Walker Magnetics IMI Smart-D Series Operation Manual

Microprocessor controlled chuck control
Table of Contents

Advertisement

Quick Links

P.O. #:
NEVER ATTEMPT TO OPERATE THIS CONTROL UNTIL YOU
HAVE READ AND UNDERSTAND THIS OPERATOR'S MANUAL
CONTENTS
1 INTRODUCTION ............................................................................................................................................................................... 1-1
2 SAFETY INSTRUCTIONS ................................................................................................................................................................ 2-1
2.1 GENERAL SAFETY RULES ................................................................................................................................................... 2-1
2.2 RECOGNIZE SAFETY INFORMATION .................................................................................................................................. 2-2
2.2.1 Ways to Avoid a Reduction of Holding Capacity ............................................................................................................. 2-2
2.3 ADDITIONAL WARNINGS ...................................................................................................................................................... 2-3
2.4 DESIGNATED PERSON ......................................................................................................................................................... 2-3
3 INSTALLATION INSTRUCTIONS ..................................................................................................................................................... 3-1
3.1 MOUNTING THE CHUCK CONTROL & CONNECTING ELECTRICAL POWER .................................................................. 3-1
3.1.1 Optional Remote Unit...................................................................................................................................................... 3-1
3.1.2 Main Chuck Control Unit ................................................................................................................................................. 3-1
3.1.3 Connecting the Chuck..................................................................................................................................................... 3-2
3.1.4 Connecting the AC Input voltage .................................................................................................................................... 3-2
3.1.5 575 Volt Controllers ........................................................................................................................................................ 3-2
3.1.6 Transformer Wiring Diagram ........................................................................................................................................... 3-3
3.1.7 Connecting Optional Features ........................................................................................................................................ 3-4
3.1.8 Current Sensing .............................................................................................................................................................. 3-4
3.1.9 Part Release ................................................................................................................................................................... 3-4
3.1.10 Lockout ......................................................................................................................................................................... 3-4
3.1.11 Energizing the System .................................................................................................................................................. 3-4
3.2 CONTROL MOUNTING GUIDELINES ................................................................................................................................... 3-5
4 OPERATING INSTRUCTIONS ......................................................................................................................................................... 4-1
4.1 IMPORTANT FACTS ABOUT MAGNETIC HOLDING ............................................................................................................ 4-1
4.1.1 Surface Conditions.......................................................................................................................................................... 4-1
4.1.2 Workpiece Thickness ...................................................................................................................................................... 4-2
4.1.3 Portion of the Chuck Surface In Contact With the Workpiece ........................................................................................ 4-2
4.1.4 Workpiece Material ......................................................................................................................................................... 4-2
4.2 FULL HOLDING ...................................................................................................................................................................... 4-3
4.3 VARIABLE HOLDING .............................................................................................................................................................. 4-3
4.4 RESIDUAL HOLDING ............................................................................................................................................................. 4-3
4.5 RELEASE ................................................................................................................................................................................ 4-3
4.6 CONTROL PROTECTION ...................................................................................................................................................... 4-5
4.7 RELEASE CYCLE STEPS ...................................................................................................................................................... 4-5
4.8 GROUNDING & SHIELDING .................................................................................................................................................. 4-7
4.8.1 Current Sensing .............................................................................................................................................................. 4-7
4.8.2 Part Release ................................................................................................................................................................... 4-7
4.8.3 Lockout ........................................................................................................................................................................... 4-7
4.9 CONTROL OUTPUT VOLTAGE .............................................................................................................................................. 4-7
800-WMAGNET
s
-D s
Mart
eries
Order #:
O
peratiOns
M
icrOprOcessOr
TOLL FREE: 800.WMAGNET
M
anual
c
c
OntrOlleD
huck
Part #:
c
OntrOl
1 of 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IMI Smart-D Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Walker Magnetics IMI Smart-D Series

  • Page 1: Table Of Contents

    peratiOns anual -D s Mart eries icrOprOcessOr OntrOlleD huck OntrOl TOLL FREE: 800.WMAGNET P.O. #: Order #: Part #: NEVER ATTEMPT TO OPERATE THIS CONTROL UNTIL YOU HAVE READ AND UNDERSTAND THIS OPERATOR’S MANUAL CONTENTS 1 INTRODUCTION ....................................1-1 2 SAFETY INSTRUCTIONS ................................2-1 2.1 GENERAL SAFETY RULES ..............................
  • Page 2 5 MAINTENANCE & TROUBLESHOOTING ............................5-1 5.1 INSPECTION & MAINTENANCE ............................5-1 5.2 HAVING A PROBLEM WITH YOUR CHUCK CONTROL? ..................... 5-1 5.3 CHUCK CONTROL CONNECTIONS ............................. 5-3 5.4 REMOTE INTERFACE ................................5-4 5.4.1 Connections: ................................... 5-4 5.5 INTERFACE .................................... 5-4 5.6 SMART 75/100D PANEL LAYOUT ............................
  • Page 3: Introduction

