POWER REQUIREMENTS
Utilizes standard 9V alkaline battery (not included). NOTE: Input jack
•
activates battery. To conserve energy, unplug when not in use.
Power Consumption: approx. 21mA.
•USE DC POWER SUPPLY ONLY!
unit and void warranty. DC Power Supply Specifications:
-9V DC regulated or unregulated, 100mA minimum;
-2.1mm female plug, center negative (-).
Optional factory power supplies are available: Tech 21 Model
#
DC9. Also operable via previous models:
WARNINGS:
• Attempting to repair unit is not recommended and may void warranty.
• Missing or altered serial numbers automatically void warranty. For your own
protection: be sure serial number labels on the unit's back plate and exterior
box are intact, and return your warranty registration card.
ONE YEAR LIMITED WARRANTY. PROOF OF PURCHASE
REQUIRED. Manufacturer warrants unit to be free from defects in materials
and workmanship for one (1) year from date of purchase to the original pur-
chaser and is not transferable. This warranty does not include damage resulting
from accident, misuse, abuse, alteration, or incorrect current or voltage. If unit
becomes defective within warranty period, Tech 21 will repair or replace it
free of charge. After expiration, Tech 21 will repair defective unit for a fee.
ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return
Authorization Number. Manufacturer will not accept packages without
prior authorization, pre-paid freight (UPS preferred) and proper insurance.
FOR PERSONAL ASSISTANCE & SERVICE:
Contact Tech 21 weekdays from 9:00 AM to 5:00 PM, EST.
Hand-built in the U.S.A. using high-quality compo-
nents sourced domestically and around the globe.
T: 973-777-6996 • F: 973-777-9899
E: info@tech21nyc.com • W: tech21nyc.com
©2019 Tech 21 USA, Inc.
Failure to do so may damage the
#
#
DC2 and
DC4.
Advertisement
Table of Contents
Related Manuals for Tech 21 SansAmp YYZ
Summary of Contents for Tech 21 SansAmp YYZ
- Page 1 If unit becomes defective within warranty period, Tech 21 will repair or replace it free of charge. After expiration, Tech 21 will repair defective unit for a fee. ALL REPAIRS for residents of U.S. and Canada: Call Tech 21 for Return Authorization Number.
- Page 2 With each Tech 21 product, the controls are designed to give you the freedom and opportunity to explore, create, build and rebuild your sound. It is our hope that the SansAmp YYZ will be a useful tool for stimulating your creativity and, ultimately, providing the inspiration to play your best.
- Page 3 TO DRIVE A POWER AMP TURN (SansAmp YYZ) ON FIRST. TURN OFF LAST. Run the 1/4” Output of SansAmp YYZ into the input of a power amp and To avoid unwanted and potentially speaker-damaging “pops” when connecting adjust your stage volume with the Level control of the SansAmp YYZ.
- Page 4 PLACEMENT ORDER OF OTHER EFFECTS HIGH and LOW For best results, plug your instrument directly into the SansAmp YYZ. This will These active tone controls cut or boost ± 12dB from unity gain at 12 o’clock. preserve the interactive nature of the unit. When incorporating into a pedal- High is 3.2kHz.
- Page 5 EQ settings on SansAmp YYZ to achieve your desired sound. You need not be discour- aged or suspect something is wrong with the unit. If you’ve got your sound, you’ve simply found the right balance to complement your particular amp.
- Page 7 Names of sample settings are intended for descriptive purposes only and should not be construed as an endorsement or affiliation with the companies, products, artists or songs named, except, of course, Geddy Lee.
