Contents in this document may change without prior notice.
Please obtain the delivery specification for the latest design.
EM Series Gesture Model
7"Wide Windows CE Embedded
Panel Computer
EMG7
Model: EMG7-W207A8-0024-x11-01
Product Specification
Seedsware Corporation
http://www.seedsware.co.jp/global/
-1-
12A4A2-00007E-8
Advertisement
Table of Contents
Related Manuals for Seedsware EMG Series
Summary of Contents for Seedsware EMG Series
- Page 1 Contents in this document may change without prior notice. Please obtain the delivery specification for the latest design. EM Series Gesture Model 7”Wide Windows CE Embedded Panel Computer EMG7 Model: EMG7-W207A8-0024-x11-01 Product Specification Seedsware Corporation http://www.seedsware.co.jp/global/ 12A4A2-00007E-8...
-
Page 2: Table Of Contents
Table of Contents Summary ............................... 3 Product Model ............................3 Packaged Contents ..........................3 Specification ............................4 4-1 Functional specification ........................4 4-2 Display Specifications ........................5 4-3 Touch Screen Specification ......................5 4-4 General Specification ........................5 4-5 Environmental Specification ......................6 4-6 Installation Specification ........................ -
Page 3: Summary
Summary This specification describes the panel computer with Windows Embedded Compact7. The panel computer will be referred to as EMG7 hereinafter. Product Model Specification Model 7” wide Panel computer EMG7-W207A8-0024-011-01 7” wide Panel computer with Indusoft EMG7-W207A8-0024-111-01 Packaged Contents The following items are included in the package: •... -
Page 4: Specification
Specification 4-1 Functional specification Item Specifications NXP i.MX535 1GHz DDR3-SDRAM 512MB NAND Flash 512MB Battery Backup SRAM 512KB Microsoft® Windows Embedded Compact7 Serial RS232C (COM1)：x 1 (5-pin connector) Ethernet 10BASE-T/100BASE-TX：x 1 SD Card * SD/SDHC card slot : x 1 USB2.0 : x 2 (TYPE-A connector) USB Host * USB devices that can be used : keyboard, mouse (HID Class),... -
Page 5: Display Specifications
4-2 Display Specifications Item Specifications Type 7-inch Wide TFT LCD Resolution 800(W) X 480(H) Color 65,536 colors Display Backlight LED (not replaceable) Brightness 310 cd/m Backlight brightness adjustment* Adjustable in 16 levels Backlight life * 70,000 hours average 4 levels of adjustment is possible by a EMG tool. Time until brightness declines by 50% from the initial value at maximum brightness in ambient temperature of 25℃. -
Page 6: Environmental Specification
4-5 Environmental Specification Item Specifications Ambient operating temperature 0℃ to 55℃ (Inside cabinet and display side) Ambient storage temperature -10℃ to +60℃ 10%RH to 85%RH Ambient operating humidity (non-condensing. Wet-bulb temperature is 39 ℃ or less) 10%RH to 85%RH Ambient storage humidity (non-condensing. -
Page 7: Names Of Parts
4-7 Names of Parts 4-7-1 Front Status LED The status LED displays the state of the EMG by the LED color shown below: LED State EMG State Power not applied Amber, steady OS starting Green, steady Normal operating state Backlight off Green, blinking (Normal Operation) 4-7-2 Back... -
Page 8: Right
4-7-3 Right SD Card Slot USB Device Audio Interface (LINE OUT) Audio Interface (MIC IN) 4-7-4 Top Mounting Holes 4-7-5 Bottom Power Input Ethernet USB Host Serial Port (COM1） Mounting Holes 12A4A2-00007E-8... -
Page 9: External Interface
4-8 External Interface 4-8-1 SD Card Slot Connector : SD / SDHC memory card (Push-in/push-out method) Corresponding media : SD/SDHC memory card Maximum capacity : 32GB 4-8-2 Serial Port (COM 1) Serial port : RS232C Connector : Euro terminal connector (<Tyco Electronics> 284539-5) Recommended cable connector : SWCN-01-05(<Tyco Electronics>284510-5) *Included as accessory. -