    1 INTRODUCTION Thank you for purchasing this O.S. Walker Chuck Control. If used and maintained properly, it should serve you for many years. However, if installed and used improperly, it can be rendered inefficient and unsafe. Therefore, it is absolutely essential that anyone who uses this control or is responsible for its application be trained on how to use it correctly.
  • Page 4: Safety Instructions

    2 SAFETY INSTRUCTIONS 2.1 General Safety Rules Following these simple rules can help to avoid accidents: • Never attempt to operate this control and your magnetic chuck until you read and understand this operator’s manual. • Never disconnect a magnetic chuck from the control’s DC power source while it is energized! Electrical arcing will occur and may cause serious injury or death.
  • Page 5: Recognize Safety Information

    2.2 Recognize Safety Information This is the safety alert symbol. When you see this symbol on your magnet or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices at all times. This indicates a situation in which a hazard is imminent and will result in a high probability of serious injury or death.
  • Page 6: Additional Warnings

    2.3 Additional Warnings • Disassembly or repair of this chuck control can result in reduced holding power and/or cause an unsafe condition. Therefore, any time the control is disassembled or repaired it should be thoroughly inspected and re-tested for proper electrical grounding and power output. • Modification of any operating circuits and electrical safety grounding can reduce the chuck control’s effectiveness and/or cause an unsafe condition.
  • Page 7: Mounting The Chuck Control & Connecting Electrical Power

    3 INSTALLATION All electrical chassis must be safety grounded. • Check that all sources of power are disconnected, locked out and tagged “Out of Service” prior to beginning • installation. Only qualified personnel should install this chuck control unit. • Prior to beginning, thoroughly plan your installation.
  • Page 8: Connecting The Chuck

    3.1.3 Connecting the Chuck The DC output to the chuck must include a ground wire that is connected to the safety ground lug on the chuck and to the chassis of the chuck control. It is recommended that the conduit for the DC output not be routed near high voltage AC wires.
  • Page 9: Connecting Optional Features

    3.1.7 Connecting Optional Features SMART-D chuck controls are equipped with three optional features, Current Sensing, Part Release and Lockout. These features enable the chuck control to work with external equipment such as machine controls or a PLC. Refer to the “Operation” section 4 of this manual for using of these features. 3.1.8 Current Sensing This control is equipped with a current sensing feature that monitors the current flowing to the chuck and indicates when this current has reached a predetermined value.
  • Page 10: Operating Instructions

    2. When any control (power section) is to be placed in a secondary enclosure while still in its original enclosure, the following specifications must be met: a. With the control (power section) mounted in its original enclosure and then mounted in a secondary enclosure, the air surrounding the original enclosure should not exceed 104°...
  • Page 11: Workpiece Material

    4.1.4 Workpiece Material Low carbon steel such as SAE 1020 steel, are nearly as good conductors of magnetic lines of force as pure iron. However, many other alloys contain non-magnetic materials which reduce the ability of magnetic lines of force to flow. An alloy such as SAE 300 series stainless steel is almost as poor a conductor of magnetic lines of force as air.
  • Page 12 The external adjustment for the number of demagnetization pulses per Release cycle is done using the full, residual, release pushbuttons, and the Variable potentiometer. To adjust the number of release pulses, the control must be “at the end of the release cycle”.
  • Page 13: Control Protection

    4.6 Control Protection If the control is switched into sudden high power operation with too large a load, the AC fuse may blow before the electronic protective circuits can function. If the chuck control is overloaded by a short circuit or a chuck too large for this control’s rating, the control will sense this condition and will attempt to protect itself by flashing all the system indicator lights, and the control will not respond to any function selection.
  • Page 14: Grounding & Shielding

    4.8 Grounding & Shielding The optional chuck control outputs for current sense and part released are isolated from the control circuit ground. All other chuck control electrical inputs and outputs, if connected to electronic equipment, must be isolated from the control’s internal circuit ground, which is connected to the AC safety ground (the green or green/yellow wire in the AC line cord).
  • Page 15: Inspection & Maintenance

    5 INSPECTION & MAINTENANCE 5.1 Daily Inspection Check the physical condition of the power cords, indicating lamps, switches, and the control enclosure. If any • deficiencies are observed, contact your supervisor or O.S. Walker. Check the integrity of the enclosure by inspecting for dust, debris, and fluid. Make necessary repairs. •...
  • Page 16: Chuck Control Connections

    5.3 Chuck Control Connections Table 5-1 Terminal TB1 Chuck DC Chuck DC Table 5-2 Connector - J4 Lockout Supply Relay Contacts 3,4,5 Part Released Signal Relay Contacts 6,7,8 Current Sense Relay Contacts Table 5-3 Connector - J5 50K Ohm Variable Potentiometer Release Lamp Variable Lamp Full Lamp...
  • Page 17: Remote Interface

