HEATING SYSTEM / AIR CONDITIONING
The heating system can be used to control the interior temperatures of the
vehicle. To use these functions, the engine must be switched on.
To activate the system, press the power button (1).
7
6
1
2
4
3
11 12
Air conditioner 6. input error display
(point 1 to 8)
yellow: Inputs are not
1. switch on button valid (temperatures
2. change display mode selected too low or too
temperature display (7) high)
driver area / passenger red: Internal error
area / set temperature 7. temperature display
3. change mode (automatic In case of error: Ht =
/ cool / heat) temperature too high / Fr
4. change fan speed (au- = temperature too low
tomatic / high / medium 8. temperature selection
/ low) (range 17 to 27 degrees
5. change ventilation mode Celsius)
(automatic / fresh air / 9. odometer (time, speed,
recirculated air) distance)
18
8
5
9 10
13 14 15 16
10. FM radio - click on left
button for on/off
Heating in the driver's area
(point 11 to 14)
11. fan speed
12. heating position
13. temperature selection
14. fresh air /
recirculated air
15. open front door
(upwards) / close
(downwards)
16. Back door open / close
IBIS MATRIX CONTROLLER
The internal and external bus displays are configured and controlled via the
matrix controller. For example, the selected destination can be seen on the
outside of the bus
1
1. numeric keypad 3. change between
2. arrow keys stop selection automatic and manual
(up next / down previous announcement
stop) 4. no function
5. route
3 4
5 6
7 8
9
2 10
6. line
7. play next stop
8. destination
9. no function
10. enter
