T-1100/1100XL Quick Start Guide
Version 11.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-1100 and is the answer not in the manual?

Questions and answers

Related Manuals for tufin T-1100

Summary of Contents for tufin T-1100

  • Page 1 T-1100/1100XL Quick Start Guide Version 11.6...

  • Page 2: Table Of Contents

    Setting Up The T-1100 Setting up the Remote Management Module Prerequisites Installing and Configuring TOS Aurora Restoring Factory Defaults Appendix: Installing and Configuring Tufin Orchestration Suite Classic Install TOS Classic Configure SecureTrack Configure SecureChange Copyright 2003-2022, Tufin Software Technologies Ltd.

  • Page 3: Introduction

    Information in this guide applies to both the T-1100 and the T-1100XL. (All references to T-1100 include T-1100XL as well.) The Tufin T-1100 appliance is designed to simplify integration and use of Tufin Orchestration Suite (TOS) by providing a unified hardware and software solution.
  • Page 4 Trademarks 2022 Tufin Technologies Ltd. Tufin, Unified Security Policy, Tufin Orchestration Suite and the Tufin logo are trademarks of Tufin. All other product names mentioned herein are trademarks or registered trademarks of their respective owners. Copyright 2003-2022, Tufin Software Technologies Ltd.

  • Page 5: T-1100 Front And Rear Panels

    T-1100/1100XL Quick Start Guide T-1100 Front and Rear Panels T-1100 Front and Rear Panels These sections describe the different elements in the front and rear panels. Front Panel Item Description VGA port 2 USB 3.0 ports Front panel LEDs and buttons...
  • Page 6 T-1100/1100XL Quick Start Guide T-1100 Front and Rear Panels Item Feature Description Blinking green indicates degraded operation (e.g., power supply nonredundancy, part of system memory mapped out by BIOS). Blinking red indicates one or more non-critical fault conditions. Steady red indicates one or more critical fault conditions.

  • Page 7: Rear Panel

    T-1100/1100XL Quick Start Guide T-1100 Front and Rear Panels Rear Panel Item Description Notes Power supply 1 Power supply 2 Onboard LAN (eth0) Onboard LAN (eth1) Video connector RJ45 serial port 3 USB 3.0 ports RJ45 Remote Management Module (RMM)

  • Page 8: Setting Up The T-1100

    For easier appliance management, we recommend that you also configure the Remote Management Module (RMM) after you connect your appliance to your network and before you install Tufin Orchestration Suite. Using RMM, you can upgrade TufinOS or TOS on the appliance without...

  • Page 9: Setting Up The Remote Management Module

    Setting up the Remote Management Module The remote management module (RMM) or IPMI port in Tufin appliances lets you connect to an administration web interface for the appliance. You can configure RMM by either using BIOS or using SSH or a Console.
  • Page 10 T-1100/1100XL Quick Start Guide Setting up the Remote Management Module 3. In the next screen, go to Setup Menu. 4. Select Server Management and enter the BMC LAN Configuration. Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 11 T-1100/1100XL Quick Start Guide Setting up the Remote Management Module 5. Edit the settings as required. 6. Save settings and reboot the appliance. Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 12 Create a new user or modify settings for an existing User ID. ipmitool user set name <user_id> <username> ipmitool user set password <user_id> ipmitool channel setaccess <channel number> <user id> [callin=on|off] [ipmi=on|off] [link=on|off] [privilege=level] For example: Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 13 HTTPS. Now you can securely connect to the RMM to do remote administration tasks. For more about using the RMM, refer to the Intel® Remote Management Module 4 (Intel® RMM4) User Guide at http://www.intel.com/support/motherboards/server/sb/CS-032371.htm. Copyright 2003-2022, Tufin Software Technologies Ltd.

