- Page 1 EDGE with UNLOCKS THE MINERALS FOR BETTER ABSORPTION EDGE Note: The colour and specifications of the product may vary from that shown on the user manual.
-
Page 2: Table Of Contents
EDGE WITH AYURFRESH™ CONTENTS The Power of Dr.Aquaguard EDGE......................Dr.Aquaguard EDGE and Other Mineral Enrichment Technologies............. Installing Your EDGE ............................Input Water Quality Usage Limitations........................ Know Your Dr.Aquaguard EDGE........................Precautions When Using Ayur Water........................Cleaning and Disinfection of Water Storage Tanks – Ayur Tank & Regular Water Tank........Here’s How Your Dr.Aquaguard EDGE Works.................... -
Page 3: The Power Of Dr.aquaguard
THE POWER OF Dr.Aquaguard EDGE WITH AYURFRESH Dr.Aquaguard EDGE removes all harmful substances from water and retains the essential natural minerals. But what’s really different about this purifier, is that it brings you the Goodness of 7 Ayurvedic ingredients in your water purifier with AYURFRESH™^. Along with Active Copper Maxx™* technology that adds Calcium, Magnesium, Copper and Zinc to your drinking water, Dr.Aquaguard EDGE ensures that you get the Goodness of Ayurvedic ingredients in your water. - Page 4 Dr.Aquaguard EDGE WITH AYURFRESH OTHER MINERAL ENRICHMENT TECHNOLOGIES BIOTRON™** TECHNOLOGY The Biotron is a patented (applied) Multiple Magnetic Field (MMF) generating device. It creates a magnetic field in the water. This magnetic field breaks complex water molecules into fine micro-clusters, making water more bio-available so that your body can easily absorb the minerals and the goodness of water, along with its much-needed nutrients.
-
Page 5: Tm Edge
INSTALLING YOUR WATER PURIFIER Make sure that your Dr.Aquaguard EDGE is installed by a trained Eureka Forbes Service Technician only. 1. Input water must be tested for Total Dissolved Solids (TDS). 2. Install your water purifier in a suitably ventilated place. Keep it away from direct sunlight, heating devices or areas below freezing temperature. -
Page 6: Input Water Quality Usage Limitations
INPUT WATER QUALITY USAGE LIMITATIONS 1. If the input water Iron content is more than 0.3 mg/litre, use of an Iron Remover** is recommended as a Pre-treatment. 2. If the input water turbidity is more than 5 NTU, or comprises of colloidal particles, use of a special filter** is required as a pre-filter. -
Page 7: Know Your Dr.aquaguard
3. The cartridge can be bought from our Eureka Forbes Service Centre at an extra cost. 4. Ayur tank gets filled only when the regular RO water tank is full. Ensure that the regular tank and Ayur tank are full during water collection. -
Page 8: Precautions When Using Ayur Water
PRECAUTIONS WHEN USING AYUR WATER 1. Ayur water is only for drinking purposes. 2. Avoid the use of Ayur water to make baby food as it imparts flavours. Pregnant and nursing women should consult their doctor before consuming this water. 3. -
Page 9: Here's How Your Dr.aquaguard
HERE’S HOW YOUR Dr.Aquaguard EDGE WITH AYURFRESH WORK Dr.Aquaguard EDGE HD RO+UV+MTDS ( WATER FLOW DIAGRAM ) ELECTRONIC LEVEL SENSOR DRAIN REGULAR AYUR WATER WATER TANK FLOW RESTRICTOR TANK AYUR CARTRIDGE AYUR Cartridge REGULAR WATER AYUR TAP FLOW RESTRICTOR TDS MODULATOR Membrane life enhancer is recommended to be installed NOTE : THIS IS A SCHEMATIC ILLUSTRATION OF THE PRODUCT TO GIVE A VISUAL SCHEME OF WORKING OF PRODUCTS. - Page 10 EDGE WITH AYURFRESH Read attentively and understand the purifier and its functions before use. Installation and service has to be conducted by authorised persons from Eureka Forbes Limited only. Install the purifier at a location with ample ventilation. Ensure that the purifier is installed in a dry place. Do not expose it to direct sunlight or heat sources.
