
Related Manuals for Love Controls Iso Verter II
Summary of Contents for Love Controls Iso Verter II
- Page 1 Specifications are on page 4. Dimensions 22.5 (0.886) 35.5 (2.950) (1.40) 98.5 (3.880) Dimensions shown in mm (inches) LOVE CONTROLS DIVISION Phone: 219/879-8000 DWYER INSTRUMENTS, INC. www.love-controls.com P.O. BOX 373 • MICHIGAN CITY, Fax: 219/872-9057 INDIANA 46361, U.S.A. e-mail: lit@dwyer-inst.com...
- Page 2 Input Programming RANGE SELECTION SWITCH BANK (SW-1) Turn ON the switch for the scale desired. All other switches should be OFF. If BI-POLAR INPUT is selected, the scale will be MINUS-SELECTION to PULSE-SELECTION (eg. -10 TO +10 VDC). MODE SELECTION SWITCH BANK (SW-2) 1.
- Page 3 RANGE SELECTION SWITCH BANK (SW-4) Turn ON the switch for the scale desired. All other switches should be OFF. If BIPOLAR OUTPUT is selected, the scale will be from MINUS-SELECTION to PLUS-SELECTION (eg. -10 TO +10 VDC). OUTPUT WARNING: Do not attempt to operate this device with the cover removed. Poten- tially lethal voltage is present on some of the internal components.
- Page 4 Input Impedence - Current: 10 ohms. Input Impedence - Voltage: 1 Megohm. ©Copyright 2010 Dwyer Instruments, Inc. Printed in U.S.A. 3/10 FR# 949-0527 Rev. 1 LOVE CONTROLS DIVISION Phone: 219/879-8000 DWYER INSTRUMENTS, INC. www.love-controls.com P.O. BOX 373 • MICHIGAN CITY, Fax: 219/872-9057 INDIANA 46361, U.S.A.