  • Page 14: Installing And Configuring Tos Aurora

    Installing and Configuring TOS Aurora This topic includes instructions to install and configure Tufin Orchestration Suite (TOS) Aurora 11.6 and later running on TufinOS . You must install the version of TOS Aurora that is found on your appliance before upgrading to any later version of TOS Aurora.
  • Page 15 <MyNetmask> , <MyGateway>, <DNS_IP1>, <DNS_IP2> are the appropriate values for your network. f. Restart the network service. service network restart 3. Installing TOS Aurora a. Run the install command, replacing the parameters: sudo tos install --modules=<MODULE-TYPE> --loadbalancer-ip=<VIP> --services- network=<SERVICE-CIDR> Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 16 EULA and continue until the commands completes. c. Type Exit to leave the CLI. Configure SecureTrack 1. Log in as admin with password admin, and click Login. Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 17 Enter a value for Server DNS name. The DNS server is used for links in email notifications. This can be an IP address in the format 11.22.33.44 or a FQDN in the format https://mydomain.com. Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 18 After you install the pre-loaded TOS Aurora, you can upgrade to a newer version of both TufinOS and TOS Aurora. Confirm the TufinOS and TOS Versions Retrieve the TufinOS an TOS Aurora versions from your appliance. Copyright 2003-2022, Tufin Software Technologies Ltd.
  • Page 19 We recommend that you use RMM to install a newer version of TufinOS on your appliance (see Installing TufinOS via Remote Management Module (RMM) for Gen 3.5 Appliances). Upgrade TOS Aurora To upgrade your version of TOS Aurora, see Upgrade From TOS Aurora. Copyright 2003-2022, Tufin Software Technologies Ltd.

  • Page 20: Restoring Factory Defaults

    Warning! Restoring factory defaults will delete all information on the appliance including database records, backup files and logs. 1. Backup the Tufin Orchestration Suite (TOS) databases (SecureTrack and SecureChange). Aurora only: i. Run this command: # sudo tos backup create You can continue working while the backup is running.
  • Page 21 T-1100/1100XL Quick Start Guide Restoring Factory Defaults a. Visit the Tufin Support Download site (https://portal.tufin.com/aspx/TechnicalDownloads). b. Download the same version of TOS that you received with your appliance. c. Copy it to the /opt partition on your appliance. d. Log onto the appliance command line as tufin-admin with new password that you created.

  • Page 22: Appendix: Installing And Configuring Tufin Orchestration Suite Classic

    Appendix: Installing and Configuring Tufin Orchestration Suite Classic This section includes instructions to install and configure Tufin Orchestration Suite (TOS) Classic 11.6 and later running on TufinOS . If you are installing TOS Classic, you must install the version that is found on your appliance.

  • Page 23: Configure Securetrack

    T-1100/1100XL Quick Start Guide Appendix: Installing and Configuring Tufin Orchestration Suite Classic c. Log in with these credentials (admin/admin) and click Login. Configure SecureTrack After logging into SecureTrack for the first time, the SecureTrack Setup Wizard opens. The wizard includes the following pages: Login: For security reasons, change the admin password.
  • Page 24 T-1100/1100XL Quick Start Guide Appendix: Installing and Configuring Tufin Orchestration Suite Classic Password: Type system for the Old Password of the TufinOS root user, and change the password. Networking (optional): Configure networking (DNS settings can also be configured later from SecureTrack's web interface) Time: Configure date and time settings.
  • Page 25 Username and password cannot be changed in this page. Notifications: Configure the SMTP settings for SecureTrack email notifications. License: Installing a license is optional at this stage. To receive a license, please contact your Tufin reseller. Copyright 2003-2022, Tufin Software Technologies Ltd.

  • Page 26: Configure Securechange

    T-1100/1100XL Quick Start Guide Appendix: Installing and Configuring Tufin Orchestration Suite Classic Finish: Click Save to complete the installation wizard: Configure SecureChange 1. Configure SecureChange for the first time: If SecureTrack is disabled, and you have not gone through the SecureTrack Setup Wizard, use standard Linux commands in TufinOS to...
  • Page 27 Retrieve the TufinOS an TOS Classic versions from your appliance. Run these commands to confirm the TufinOS and TOS Classic versions on your appliance: # sudo tos version Tufin Orchestration Suite version: 21.2 HF3 build 297281 (final) TufinOS Linux release 3.81 build 289282 (Final) Check for Updates...