-
Page 11: Recommendations
Before installation, please check the expiry date of the cartridge. In case of expiry, contact our customer care number on 1860 2661 177. Exhausted Ayur cartridge is to be returned to the authorised persons of Eureka Forbes only. As per standard test conditions... -
Page 12: Important Suggestions
IMPORTANT SUGGESTIONS • Turn OFF the main switch if you don’t use your Dr.Aquaguard for more that 3-4 hours. • Store water from your Dr.Aquaguard EDGE in clean containers. For hygiene reasons, it is preferable not to store water for more than 2 days. •... - Page 13 Do not use if the cartridge packaging is open/distorted. 2. Replacement: Procure the cartridges directly from the authorised service Centre of Eureka Forbes and it should be replaced by a qualified service technician. 3. Additional Information: Children can use the Ayur water under the supervision of adults. The taste of water drawn from Dr.Aquaguard EDGE AyurFresh may vary because of water temperature, pH level, TDS level and flow rate.
- Page 14 FILTER REPLACEMENT METHODS DIY: STEPS TO REPLACE CARTRIDGE FILTER Turn o the power supply and Open the water dispenser tap and Open the front fascia. close the water supply before empty the water from regular water proceeding to change the cartridge. tank and Ayur water tank.
- Page 15 Unclip the junction connector. Rotate Filter clockwise to Replace the new lter by rst eject. aligning its position to the top manifold using the arrow guides. Grip the cartridge rmly from Carefully match and re-clip the Pull the levers on either side of the bottom, apply an upward force colour-coded junction connectors.
-
Page 16: Technical Specifications Of Dr.aquaguard
TECHNICAL SPECIFICATIONS OF Dr.Aquaguard EDGE WITH AYURFRESH *Technical Specifications are subject to change without prior notice. Technical Parameter Specification Note: The performance data presented in the table is applicable under standard laboratory conditions Model Dr.Aquaguard EDGE HD RO+UV+MTDS Actual performance may vary depending on the input water quality, water pressure and condition of filters. Input water quality/pressure/TDS are important determinants of recovery rate and rejection. -
Page 17: Tm Edge
KNOW YOUR Dr.Aquaguard EDGE WITH AYURFRESH NEXT-GEN LED DISPLAY Process Icon Call Service RO / UV Icon Power Icon Indication Bar PURIFICATION PROCESS PROCESS RO/UV ICON CALL SERVICE POWER ICON INDICATION BAR All LEDs will glow for 5 seconds Power ON Puri cation Process Blinks for 6 secs. -
Page 18: Quick Checklist
2. Have you kept the purified water in the tank or too long? Dispense of water and clean the tank. 3. Is it time to change the filter? Call an authorised Eureka Forbes service technician. Less water has been 1. Is the tap water valve closed? Open the tap water valve. -
Page 19: Zero Pressure Pump
ZERO PRESSURE PUMP Your Dr.Aquaguard is equipped with a unique pump having both suction and boosting capabilities with specially designed ZPP and DRS (Dry Run Sensor) Claims. Now, this enables your Dr.Aquaguard to work in the following operating conditions:- • Normal Input Water Pressure – up to 3 bar (max.) •... -
Page 20: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS 1. The Products are warranted against manufacturing defects for a period of twelve (12) months from the date of original purchase. 2. The Customer will notify the Company in writing promptly of any defects noticed and give the Company or its authorized agent adequate opportunity to inspect test and remedy them for which the Customer will deposit the goods at its own expense, if so, required by the Company with the Company's Office/Service Centre along with the original invoice in the city where they are sold. - Page 21 For the purpose of this warranty, the following expressions shall have the following meanings respectively: 1. The 'Goods' shall mean the goods described in the Order Form. 2. The 'Customer' shall mean the original purchaser of goods from the company. 3. The 'Company' shall mean EUREKA FORBES LIMITED. ® ®...
- Page 22 3. If during such servicing it is necessary for the company to replace or repair defective components or parts, the customer shall be required to pay for the same as per the company's prevailing price list. 4. Eureka Forbes limited reserves the right to offer annual maintenance contract/ensure availability of spares only up to 7 years from the date of invoice.
- Page 23 Forbes will be able to guide you. Allow us to become your environmental partner; together we can make the world a Active Copper Cartridge. cleaner place. R00-0122 old logo and new logo are both original Aquaguard products from the house of Eureka Forbes Limited.
