- Page 1 SPORT ROOF RACK INSTALLATION MANUAL info@afxmotorsports.com CAN AM MAX SKU CAN006-S THIS PRODUCT IS FOR OFF ROAD USE ONLY...
- Page 2 AFX Motorsports. The total liability of seller to user for all damages, losses, and causes of action, if any, shall not exceed the total purchase price paid for the product that gave rise to the claim. AFX Motorsports will warranty only parts provided by AFX Motorsports.
- Page 3 NOTE: Just in case you have the Flat Roof start from step 5. Drill 2 holes on the marks of the OEM plastic roof, in order Use the holes you did in the rst step to align your roof rack on to align the rack with them.
- Page 4 Passenger’s side: Align Bracket at the front part of the roof rack with the perforations, (as it is shown in the image), hold it with a 1/4 x 1/2" screw using the washer and nut provided (Do not tighten)(Repeat this step in the Driver´s Side) Settle the leg over the roof (Only with he Original Roof ), place a washer over the perforations as it is shown in the image, using 1/4 x 1”...
- Page 5 Install rear frame assembly onto rear side rails (as it is shown in the image). Use four 1/4x 1/2” screws with nut. (Do not tighten yet). Now, settle the front part of the roof rack over the front legs, Nuts Rear Roof Rack using a 1/4 x 1"...
- Page 6 Install Front frame Assembly onto front side rails (as it is shown in the image). Use four 1/4 x 1/2” screws with nut (Do not tighten yet). Settle the part at the rear of the Roof Rack over the legs at the 1/4x 1/2 “...
