6.1.2 LEDs

The Zone Controller status indicator LEDs display conditions as tabled below:

Table 2 Description of Zone Controller LEDs

Condition
Alarm
Normal
Battery Fault
Battery not Present
AC not Present
Ground Fault
Input Open Circuit
Weak-link Trouble
CPU(WIO) Off line
i
Note:
FIRE ALARM CONTROL PANEL

Figure 31 Trouble Condition and Location

6.1.3 Buzzer

The buzzer is activated by any of the following:
Alarm: steady
Supervisory: fast rate
Trouble: slow rate
28
Indication
Alarm
AC
Trouble
Trouble
Trouble
Trouble
Trouble
Trouble
Trouble
Any WIO trouble condition and location will be identified at the Zone Controller
and the specific Zone Controller in trouble (and its location) at the Fire Alarm
Control Panel.
