USER MANUAL
AFTER SALES SUPPORT:
WWW.SPTOOLS.COM
IMPORTANT
ALL PERSONS WHO ARE TO USE THIS EQUIPMENT MUST THOROUGHLY READ
AND UNDERSTAND THIS INSTRUCTION MANUAL PRIOR TO OPERATION.
SP62011
DIGITAL
AUTOMOTIVE
MULTIMETER
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO
MANUAL FOR FUTURE
NOTE: Proof of purchase must be retained by
the customer as it will be required in the
event of a claim under warranty.
AUSTRALIA: Visit the website's contact page to get in
touch with your local service department.
INTERNATIONAL: Use the county selector to get in touch
with your service department in your country or region.
REFERENCE
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SP tools SP62011
Summary of Contents for SP tools SP62011
- Page 1 USER MANUAL SP62011 DIGITAL AUTOMOTIVE MULTIMETER RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE NOTE: Proof of purchase must be retained by the customer as it will be required in the event of a claim under warranty.
- Page 2 CONTENTS Safety Information Symbols Controls & Jacks Symbols & Annunciators Specifications Tables / Graphs Operation Instructions Replacing battery / fuse Limited Warranty INTRODUCTUCTION SAFETY INFORMATION The following safety information must be observed to insure maximum personal safety during the operation at this meter: ...
- Page 3 SYMBOLS This symbol adjacent to another symbol, terminal or operating device indicates that the operator must refer to an explanation in the Operating Instructions to avoid personal injury or damage to the meter. This WARNING symbol indicates a potentially hazardous situation, which if not avoided, could result in death or serious injury.
- Page 4 SYMBOLS AND ANNUNCIATORS Continuity Low Battery Diode DATA HOLD Data Hold AUTO Auto Ranging Alternating Current or Voltage Direct Current or Voltage SPECIFICATIONS The instrument complies with: IEC 1010-1 EN61010-1. Insulation: Class2, Double insulation. Overvoltage category: CATII 1000V. Display: 4000 counts LCD display with function indication. Polarity: Automatic, (-) negative polarity indication.
- Page 5 RPM (Tach) Range Resolution Accuracy 600~400 1 RPM RPM 4 600~120 10 RPM +2 % of rdg + 4 dgts (X10 RPM) 300~400 1 RPM RPM 2 300~600 10 RPM (X10 RPM) Effect Reading: >600 RPM Overload protection: 250V dc or ac rms. DEWLL ANGLE Cylind Range...
- Page 6 AC Voltage (Auto-ranging except 400mV) Range Resolution Accuracy 400.0m 0.1mV +1.5%of rdg + 30 dgts 4.000V +1.0% of rdg + 3 dgts 40.00V 10mV +1.5% of rdg + 3 dgts 400.0V 100mV 700V +2.0% of rdg + 4 dgts Input Impedance: 10MΩ. Frequency Range:50 to 400Hz Maximum Input: 1000V dc or 700V ac rms.
- Page 7 Capacitance (Auto-ranging) Range Resoluti Accuracy 40.00nF 10pF +5.0% of rdg + 7 dgts 400.0nF 0.1nF +3.0% of rdg 4.000uF 1nF + 5 dgts 40.00uF 10nF 100.0uF 0.1uF +5.0% of rdg + 5 dgts Input Protection: 250V dc or 250V ac rms. Frequency (Auto-ranging) Range Resolution...
- Page 8 Temperature: Range Resolutio Accuracy -20 o C~+760 o C 1 o C +3% of rdg +3dgts -4 o F~+1400 o F 1 o F (Meter only, probe accuracy included) Sensor: Type K Thermocouple Diode Test Test Resoluti Accuracy current 0.3mA 1 mV +10% of rdg typical...
- Page 9 Press the DATA HOLD button to return to normal operation. If Press the BACKLIGHT button 2 seconds the display light ON Press BACKLIGHT button2 seconds again to exit the light mode. RELATIVE BUTTON The relative measurement feature allows you to make measurements relative to a stored reference value.
- Page 10 Resistance or Diode or Continuity or Capacitance Measurements WARNING: To avoid electric shock, disconnect power to the unit under test and discharge all capacitors before taking any resistance or capacitance measurements. 1. Insert the black test lead banana plug into the negative COM jack and the red test lead banana plug into the positive Ω...
- Page 11 Pulse Width Measurements 1. Insert the black test lead banana plug into the negative COM jack and the red test lead banana plug into the positive + jack. 2. Turn the rotary switch to the Pulse Width position. 3. Connect the back test probe to ground and connect the red test probe to the signal wire that connects to the component to be measured Note: the applied time for most fuel injectors is displayed on the negative (-) slope RPM (TACH) Measurements...
- Page 12 REPLACING THE BATTERY WARNING: To avoid electric shock, disconnect the test leads from any source of voltage before removing the battery door. 1. When the batteries become exhausted or drop below the operating voltage, “BAT” will appear in the right-hand side of the LCD display. The battery should be replaced. 2.
- Page 13 To the extent permitted by law and subject to this Limited Warranty, and as part of the terms of the sale of the equipment or part thereof: SP Tools shall not be liable for any form of loss, damage, cost, injury or harm of any kind (whether direct, indirect, special or consequential) howsoever arising from the use or supply of the equipment to the purchaser.
