PSK01 Smart Keypad
TM
The PSK01 support Z-Wave
report key status and setup Arm/ Disarm.
This product can be included and operated in any Z-Wave
TM
network with other Z-Wave
manufacturers and/or other applications.
The devices Built-in rechargeable Lithium-ion battery and using
DC 5V(Micro USB) charge.
Multi-Functions Smart Switch to
TM
certified devices from other
CAUTION
– replacement of a battery with an incorrect type that can defeat
a safeguard (for example, in the case of some lithium battery
types);
– disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery, that can result in an explosion;
– leaving a battery in an extremely high temperature surrounding
environment that can result in an explosion or the leakage of
flammable liquid or gas;
– a battery subjected to extremely low air pressure that may
result in an explosion or the leakage of flammable liquid or gas
The marking information is located at the bottom of the
apparatus.
Specification
Rated Voltage (
rechargeable
Lithium-ion battery)
Micro USB)
Rated Voltage (
Operating Temperature
Storage Temperature
Location
RF Range (distance)
1
DC3.7V~4.2V
DC5V / 1A
0°C - 40°C (85% humidity)
-20 C - 60°C
IP44 (indoor and outdoor)
Minimum 40M in door and 100M
in outdoor, line of sight
