- Page 1 Contents in this document may change without prior notice. Please obtain the delivery specification for the latest design. TM Series LCD Touchscreen Monitor Panel Mount Type Product Specification 7” Wide TMG-W207-1211-01 Seedsware Corporation http://www.seedsware.co.jp/global/ 13A4A2-00055E-3...
-
Page 2: Table Of Contents
Table of Contents 1． Summary ................2 2． Model ................2 3． Items Included in Package ............2 4． Specifications ..............3 4-1 Function Specification............3 4-2 Touchpanel Specification ............3 4-3 General Specification ............3 4-4 Environmental Specification ............4 4-5 Installation Specification ............ -
Page 3: 1．Summary
1．Summary This specification describes panel mounting type 7”W Touchscreen Monitor. This monitor will be referred to as TM hereinafter. 2．Model ■Projected Capacitive Type Touchscreen TMG-W207-1211-01 3．Items Included in Package The following items are included in the package: ・TM 1unit ・Mounting Brackets 1set (4pcs) ・Waterproof Gasket 1pc (preinstalled to unit) -
Page 4: 4．Specifications
4．Specifications Function Specification Items Specifications Method TFT Active Matrix Method Resolution 800(W)x480(H) pixels WVGA Display Area 152.4mm(W)×91.44mm(H) Pixel Pitch 0.0635mm(W)×0.1905mm(H) Color App. 260K colors LCD Panel Vertical View Angle Horizontal (Typ.) From 12 o’clock direction (Gray Inversion) Direction Brightness (Typ.) 310 cd/m Backlight ※... -
Page 5: Environmental Specification
Environmental Specification Item Specification Ambient Operating Temperature 0℃ to 50℃ (Inside cabinet and Display side) Ambient Storage Temperature -10℃ to +60℃ Ambient Operating Humidity 10%RH to 85%RH (Non-condensing, Wet bulb temperature is 39℃or less) Ambient Storage Humidity 10%RH to 85%RH (Non-condensing, Wet bulb temperature is 39℃or less) Dust Prohibited... -
Page 6: Name Of Each Parts And Their Functions
Name of Each Parts and Their Functions Name Function Displays power of monitor and video input signal status Green: Power ON with input signal Status LED Red: Power ON without input signal Unlit: Power OFF Power ON/OFF Dial Switch OSD (On Screen Display) operation DC IN Input power (12V DC) Video Input (DVI-i) -
Page 7: 5．Interface Connectors (Ports)
5．Interface Connectors (Ports) DVI (Digital Video Input) Interface: DVI 1.0 Connector: DVI-D Female Pin No Signal Pin No Signal Pin No Signal DATA2- DATA2+ CLKa+ DDC 5V CLKa- Analog RED DVI_DDC_SCL Analog GREEN DVI_DDC_SDA DATA0- Analog BLUE DATA0+ Analog H-Sync DATA1- Analog GND DATA1+... -
Page 8: 6．Main Functions
6．Main Functions Multi-Scanning Automatically enlarges or shrinks images to match the input and LCD display resolution. However, because it will be processed according to the resolutions, there are possibilities of deformation of images and/or blurring of characters. OSD Function Input and output image adjustment can be done with the OSD (On Screen Display). Setting will be memorized even after power is turned off and will not change unless done so intentionally. -
Page 9: 7．Installation
7．Installation Mounting Conditions ・ When mounting the TM to panels, be sure to have enough room for inserting and removing OSD Switch, cables, and mounting brackets. ・ Be sure that the ambient operation temperature (0℃ to 50℃) and the ambient humidity (10%RH to 85%RH. Wet-bulb temperature is 39 ℃... -
Page 10: How To Mount
How to Mount 7-2-1 Installng to Panels Panel thickness shall be 1.0mm to 1.6mm Panel cut-out dimension is as shown in below diagram. Panel Opening Dimensions 183.5 + 0 . 5 4-R3以 下 The material of the mounting panel, please use the metal. Be recommended panel thickness range, depending on material and size, may not maintain the strength when an impact is applied. -
Page 11: Attaching To "Vesa" Standard Arms
Attaching to “VESA” Standard Arms 7-2-2 TM can be installed on a commercially available Video Electronics Standards Association (VESA) MIS-D arm, stand, or apparatus that is listed to comply with the UL1678 standard. Please refer to each arm or stand manual for attaching directions. Dimensions of the installation holes are as shown in below diagram. -
Page 12: 8．Compatible Standards
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference at their own expense. Changes or modifications to this unit that are not expressly approved by Seedsware could void the user’s authority to operate the equipment. -
Page 13: 9．Warranty
Any malfunctions, defects, and/or damages caused by associated equipment and/or usage of inappropriate consumables and media. If the product is repaired, remodeled, modified, or disassembled by a party other than Seedsware If the product cannot be identified by a serial number. -
Page 14: 11．Others
+1-630-832-0438 (Business Hours 9:00a.m.~5:45p.m.) By E-mail sales@uscoamerica.com www.seedsware.co.jp/global/support/faq/ Microsoft®, Windows® 7, Windows® 8, and Microsoft® 10 are trademarks and registered trademarks of Microsoft Corporation USA in the United States and other countries. Other company and/or product names listed herein are also trademarks and/or registered trademarks. - Page 15 寸法許容差 改訂日 改 訂 内 容 ページ 担当 TOLERANCE DATE DESCRIPTION PAGE DESIGNED 呼び寸法 Nominal Dimensions 新規図面登録 183.5 2016,10,03 － S.Yoshimoto L≦3 ±0.4 New Diagram Registration ±0.48 3＜L≦6 ±0.58 6＜L≦10 10＜L≦18 ±0.7 18＜L≦30 ±0.84 ±1.0 30＜L≦50 50＜L≦80 ±1.2 80＜L≦120 ±1.4 120＜L≦180 ±1.6 NOTES...
