- Page 1 LINDR FLOW-THROUGH ENGLISH WATER COOLING Number 007-2020 Valid 2020-01-01 VCH 02236 AS-110-us Green Line...
- Page 3 503 15 Nechanice, Czech Republic mob.: + 420 778 070 276 tel.: +420 495 447 239 e-mail: info@lindr.cz web: www.lindr.cz, www.lindr.eu This manual contains instructions for installation, use and operation of the appliance. This manual is an integral part of the device.
-
Page 4: Table Of Contents
Contents: …............... Introduction …............... Description of the cooler …............... Machine plate General instructions, measures and safety …............... instructions …............... Installation and placement …............... Electrical connection …............... Testing …............... Warranty …............... Description of the cooler …............... 10. Beverage inlets and outlets …............... - Page 5 Symbols and Markings Used in the Manual: WARNING: Not following instructions may cause injury or damage the device. WARNING: Risk of injury by electrical current. NOTE: This symbol indicates information and recommendations for the user. WARNING: The cooling system contains flammable coolant R290 (propane)! ˇ...
-
Page 6: Introduction
1. Introduction: made of stainless steel. The materials used meet strictest hygienic Thank you for purchasing this LINDR standards and guarantee long service product. life of the cooler. 2. Description of the cooler: 3. Product label: The cooler is designed for professional... -
Page 7: Instructions
4. General Instructions, WARNING: Cleaning Measures Safety maintenance of the appliance on the part of Instructions: the user must not be done by unsupervised children. WARNING: Before connecting to main When using the device, follow basic electrical supply, check that the voltage and safety instructions stated... -
Page 8: Installation And Placement
WARNING: Do not place objects that WARNING: To turn the device off could prevent air circulation on top of the completely, unplug the appliance from the cooler. power socket. WARNING: In the event the electrical 5. Instalation and Placement: wiring of the product becomes damaged, summon a trained service technician. - Page 9 V Clearances, mm (inch) Model Rear Right Side Left Side Front AS-110-us 200 (7.87) 200 (7.87) 508 (20) 70 (2.76) (7.87) ˇ...
-
Page 10: Electrical Connection
7. Testing: The product is delivered ready for immediate The device MUST NOT be used or stored use. at ambient temperature lower than 0 °C. The device is designed for use in a normal 8. Warranty: environment, always indoors, protected from The device comes with a warranty in rain or sunlight. -
Page 11: Description Of The Cooler
9. Description of the cooler: Inlet beverage - speed fiting 3/8“ 1 Thermostat (9,5mm) Outlet beverage - speed fiting 2 Main switch 3/8“ (9,5mm) Outlet cold water-speed fiting 3 Pump socket 1/2“ (12,7mm) 4 Product label Pump 5 Power cable 10 Condenser ˇ... -
Page 12: Beverage Inlets And Outlets
10. Beverage inlets and outlets: The beverage inlet and outlet is fitted with a 3/8“ speed fiting (9.5 mm), while the pump outlet is fitted with a 1/2" (12.7 mm) speed fiting. Beverage outlet Beverage inlet Outlet cold water... -
Page 13: Thermostat Placement
11. Thermostat placement: The mechanical thermostat with 1 -7 numerical scale located on the front of the cooler 12. Temperatureand adjustment: The temperature of the cooled beverage is controlled by a mechanical thermostat. The thermostat has a numerical scale of 1-7. Setting the thermostat to 6-7 creates an ice bank (ice accumulation). -
Page 14: Putting Into Operation
Putting into operation: The device requires professional installation by a qualified firm including training of the operator (owner) and operating staff. 1. Interconnect the beverage tubing according to point 14. WARNING: Check the connection of the pump outlet - until it is connected, water will pour out of the pump after when the device turned on. -
Page 15: Interconnecting Beverage Tubing
14. Interconnecting beverege tubing: The figure shows a model example of connection. ˇ... -
Page 16: Pouring Water Into The Tank
15. Pouring water into the tank: 1. Remove the two screws holding the lid. WARNING: Always disconnect the device from power before pouring in water. 2. Remote the lid. - Page 17 3. Pour water all the way up to the overflow, the cooling coils must be submerged. 4. Replace the lid and secure it with screws. ˇ...
-
Page 18: Keg Tapping And Untapping
KEG TAPPING AND UNTAPPING WARNING: Make sure the adapter is clean before tapping the keg! S system keg coupler Procedure for tapping and untapping a keg with an S system keg coupler: 1. Keg tapping:... - Page 19 ˇ...
- Page 20 2. Keg untapping:...
- Page 21 A system keg coupler: ˇ...
- Page 22 Procedure for tapping and untapping a keg with an A system keg coupler: 1. Keg tapping:...
- Page 23 ˇ...
- Page 24 2. Keg untapping:...
-
Page 25: How To Work With Rapid Couplings
How to Work with speed fitings Speed fitings Installation Grasp the speed fiting and insert the hose all the way inside the speed fiting body (ca. 20 mm). The end of the hose must be straight, so that it plugs fully into the coupling. -
Page 26: Environmental Protection
18. Environmental protection: This product must not be disposed of in communal waste. Electrical waste in the Czech Republic is disposed of within the Rema System. In countries other than the Czech Republic, waste sorting is subject to local regulations. Sorted waste enables recycling and reusing used products and packaging materials. -
Page 27: Periodic Checks
21. Periodic check: • 1x a week: check water level in the tank. • 1x a week: check that the lead-in cable is undamaged and that the plug is firmly in the socket. • 1x a week: check that the device is not exposed to radiant heat. •... - Page 28 Warning: Disconnect the device from power before cleaning the condenser!
- Page 29 ˇ...
-
Page 30: Sanitation By Water
23. Sanitation by water (sanitation adapter): Connect the sanitation adapter (not included) to water mains using a hose. WARNING: Maximum water temperature must not exceed 25 °C . NOTE: Sanitation adapter is not included. Can be purchased as an accessory for the cooler. -
Page 31: Table Of Malfunctions
24. Table of defects: MALFUNCTION CAUSE REMOVAL beverage does not flow keg tapped incorrectly check that the keg coupler lever is pushed down the keg is not pressurised pressurise the keg compensator is closed move the compensator lever incorrect thermostat setting turn the thermostat knob beverage cooled to the right towards number 7... -
Page 32: Spare Parts
Do not forget to specify the following: • type of defect • product type • production year • product's serial number (found on the label) Ordering Components. ALWAYS USE ORIGINAL COMPONENTS. The manufacturer or supplier bear no responsibility for non-original components or components not recommended by the manufacturer. -
Page 33: Technical Data
26. Technical data: Card munber VCH 02236 Name AS-110-us Power (Hp) Power (W) Max output (l/hour.) Sustained output.(l/hour.) Temperature difference Δt (°C) Coolant type R290 Voltage 115V 60Hz~1 Input power (W) Current (A) Coling coils 2 x 14 Dimensions (WxDxH mm) 610 x 420 x 475 Net weight (kg) ˇ... -
Page 34: Wiring Diagram
27. Wiring diagram:... -
Page 35: Cooling Diagram
28. Cooling diagram: ˇ...
