- Page 1 2010 2011 2012 2013 2014 2015 2016 2017 2018 2019 2020 2021 2020 2019 2018 2017 2016 2015 2014 2013 2012 2011 WARNING 2010 Read this manual. Serious injury or death can result if safety instructions are not followed.
-
Page 2: Table Of Contents
Table of Contents General Warnings and Rules ................3 Hazard Signal Word Definitions ................4 Controls and Features Identification ..............5, 6 Assembly Instructions ................ 6, 7, 8, 9, 10 Operation Instructions ............... 11, 12, 13,14 Maintenance and Storage .................. 15 Troubleshooting .................... - Page 3 GENERAL WARNINGS READ and UNDERSTAND this manual completely before using 32-Ton Log Splitter. Operator must read and understand all safety and warning information, operating instructions maintenance and storage instructions before operating this equipment. Failure to properly operate and maintain the log splitter could result in serious injury to the operator or bystanders. Operation Warnings l Do not at any time carry passengers, sit or stand on the log splitter.
-
Page 4: Hazard Signal Word Definitions
Hazard Signal Word Definitions This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER indicates an imminently hazardous DANGER situation which, if not avoided, will result in death or serious injury. -
Page 5: Controls And Features Identification
Controls and Features Identification Read this owner’s manual before operating the equipment. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. 1) 2” Coupler – Attaches the log splitter to the 2” ball. 2) Hydraulic Cylinder –... -
Page 6: Assembly Instructions
WARNING Read and follow all instructions for assembly and operation. Failure to properly assemble this equipment could result in serious injury to the user or bystanders or cause equipment damage. Engine Shipped Without Oil. Before starting the engine, fill with SAE 10W-30 motor oil. See engine manual for engine oil capacity. - Page 7 WARNING: After the slotted nut is tightened, turn back 1/4 circle to make sure the wheel can rotate smoothly and freely. Failure to turn the slotted nut back will cause the wheel not to operate correctly STEP 2: Attach Tow Bar to the Hydraulic Reservoir 1.
- Page 8 STEP 4: Attach Engine to Mounting Plate 1. Position the engine (#33) to the mounting plate, put the hex bolt M8x40 (#46) through the bottom of the plate. Place flat washer Ø8 (#36), lock washer Ø8 (#32) and tighten with the nylon lock nut M8 (#31).
- Page 9 STEP 5: Attach Hydraulic Hose 1. Remove the connector and the hose plugs. Both plugs may be discarded. 2. Put the O ring Ø11x2.5 (#19) on the gear pump connector (#23), and attach the hydraulic hose (valve-pump) (#16) to the gear pump connector (#23). 3.
- Page 10 STEP 7: Add Engine Oil 1. Make sure the log splitter is on a level surface. 2. Remove oil fill cap/dipstick to add oil. 3. Refer to the separate owner’s engine manual for the amount needed of SAE10W-30 engine oil; replace oil fill cap/dipstick.
-
Page 11: Operation Instructions
5. Start engine and use the control lever to extend and retract wedge several times to remove air from the lines. 6. With the wedge retracted, check hydraulic oil level again and fill if necessary. WARNING DO NOT remove the hydraulic oil fill cap when the engine is running or hot. Hot oil can escape, causing severe burns. - Page 12 TIRE WARNING DO NOT over inflate tyres. Serious injury can result if tyres explode. DO NOT tow the log splitter if the tyres are worn or will not hold air. DO NOT exceed the maximum 45 MPH towing speed. 5. Refer to the vehicle owner’s manual for proper safety and towing instructions. TOWING WARNING Serious injury or death can occur if towing safety rules are not followed.
- Page 13 NOTE: HORIZONAL position is used for lighter logs that can easily be loaded onto the beam. The VERTICAL position is used for either light logs or heavy logs that are difficult to load onto the beam. Back injury can result from lifting logs onto the log splitter if proper lifting techniques are not used.
- Page 14 Operation Instructions - 14 -...
-
Page 15: Maintenance And Storage
Maintenance and Storage WARNING Improper maintenance and storage of the log splitter may void your warranty. MAINTENANCE • Before performing maintenance, the log splitter must be placed in maintenance mode. Turn off the engine and move the control lever forward and backwards to relieve the hydraulic pressure. -
Page 16: Troubleshooting
Troubleshooting Problem Cylinder rod will not move SOLUTION: A,D,E,H,J Slow cylinder rod speed when extending or SOLUTION: A,B,C,H,I,K,L retracting Wood will not split or splits extremely slowly SOLUTION: A,B,C,F,I,K Engine bogs down during splitting SOLUTION: G,L Engine stalls under low load condition SOLUTION: D,E,L,M Problem when starting the engine SOLUTION: N... -
Page 17: Specifications
Specifications Ram Force ....................32-Ton Cycle Time ....................13.5 Sec Wedge Size ................... 9” Harden Steel Gear Pump..............2-Stage 16 Gallons/Minute Hydraulic Oil ......... AW32, AW46, ISO32 or Universal Hydraulic Oil Amount of Hydraulic Fluid ................8Gallon Max. Log Length ....................26” Hydraulic Cylinder ................4-1/2”... -
Page 18: Parts Drawing & Parts List
Parts Drawing & Parts List - 18 -... - Page 19 Parts Drawing & Parts List Ref# Drawing No. Description 9101-05010-DX8.8 Hex Bolt M5x10 9121-06010-FH Inner Hex Cone Point Set Screw M6x10 LSP30B-03000 Cylinder LSP25-00001-DX Metal Tube LSP25-00005-DX R Pin LSP25-00004-DX Cylinder Pin LSP30M-00017 Hydraulic Hose (valve-external filter) LSP25-06000-DX Connector LSA22-09000 Control Valve LSP25-17000-DX Combination Connector...
- Page 20 Ref# Drawing No. Description LSP25-00009-DX Axle Cap LSP30-00006 Rubber Washer LSP25-10008-FH Steel Wire Snap Ring for Shaft LSP30-03000 Hydraulic Reservoir 9301-06000-DX Flat Washer Ø6 9101-08040-DX8.8 Hex Bolt M8x40 9101-06020-DX8.8 Hex Bolt M6x20 LSP30-15000-DX Filter Fixed Plate LSP25-09000 Oil Return Filter LSP25-00007-DX Connector LSP25-00011-DG...
-
Page 21: Limited Warranty
Limited Warranty Warranty For 3 years from the date of purchase YTL International will replace or repair defects in material and workmanship for the original purchaser of the log splitter. For 2 years the engine warranty is covered per the engine manufactures warranty. For 1 year from date of purchase YTL International will repair or replace hydraulic system components.
