Honeywell Home PS1202C Installation Instructions Manual

PS1202C, PS2402C
Replacement Power Supply Kits
for Electronic Air Cleaners
APPLICATION
These kits replace the power supplies with solid-state
performance indicators (SSPI) used in the F50, F52,
F57, and F90 Electronic Air Cleaners. See Table 1.
Each kit includes the power supply and leadwires.
Supply
Model Voltage
F50E 120 Vac
240 Vac
F52E (One 120 Vac
Cell)
220-240 Vac,
50 Hz
F52E (Two 120 Vac
Cell)
220-240 Vac,
50 Hz
F57A (Two 120 Vac
Cell)
220-240 Vac,
50 Hz
F57B (One 120 Vac
Cell)
220-240 Vac
F90A (Two 120 Vac
Cell)
220-240 Vac,
50 Hz
F90B (One 120 Vac
Cell)
220-240 Vac,
50 Hz
F52F (One 120 Vac
Cell)
220-240 Vac,
50 Hz
F52F (Two 120 Vac
Cell)
240 Vac
Table 1. Power Supply Replacement Guide.
Nominal Size of
Electronic Cell(s)
(in.) (mm)
16 x 25 406 x 635
20 x 20 508 x 508
20 x 25 508 x 635
16 x 25 406 x 635
20 x 20 508 x 508
20 x 25 508 x 635
20 x 12-1/2 508 x 318
20 x 25 508 x 635
20 x 25 508 x 635
20 x 12-1/2 508 x 318
20 x 25 508 x 635
20 x 12-1/2 508 x 318
20 x 12-1/2 508 x 318
20 x 25 508 x 635
INSTALLATION INSTRUCTIONS
CAUTION
Electric Shock Hazard.
Can cause electrical shock or equipment
damage.
Disconnect power before removing or
installing power supply board.
LED Board
P5 Ionizer Jumper
Current (mA) Position
1.65 2 (1.65)
1.65 2 (1.65)
2.1 1 (2.1)
1.65 2 (1.65)
1.65 2 (1.65)
2.1 1 (2.1)
1.05 4 (1.05)
1.05 4 (1.05)
2.1 1 (2.1)
2.1 1 (2.1)
2.1 1 (2.1)
2.1 1 (2.1)
0.9 3 (1.29)
0.9 3 (1.29)
2.1 1 (2.1)
2.1 1 (2.1)
0.9 3 (1.29)
0.9 3 (1.29)
1.05 4 (1.05)
1.05 4 (1.05)
2.1 1 (2.1)
2.1 1 (2.1)
Replacement Power Supply
(OS no.)
PS1202C00
PS2402C00
PS1202C00
PS2402C00
PS1202C00
PS2402C00
PS1202C00
PS2402C00
PS1202C03
PS1202C03 with 203365
PS1202C03
PS1202C03 with 203365
PS1202C00
PS2402C00
PS1202C00
PS2402C00
PS1202C00
PS2402C00
69-1137EF-05
Air Flow
Switch
No
Yes
