Hunter 20501 Parts Manual

Hardware
(Drawn to Scale)
x 2
x 4
x 2
x 2
x 4
x 1
x 11
x 16
Allen
x 1
Wrench
x 16
Balancing
x 1
Kit
x 3
Wire
x 4
Connector
x 3
3" Wood Screw
Flat Washer
Hanger
1.5" Wood Screw
Bracket
Assembly
Decorative Screw
Canopy Screw
Setscrew
Screw, Blade
Iron Armature
Screw, Blade
Assembly
Blade
Assembly
Blade
Grommet
Screw, Switch
Housing Assembly
Switch
Housing
Screw,
Assembly
Machine, 6-32
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model #

Parts List

Asm. Dwg. #
Finish
Item Name Qnty
* Hanging System Kit 1
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
Switch Housing Assembly 1
Decorative Scroll Assembly 1
Hanger Pipe 1
Switch Housing, Upper 1
Blade Iron Set 1
Blade Set 1
Screw, Blade Iron Armature 11
Hardware Kit 1
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1
Decorative Screw 2
Pull Chain Pendant 1
Pull Chain Pendant 1
Bottom Cap 1
Finial 1
Light bulb / Bulb 2
Globe/Shade 1
Hunter Fan Company • 7130 Goodlett Pkwy. #400 • Memphis, TN 38016 • www.hunterfan.com •
20501
99136-01
Bullion Black
Part #
98026-94
99052-01
88762-01
74228-03
87445-01
87647-05
76697-58
63755-05
99136-00-860
07570-01
03111-02
66636-01
66637-01
88861-01
76849-01
77646-03
88719-04
98000-01-971 03-02-2009 • 2009
©
