When turning off the display by detaching the power cord, wait 6 seconds before re-attaching the power cord for normal operation. • Ensure the use of an approved power cord provided by Philips at all times. If your power cord is missing, please contact your local service center. •...
Page 4
32BDL3651T/43BDL3651T If your display does not operate normally, having followed the instructions set out in this document, please contact a technician or your local service center. Stability Hazard The device may fall, causing serious personal injury or death. To prevent injury, this device must be securely attached to the floor/ wall in accordance with the installation instructions.
Page 5
32BDL3651T/43BDL3651T To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or excessive moisture. This device complies with Part 15 of the FCC / ISED’s licence-exempt RSSs Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 6
32BDL3651T/43BDL3651T Taiwan: 低功率電波輻射性電機管理辦法 取得審驗證明之低功率射頻器材,非經核准,公司、商號或使用者均不得擅自變更頻率、加大功率或變 更原設計之特性及功能。 低功率射頻器材之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善 至無干擾時方得繼續使用。 前述合法通信,指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學 及醫療用電波輻射性電機設備之干擾。 FCC/ISED/CE-RED Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5GHz products are restricted to indoor usage only.
Page 7
32BDL3651T/43BDL3651T Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source. The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A).
Page 8
32BDL3651T/43BDL3651T Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows:+ 1. Remove fuse cover and fuse. 2.
Page 11
Please find out about the local regulations on how to dispose of your old display from your local Philips dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.
Page 12
32BDL3651T/43BDL3651T Batteries For EU: The crossed-out wheeled bin implies that used batteries should not be put to the general household waste! There is a separate collection system for used batteries, to allow proper treatment and recycling in accordance with legislation. Please contact your local authority for details on the collection and recycling schemes.
DVI cable • Touch USB Power Cord RS232 Cable RS232 Daisy IR Sensor Cable • AC Cover(Only 43BDL3651T) Chain Cable • Philips logo plate • Cleaning cloth • USB Cover • Cable Clip Touch USB AC Cover HDMI Cable DVI Cable...
32BDL3651T/43BDL3651T 2.3. Mounting on a Wall To mount this display on a wall, a standard wall-mounting kit (commercially available) is required. It is recommended that you use a mounting interface that complied with TUV-GS and /or UL1678 standard in North America. 32BDL3651T 43BDL3651T Protective Sheet...
32BDL3651T/43BDL3651T Parts and Functions 3.1. Control Panel 32BDL3651T 43BDL3651T 1 2 3 4 5 6 7 8 ]button Turn the display On or put the display to standby mode. [MUTE] button Mute the sound or reactivate sound. [INPUT] button If the light blinks red, it indicates that a failure has been detected Select an input source.
32BDL3651T/43BDL3651T 3.2. Input/Output Terminals 32BDL3651T RS232 RS232 USB2.0 Service Port MICRO SD IR-OUT IR-IN PC LINE IN AUDIO OUT HDMI 1 IN HDMI 2 IN RJ45 DVI-I IN USB B AC IN USB 2.0 PORT AC power input from the wall outlet. Connect your USB storage device and service port.
Page 17
32BDL3651T/43BDL3651T 43BDL3651T RS232 RS232 USB2.0 Service Port MICRO SD IR-OUT IR-IN AUDIO OUT HDMI 1 IN HDMI 2 IN PC LINE IN DVI-D IN USB B RJ45 VGA IN 9 10 USB 2.0 PORT AC IN Connect your USB storage device and service port. AC power input from the wall outlet.
32BDL3651T/43BDL3651T 3.3. Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace the batteries: 1. Press and then slide the cover to open it. 2. Insert the batteries with the correct polarity (+) and (–). 3.
32BDL3651T/43BDL3651T 3.6. Remote Control Show Information OSD. NAVIGATION buttons 3.6.1. General functions Root Menu: Go to the OSD of Smart picture. Main Menu: Move the selected item up to make adjustment. IR Daisy Chain Menu: Increase the controlled Group ID number.
32BDL3651T/43BDL3651T 3.6.2. ID Remote Control Press the [ID] button and the red LED blinks twice. 1. Press [ID SET] button for more than 1 second to enter the ID Set remote control ID number when using several displays. Mode. The red LED lights up. Press the [ID SET] button again will exit the ID Mode.
3. When playing a video or music file, you can press button to pause playing. 4. All media files should be located in the folder of “philips”, under the root directory of the specified storage (internal/USB/SD Card). All sub-folders (video/photo/ music) are named by media types and shouldn’t be changed.
Page 22
32BDL3651T/43BDL3651T ] BACK button Return to the previous page or exit from the previous function. ] MUTE button Mute or unmute the sound. The button is only controlled by Scalar. [ ] [ ] [ ] [ ] COLOR buttons [Number/ ID SET/ ENTER] button ID SET and ENTER...
32BDL3651T/43BDL3651T 3.7. USB Cover * Use the USB cover and screws to hide the USB stick and Micro SD card ■ Install the USB sticker and micro SD card. ■ Use the screw from accessory to fix the USB cover. Maximum suitable USB stick size: 20(W)x10(H)x80(L) mm 32BDL3651T 43BDL3651T...
32BDL3651T/43BDL3651T 3.8. AC Switch Cover(Only for 43BDL3651T) • Use AC Switch Cover to cover the AC switch. 1. Release the screw. 2. Install the AC Switch Cover. 3. Fix the AC Switch Cover with the screw in step1.