    5.4 Remote Interface 5.4.1 Connections: Table 5-4 Remote TB = TBR (located in remote enclosure); J5 (located on main PC board) TBR:1 J5:1 TBR:2 J5:2 TBR:3 J5:3 TBR:4 J5:4 TBR:5 J5:5 TBR:6 J5:6 TBR:7,14 J5:7 TBR:8 TBR:9 J5:9 TBR:10 J5:10 TBR:11 J5:11 TBR:12...
  • Page 18: Smart 75/100D Panel Layout

    5.6 Smart 75/100D Panel Layout Figure 5-1 Smart 75/100D Panel 800-WMAGNET 18 of 33...
  • Page 19: Smart 20/30/50D Panel Layout

    5.7 Smart 20/30/50D Panel Layout Figure 5-2 Smart 20/30/50D Panel 800-WMAGNET 19 of 33...
  • Page 20: Smart 7/10/15D Panel Layout

    5.8 Smart 7/10/15D Panel Layout Figure 5-3 Smart 7/10/15D Panel 800-WMAGNET 20 of 33...
  • Page 21: Smart 3/5D Panel Layout

    5.9 Smart 3/5D Panel Layout Figure 5-4 Smart 3/5D Panel 800-WMAGNET 21 of 33...
  • Page 22: Main Pc Board

    5.10 Main PC Board Figure 5-5 Main PC Board 800-WMAGNET 22 of 33...
  • Page 23: Smart 75/100D Wiring

    5.11 Smart 75/100D Wiring Reference documentation included for schematics. Figure 5-5 Main PC Board 800-WMAGNET 23 of 33...
  • Page 24: Smart 20/30/50D Wiring

    5.12 Smart 20/30/50D Wiring Reference documentation included for schematics Figure 5-7 Smart 20/30/50D Wiring 800-WMAGNET 24 of 33...
  • Page 25: Smart 7/10/15D 115V Wiring

    5.13 Smart 7/10/15D 115V Wiring Reference documentation included for schematics Figure 5-8 Smart 7/10/15D 115V Wiring 800-WMAGNET 25 of 33...
  • Page 26: Smart 7/10/15D 200V Wiring

    5.14 Smart 7/10/15D 200V Wiring Reference documentation included for schematics Figure 5-9 Smart 7/10/15D 230V Wiring 800-WMAGNET 26 of 33...
  • Page 27: Smart 3/5D 115Vdc Wiring

    5.15 Smart 3/5D 115VDC Wiring Reference documentation included for schematics Figure 5-10 Smart 3/5D 115VDC Wiring 800-WMAGNET 27 of 33...
  • Page 28: Smart 3/5D 230Vdc Wiring

    5.1 Smart 3/5D 230VDC Wiring Reference documentation included for schematics Figure 5-11 Smart 3/5D 230VDC Wiring 800-WMAGNET 28 of 33...
  • Page 29: Enclosure Dimensions For Smart-D Controls

    5.2 Enclosure Dimensions for SMART-D Controls SMART WATTAGE STANDARD MODEL # CAPACITY OUTPUT VOLTAGE 115VDC 115VDC 115/230VDC 1000 115/230VDC 1500 115/230VDC 2000 230VDC 3000 230VDC 5000 230VDC 7500 230VDC 100D 10000 230VDC ENCLOSURE MSD3 MSD7 MSD20 MSD75 PANEL MSD3 MSD7 MSD20 MSD75 DIMENSIONS...
  • Page 30: Remote Enclosure Dimensions

    5.3 Remote Enclosure Dimensions Figure 5-12 Remote Enclosure BB-8783 800-WMAGNET 30 of 33...
  • Page 31: Remote Wiring Connections

    5.4 Remote Wiring Connections Figure 5-13 Remote Wiring Connections 800-WMAGNET 31 of 33...
  • Page 32: Replacement Parts List

    5.5 Replacement Parts List Table 5-5 Replacement Parts PART NUMBER DESCRIPTION SMART 3/5D SMART 7-15D SMART20-50D SMART 75D SMART100D Main PC Board 39-DD14329 39-DD14520 39-DD14520A Remote Control 56-BB8783 Transformer T1 12-0094 12-2001 12-0302 12-0504 12-0355 (208/480 Volt) SCR Module 23-4048 Relay K1 13-0220 13-0344...
  • Page 33: Return And Repair Instructions

    6 RETURN AND REPAIR INSTRUCTIONS For warranty and non-warranty repairs on any part of your chuck system, contact O.S. Walker Company TOLL FREE at 1-800-W-MAGNET. A return authorization number will be issued along with any applicable packaging and shipping instructions. After receipt of the components to be repaired, O.S.
  • Page 34 1-800-W-MAGNET • WWW.WALKERMAGNET.COM 900632.A (07/21)
