POWER REQUIREMENTS

Utilizes standard 9V alkaline battery (not included). NOTE: Input jack
activates battery. To conserve energy, unplug when not in use.
Power Consumption: approx. 30mA.
•USE DC POWER SUPPLY ONLY!
unit and void warranty. DC Power Supply Specifications:
-9V DC regulated or unregulated, 100mA minimum;
-2.1mm female plug, center negative (-).
Optional factory power supplies are available: Tech 21 Model
#
DC9. Also operable via previous models:
WARNINGS:
• Attempting to repair unit is not recommended and may void warranty.
• Missing or altered serial numbers automatically void warranty. For your own
protection: be sure serial number labels on the unit's back plate and exterior
box are intact, and return your warranty registration card.
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE
REQUIRED. Manufacturer warrants unit to be free from defects in materials
and workmanship for one (1) year from date of purchase to the original pur-
chaser and is not transferable. This warranty does not include damage resulting
from accident, misuse, abuse, alteration, or incorrect current or voltage. If unit
becomes defective within warranty period, Tech 21 will repair or replace it
free of charge. After expiration, Tech 21 will repair defective unit for a fee.
ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return
Authorization Number. Manufacturer will not accept packages without
prior authorization, pre-paid freight (UPS preferred) and proper insurance.
FOR PERSONAL ASSISTANCE & SERVICE:
Contact Tech 21 weekdays from 9:00 AM to 5:00 PM, EST.
Hand-built in the U.S.A. using high-quality compo-
nents sourced domestically and around the globe.
T: 973-777-6996 • F: 973-777-9899
E: info@tech21nyc.com • W: tech21nyc.com
©2021 Tech 21 USA, Inc.
Failure to do so may damage the
#
#
DC2 and
DC4.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SansAmp Geddy Lee MP40 Limited Edition and is the answer not in the manual?

Questions and answers

Summary of Contents for Tech 21 SansAmp Geddy Lee MP40 Limited Edition

  • Page 1 If unit becomes defective within warranty period, Tech 21 will repair or replace it free of charge. After expiration, Tech 21 will repair defective unit for a fee. ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return Authorization Number.
  • Page 2 SansAmp continues to main- SansAmp RBI and/or SansAmp RPM. After the R40 tour, Geddy wanted to streamline his gear for new projects and partnered with Tech 21 to design a tain its reputation as the industry standard.
  • Page 3 APPLICATIONS SIGNAL LEVEL TO INPUT WITH A BASS AMP RIG: The MP40 SansAmp is designed to accommodate instrument level signals to the -As a Stomp Box: Run the 1/4” Output into the front input of an amp Input, such as the output of a guitar, the output of (other) distortion pedals, etc. or incorporate into your pedalboard chain.
  • Page 4 MASTER GUIDE TO CONTROLS Controls the overall volume. Adjusts the output level without altering any of The Geddy Lee MP40 Limited Edition Signature SansAmp has two separate the tonal characteristics. internal pre-amps that run in parallel and are blended via the Mix control. For recording applications, we recommend setting at least halfway DRIVE SECTION (12 o’clock).
  • Page 5 NOTEWORTHY NOTES 1) The MP40 SansAmp is an interactive tool. It will react differ- ently to various signal levels, as well as your individual touch. For instance, a hotter signal and a heavy hand will increase the gain structure and result in more overdrive.
  • Page 7 Names of sample settings are intended for descriptive purposes only and should not be construed as an endorsement or affiliation with the companies, products, artists or songs named, except, of course, Geddy Lee.
