Hunter 42660-01 Installation And Operation Manual

Type 2 models ceiling fan

Advertisement

Quick Links

For Your Records and Warranty
Assistance
Model Name: _____________________
Catalog/Model No.: ________________
Serial No.: ________________________
Date Purchased: ___________________
Where Purchased: _________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE 2 Models
42660-01 • 01/30/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 42660-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hunter 42660-01

  • Page 1 Model Name: _____________________ Catalog/Model No.: ________________ Serial No.: ________________________ Date Purchased: ___________________ Where Purchased: _________________ For reference also attach your receipt or a copy of your receipt to the manual. installation and operation manual for Hunter Ceiling Fans TYPE 2 Models 42660-01 • 01/30/08...
  • Page 2: Table Of Contents

    Without a Bowl Light Fixture ..11 9 • Operating and Cleaning Your Ceiling Fan ......15 10 • Troubleshooting ....16 ©...
  • Page 3 Support Brace Ceiling Outlet Box Angled Mounting Style Angled Mounting recommended for a vaulted or angled ceiling 42660-01 • 01/30/08 • Hunter Fan Company Understanding Mounting and Installer’ s Choice® Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include instructions for all three Installer’s Choice mounting methods. Considering Optional Accessories Consider using Hunter’s optional accessories, including a wall-mounted...
  • Page 4: Getting Ready

    To install a ceiling fan, be sure you can do the following: • Locate the ceiling joist or other suitable support in ceiling. • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: • Electric drill with 9/64” bit...
  • Page 5: Installing The Ceiling Plate

    For Angled Ceilings: Be sure to orient the ceiling plate so that the two tabs are pointing toward the ceiling peak. 2-2. Your fan comes with four preinstalled noise isolators. Check to make sure all four isolators are in place and were not removed during shipment.
  • Page 6: Assembling And Hanging The Fan

    3-4. Remove the set screw from the adapter. 3-5. Place the low profile washer into the canopy with the lip down. 3-6. Align the holes in the washer with the holes in the adapter. Assemble securely with three low profile screws. Hanging the Fan: Note: To hang the fan, you must tilt the canopy to an almost vertical position so that the canopy slots sit on the ceiling plate hooks. 3-7. Raise the fan and align the slots in the canopy with the hooks on the ceiling plate. 3-8. Place the slots over the hooks to hang the fan.
  • Page 7: System

    4 • Securing Fan to Secondary Support System 4-1. Find the looped end of the braided cable and insert it through the ceiling plate and one of the holes in the outlet box into the ceiling. 4-2. Access the support brace in the ceiling. You may not be able to do this from below the ceiling depending on your installation site.
  • Page 8: Wiring The Fan

    5-3. Connect the bare or green ground wire (grounded) from the ceiling to the green ground wire (grounded) from the ceiling plate and the green ground wire from the fan. 5-4. Connect the white wire (ungrounded) from the ceiling to the white wire (ungrounded) from the fan.
  • Page 9: Installing The Canopy And Canopy

    Note: Your fan may have multiple tabs and grooves that must be aligned. 6-2. Swing the fan up to align the canopy screw holes with the mounting holes on the ceiling plate. WARNING: The slots in the canopy must remain engaged while swinging the canopy for alignment.
  • Page 10: Assembling The Blades

    Note: Some blade mounting screws are installed in the motor to secure shipping blocks. 7-4. For each blade, insert one blade mounting screw through the blade iron, and attach lightly to the fan. Insert the second blade mounting screw, then securely tighten both mounting screws. Use with grommet...
  • Page 11: Completing Your Installation With Or Without A Bowl Light Fixture

    8-5. If you want to install the light fixture, proceed with step 7-6 now. If you do not want to install the light fixture, you need to uninstall it now. See “Uninstalling the Light Fixture” on step 7-15. Once you have uninstalled the light fixture, continue with step 7-6. 42660-01 • 01/30/08 • Hunter Fan Company Steps 8-1 – 8-3 Housing Upper Assembly Switch...
  • Page 12 Make sure the connectors are properly aligned before connecting them. Incorrect connection could cause improper operation and damage to the product. 8-7. Place the lower switch housing assembly over the upper switch housing. Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. 42660-01 • 01/30/08 • Hunter Fan Company Connector Steps 8-6 – 8-7 Lower Switch Housing Plug Connector...
  • Page 13 (You may find the plastic breakaway connector on the end of the extra chain.) 8-10. Thread the fan pull chain through the hole in the metal disk. Then, thread the fan pull chain through the hole in the center of the glass bowl. 8-11. Thread the light pull chain through the hole in the center of the glass bowl. Then, Thread the light pull chain throught the hole in the center of the cover plate.
  • Page 14 (female) through the hole. 8-20. Install the dummy terminals (included in the sack parts) on the two disconnected wires in the lower switch housing. 8-21. Install the switch housing cap and plug button to the lower switch housing. 8-22. Once you have uninstalled the light fixture, continue with step 8-6. Male Dummy Terminal Female Dummy Terminal Plug Button 42660-01 • 01/30/08 • Hunter Fan Company Lower Switch Housing Threaded Rod Steps 8-17 – 8-19 Step 8-21...
  • Page 15: Fan

    9 • Operating and Cleaning Your Ceiling Fan 9-1. Turn on electrical power to the fan. 9-2. The fan pull chain controls power to the fan. The pull chain has four settings in sequence: High, Medium, Low and Off. • Pull the chain slowly to change settings. • Release slowly to prevent the chain from recoiling into the blades. • The chain uses a breakaway connector that separates if the chain is jerked. If this happens, simply reinsert the chain into the connector.
  • Page 16: Troubleshooting

    2. Check to see if the blade is cracked. If so, replace all the blades. Problem: Excessive wobbling. 1. If your fan wobbles when operating, use the enclosed balancing kit and instructions to balance the fan. 2. Tighten all blade iron screws.