Page 10: Usb Host Port
4-8-4 USB Host Port Interface : USB2.0 Number of Ports Connector : Type-A connector Maximum supply current: 0.5A / Port PIN No. Signal Schematic (All ports common) USB_VCC 4-8-5 USB Device Port Interface : USB2.0 Connector : Type-B Mini connector PIN No. -
Page 11: Audio Interface (Line Out)
4-8-6 Audio Interface (LINE OUT) Interface : LINE OUT (Stereo) : φ3.5 Stereo JACK Connector Maximum output level : 1Vrms Use built-in amplifier when connecting to speakers. PIN No. Signal Schematic Lineout R Lineout L 4-8-7 Audio Interface (MIC IN) Interface : MIC IN (Mono) : φ3.5 Stereo JACK... -
Page 12: Software Specification
4-9 Software Specification The EMG7 is installed with Windows® Embedded Compact 7. Specification for Windows ®Embedded Compact 7 of Microsoft ® will follow that of Microsoft ®. 4-9-1 Application Software Development Environment Below tools can be used for application software development. ・Microsoft®... -
Page 13: Installation
Installation 5-1 Installing Condition • When mounting the EMG7 to panels, be sure to have enough room for inserting and removing SD cards, cables, and mounting brackets. • Be sure that the ambient operation temperature (0℃ to 55℃) and the ambient humidity (10%RH to 85%RH. Wet-bulb temperature is 39 ℃... -
Page 14: Mounting
5-2 Mounting 5-2-1 Panel Mounting The EMG7 may be mounted in panels of thickness 1.0mm to 5.0mm Panel cut dimension is as shown below: + 0 . 5 183.5 4-R3以 下 Under 4-R3 The material of the mounting panel, please use the metal. Be recommended panel thickness range, depending on material and size, may not maintain the strength when an impact is applied. -
Page 15: Mounting To A Vesa Arm
5-2-2 Mounting to a VESA Arm EM can be installed on a commercially available Video Electronics Standards Association (VESA) MIS-D arm, stand, or apparatus that is listed to comply with the UL1678 standard. Refer to manual of arm or stand for installation procedures. Mounting hole dimension is as below 75mm Use M4 screws to mount. -
Page 16: Compatible Standards
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference at their own expense. Changes or modifications to this unit that are not expressly approved by Seedsware could void the user’s authority to operate the equipment. -
Page 17: List Of Option
List of Option ■ Mounting brackets Model Description IS-TK-01 4pcs ■ Gasket Model Description SWPK-7W-01 1 pc ■ Protection sheet Model Description SWCA-7WS00-001 Package of 3pcs ■ Batteries Model Description SWBT-01 1 pc ■ Connector Model Description SWCN-01-03 Power connector 3Pin 1 pcs SWCN-01-05 Serial (COM1) 5Pin 1 pcs -17-... -
Page 18: Warranty
Any malfunctions, defects, and/or damages caused by associated equipment and/or usage of inappropriate consumables and media. If the product is repaired, remodeled, modified, or disassembled by a party other than Seedsware If the product cannot be identified by a serial number. -
Page 19: Others
By Phone +1-630-832-0438 (Business Hours: 9:00a.m. ~5:45p.m. CT) By E-mail sales@uscoamerica.com www.seedsware.co.jp/global/support/faq/ Microsoft®, Windows® Embedded Compact7, Windows Mobile Device Center®, Visual Studio.NET 2008®, are registered trademarks of Microsoft Corporation in the United States and other countries. Edition October, 2016 USCO America Inc. - Page 20 寸法許容差 改訂日 改 訂 内 容 ページ 担当 TOLERANCE DATE DESCRIPTION PAGE DESIGNED 呼び寸法 Nominal Dimensions 新規図面登録 183.5 2016,09,01 － S.Yoshimoto L≦3 ±0.4 New Diagram Registration ±0.48 3＜L≦6 ±0.58 6＜L≦10 10＜L≦18 ±0.7 18＜L≦30 ±0.84 ±1.0 30＜L≦50 50＜L≦80 ±1.2 80＜L≦120 ±1.4 NOTES 120＜L≦180 ±1.6...
