Honeywell Home PS1201A00 Installation Instructions Manual

PS1201A00, PS1202A00 and
PS2401B12 Replacement Power
Supplies for Electronic Air Cleaners
APPLICATION
This power supply board has a selectable ionizer current output. Selection of the correct ionizer current is
accomplished by moving the P5 shorting bar to the proper position. See table below.
Input Voltage
Power Supply Range (Vac)
PS1201A00 102-132 Vac
PS1202A00 102-132 Vac
PS2401B12 204-264 Vac
*Default setting.
Electronic Air Cleaner
Model Voltage (Vac)
F50F 120
240
F300A,E 120
F300B 240
*Default setting.
Table 1.
Input Input
Frequency Current
(Hz) (A)
50 / 60 0.4
50 / 60 0.4
50 / 60 0.2
Table 2.
Nominal Size
In. Mm
20 X 12.5 508 X 318
16 X 20 406 X 508
16 x 25 406 X 635
20 x 20 508 X 508
20 x 25 508 X 635
20 X 12.5 508 X 318
16 X 20 406 X 508
16 x 25 406 X 635
20 x 20 508 X 508
20 x 25 508 X 635
20 X 12.5 508 X 318
16 X 20 406 X 508
16 x 25 406 X 635
20 x 20 508 X 508
20 x 25 508 X 635
20 X 12.5 508 X 318
INSTALLATION INSTRUCTIONS
Output Output Ionizer Current (mA)
Ionizer (Selected by P5 shorting bar
Voltage (Vdc)
7500/8150* 2.1/1.65/1.29/1.05*/0.9/0.25
7500/8150* 2.1/1.65/1.29/1.05*/0.9/0.25
7500/8150* 2.1/1.65/1.29/1.05*/0.9/0.25
Ionizer Current P5
Position (mA)
1.05*
1.29
1.65
1.65
2.1
1.05*
1.29
1.65
1.65
2.1
1.05*
1.29
1.65
1.65
2.1
1.05*
position)
Replacement Power
Supply
PS1201A00
PS2401B12
PS1201A00
PS2401B12
69-2673EFS-03
