Operating Manual
Product:
VIENNA Air Screen
VIENNA Cold Display
Self contained or remote
Operating and Maintenance instructions
Please read this manual carefully before you start to operate your cooling equipment.
Following the instructions helps to ensure the unit is fully functional at all times.
Warranty claims can only be forwarded if all instructions are strictly
followed!
Advertisement
Table of Contents
Related Manuals for RPI VIENNA Air Screen
Summary of Contents for RPI VIENNA Air Screen
- Page 1 Operating Manual Product: VIENNA Air Screen VIENNA Cold Display Self contained or remote Operating and Maintenance instructions Please read this manual carefully before you start to operate your cooling equipment. Following the instructions helps to ensure the unit is fully functional at all times.
-
Page 2: Table Of Contents
Contents Operation and maintenance Introduction ......................1.1. Welcome ......................1.2. Fundamental Safety Notes ................1.3. Warranty and Liabilities .................... 1.4. Symbols and Notes .................... 1.5. Validity ......................Purpose of use ……....................Proper use of the unit …………..……..............Improper use of the unit .................. -
Page 3: Operation And Maintenance
OPERATING AND MAINTENANCE Introduction 1.1. Welcome With the purchase of this new refrigerating equipment you have decided on a product that combines the highest technical demands with practical service comfort. We recommend that you read these operating and maintenance instructions carefully in order to become familiar with the product quickly. With the proper treatment you will enjoy this appliance for a long time. -
Page 4: Symbols And Notes
VIENNA Closed Display Case “VICD” - Closed on front for assisted service only - Service side with pull out drawer self-contained or remote refrigerated VIENNA Air Screen Displays “VIAS” - Open on front for self serve self-contained or remote refrigerated VIENNA Counter Top Displays... -
Page 5: Purpose Of Use
Purpose of use The Refrigerated Display Cases have been specially developed for mounting in food and dispensing counters. They are suitable for the refrigeration and presentation of foodstuffs and drinks. These refrigerated units are not suitable for chilling foods. Any products to be presented have to be chilled to the temperature required before being placed in the unit. -
Page 6: Fundamental Operating Notes
Fundamental operating notes 6.1. Switching on the appliance The Display case is switched on and off by pressing the STANDBY button (5). Above the buttons there is a digital display of the cooling regulator. This field shows the medium temperature and any errors. -
Page 7: Operating Description
Load Display Case Load the display case with pre-chilled product from the rear doors. You can place the goods on the glass shelves and on the base decks. VIENNA Air Screen models have a deep well with height adjustable base decks. - Page 8 Adjustable shelves The display offers the possibility to adjust the shelves in height and angle (tilt able). This offers you various presentations of the goods. You can adjust the shelves 1 step up and down (± 1”) from the centre position. Remove the glass Before moving the shelf to another position please remove the glass.
-
Page 9: Cleaning And Care
Cleaning and care Following is some advice on maintenance, care, trouble shooting and service for your refrigerated display cases. The interior and the outside of the unit have to be cleaned every day in accordance with hygiene regulations. Only then can you guarantee optimal presentation of the goods. CAUTION: BEFORE YOU START TO CLEAN AND CARE SWITCH OFF THE APPLIANCE AND DISCONNECT IT FROM THE MAINS! -
Page 10: Special Cleaning Hints
8.3. Special cleaning hints Cleaning of the interior and evaporator coil Take out the GN containers or base decks (1) and air plenums (2) and inner tray from the well. First of all remove visible dirt inside the well (bottom) to avoid a blockage of the drain (5 und 6). Open the cover from the evaporator unit (3). - Page 11 Condenser cleaning instructions Remove air grill / louver in front the condenser. Remove the dust from the condenser coil; this can be done with either a brush or a vacuum. Be careful and don’t bend the lamellas ...
-
Page 12: Trouble Shooting
Trouble shooting Before requesting service, please check the following: If the appliance is not working at all please check whether: The power supply is interrupted ..........Self-checking A fuse has blown ............... Self-checking The plug is firmly in the socket ............. Self-checking ... -
Page 13: Dangers
Dangers 10.1. Electrical energy Switch the appliance off immediately upon interruptions in the electrical power supply! Any work carried out on the electrical units or utilities may only be carried out in accordance with electrical regulations by an electrician specialist or by those being instructed and supervised by an electrician specialist. -
Page 14: Wiring Diagram
Wiring diagram Wiring diagram: VICD and VIAS – self contained 115 V / 1 PH / 60 Hz Wiring diagram: VICD and VIAS – remote refrigerated 115 V / 1 PH / 60 Hz Valid from: 11/2011 Technical changes reserved Page 13 Doc.: OM_VIAS &... - Page 15 Wiring diagram: VICD and VIAS – self contained 115/208-230 V / 1 PH / 60 Hz Valid from: 11/2011 Technical changes reserved Page 14 Doc.: OM_VIAS & VICD (10D)
- Page 16 Wiring diagram: VICD and VIAS – self contained 115 V / 1 PH / 60 Hz With rear ventilation Kit including time relay for longer runtime of the fan Wiring diagram: VICD and VIAS – self contained 115/208-230 V / 1 PH / 60 Hz With rear ventilation Kit including time relay for longer runtime of the fan Valid from: 11/2011 Technical changes reserved...
-
Page 17: Declaration Of Conformity
1 - 8 6 6 - 7 2 7 - 0 7 2 1 P a r t s / S e r v i c e d i r e c t : s e r v i c e @r p i i n d u s t r i e s . c o m p a r t s @r p i i n d u s t r i e s .
