CENTER PART
7
6
1
3
2
5
4
1. battery disconnect 3. driver's workplace
switch. When activated, lighting on (depending on
the battery is completely model variant).
disconnected. To switch 4. load compartment
the ignition back on, this lighting
switch must be in the de- 5. driver's lighting area.
fault position and the key Press up to activate the
turned or the [E] button driving lights only when
used. the [E] button must the front door is open.
be used. Press down to activate
2. interior lighting. Press the driving lights without
up to activate the full condition
intensity of the lighting.
Press down to activate
the minimum intensity.
16
8
14
10
11
12
13
6. switches for outdoor
lighting
a. Off
b. Daytime running lights
c. Low beam headlamps
7. fog lights (low beam
must be activated)
8. rear fog lamps
9. hazard warning lights
10. vehicle speed in kilome-
tres per hour
11. remaining fuel
12. engine temperature
13. engine speed
14. on-board computer
ONBOARD COMPUTER
The onboard computer is located in the centre of the central dashboard.
The displays of the onboard computer are switched using the arrow keys on the
steering wheel.
Main screen
9
3
1
4
6
Oil and air pressure
1
2
Trip kilometer counter (Trip 1)
Ad-Blue display
1. warnings 1
5
2. warnings 2
(Door is open/low air pressure/engine
temperature too high)
2
7
3. time
4. outside temperature
5. Gear engaged
6. total kilometer counter
7. trip kilometer counter
1. Oil pressure
2. Air pressure
1. Average speed
1
2. trip time
2
* The trip kilometer counter (Trip 1) can
be reset next to the fuel gauge.
1. ad-blue level
1
