Quick Setup Guide
L920Pro Wireless Base
PAX TECHNOLOGY INC.
PAX TECHNOLOGY INC.
Contents Checklist
Please check the components after unpacking. If any one of
them is missing, or if there is a page missing from the product
manual,ect.,please contact the dealer.
L920Pro-BE
Product manual
Rubber Foot
Reset Button
Charging Contact
Charging Contact
Rubber Foot
Indicator
Front
USB HOST
The matching diagram for A920Pro host and L920Pro wireless
base is as follows:
Rubber Foot
Nameplate
1) Connect the base's Power port with the power adapter.
Barcode
2) Connect the base's RS232 port with the cash register's serial
port. (When you do this step, skip step 3.)
3) Connect the base's USB Slave port with the cash register's
USB port.(When you do this step, skip step 2.)
4) According to the requirements, connect the base's LAN port
with the gateway device, such as router, LAN switch. (This
Rubber Foot
step is optional.)
5) Embed the connected cables in the trunking according to the
outlet direction at the bottom.
Back
6) Place the base on a stable flat surface to complete the base
installation.
Trunking
Power
Type-C
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for PAX L920Pro
Summary of Contents for PAX L920Pro
- Page 1 L920Pro-BE Power USB HOST Type-C Product manual The matching diagram for A920Pro host and L920Pro wireless base is as follows: Rubber Foot Rubber Foot Nameplate Reset Button 1) Connect the base's Power port with the power adapter.