32BDL3651T/43BDL3651T Connecting External Equipment 4.1. Connecting External Equipment (DVD/VCR/VCD) 4.1.1. Using HDMI video input DVD / VCR / VCD HDMI Out HDMI1 IN HDMI2 IN [HDMI IN] Connecting a PC 4.2. 4.2.1. Using DVI input 32BDL3651T [PC LINE IN] Audio Out PC LINE IN DVI-I Out DVI-I IN...
32BDL3651T/43BDL3651T 4.2.2. Using HDMI input HDMI Out HDMI1 IN HDMI2 IN [HDMI IN] 4.2.3. Using VGA input 32BDL3651T [PC LINE IN] Audio Out PC LINE IN VGA Out DVI-I IN D-Sub 15 pin [DVI-I IN] 43BDL3651T PC LINE IN VGA IN SPEAKER DP OUT SWITCH...
32BDL3651T/43BDL3651T 4.4. Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a menu board. 4.4.1. Display control connection Connect the [RS232 OUT] connector of DISPLAY 1 to the [RS232 IN] connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [RS-232C]...
32BDL3651T/43BDL3651T IR connection 4.5. External IR Receiver DISPLAY 1 DISPLAY 2 [IR IN] [IR IN] [IR OUT] DISPLAY 1 DISPLAY 2 [RS-232 OUT] [RS-232 IN] NOTE: 1. The remote control sensor of this display will stop working if the [IR IN] is connected. 2.
32BDL3651T/43BDL3651T Touch Operation 4.7. Zoom in This display is equipped with a touch-sensitive screen and Touch the target on the screen with two fingertips held supports the Windows Touch features either by single touch or together and move them apart to zoom in (magnify) the screen multi-touch operation.
Page 30
32BDL3651T/43BDL3651T The multi Touch function is not supported by Mac OS. The OS supported is listed below. 32BDL3651T Item Description Operating Systems Supported Windows 7, 8, 10 by Plug-and-Play Single Touch Multi Touch Windows 7, 8, 10 Mac OSX before (include) 10.14 Chrome 38+ O*** O***...
32BDL3651T/43BDL3651T Operation 2) Whiteboard page: Note: The control button described in this section is mainly on the remote control unless specified otherwise. 5.1. Watch the Connected Video Source 1. Press the [ ] SOURCE button. 2. Press [ ] or [ ] button to select a device, then press ] button.
The pencil icon means the playlist is non-empty. 4. If an empty playlist is chosen, the app will guide you through selecting the media source. All media files should be placed in /philips/ of root directory. For example, videos in /philips/video/...
Page 33
32BDL3651T/43BDL3651T 5. If you select “USB” storage, the app will guide you 7.1 In the slidebar, the following functions are available: through selecting the USB device. - Select all: select all storage files. - Delete all: delete all playlist files. - Add/Remove: update playlist from source.
Page 34
32BDL3651T/43BDL3651T 10. After selecting the desired file, press “Play” key to play the media file immediately. 11. If you created a playlist with all image files, you will be asked to add a background music to the slideshow before saving. 12.
3.0/3.1 agreement becomes black when playing music file. (5) Content Step 2. Copy “mpplaylistX.txt” to “philips” folder of There are 3 options available: internal storage, SD card internal storage. You may use FTP to do this. and USB storage.
32BDL3651T/43BDL3651T 5.6. Side Bar Hide Hide side bar. Home Open Home. Source menu Open source menu. Open IWB, this item is not displayed under the IMD Home. OSD Menu Open OSD menu. My Favorite Open my favorite, add or remove frequently used APK. Quick info It will display the information of Time, Network and Monitor Information.
32BDL3651T/43BDL3651T Setting UI On the available network list, select an AP (access point) on an existing wireless network. 6.1. Settings Setting menu consists of the following items: (1). Network & Internet (2). Signage Display (3). Apps (4). Display (5). Security (6).
Page 38
32BDL3651T/43BDL3651T Wi-Fi Preference By default, the system uses DHCP to join the network. Connection Information (When the options are grayed out, Settings -> Network & Internet -> Wi-Fi -> Wi-Fi Preference they are not editable). (1). IP Address (2). Gateway (3).
When it is set to “User” mode, the option “Choose Boot Animation” becomes available. When Logo is set to “User” mode, the default Philips logo will be replaced by user selected boot animation file. Click “Choose Boot Animation” and a pop-up menu appears for 6.1.2.1.
Page 40
The function of mailing out the “bootanimation.zip” has not been saved before by user. screenshot is consequently suspended. The screenshot- Default Philips logo appears during system boot up. related features will be restarted when the system enters active mode.
Page 41
32BDL3651T/43BDL3651T Set the repeat mode for auto screenshot. (5). Save to The screen images will be saved under the folder named “philips/screenshot” of the internal storage. (6). Purge Screenshots Set the interval time for deleting the screenshot images. Email Notification The available options are “Every day”...
Page 42
32BDL3651T/43BDL3651T SMTP Manager Email Setup sender E-mail address and SMTP server information. Specify the destination address to receive the e-mail. There are two types of SMTP server for user to set up: “Gmail” and “Other”. By using “Other” option, user can manually setup STMP server, security type and server port.
Page 43
32BDL3651T/43BDL3651T Bind status: CMND & Play APK settings activity (1). If the device does not have appropriate network connection, a message “Network is disconnected” will appear. (2). If the device is equipped with network function, but is not connected to the remote control server, a message “Server is disconnected”...
Page 44
32BDL3651T/43BDL3651T Select APP System supports the following proxy types: HTTP, HTTPS, SOCKS4, and SOCKS5. Choose one for your proxy server. Select a specific APP for custom APP source. If an authorization is requested by proxy server, click the checkbox of “Authorization” and enter the username and password.
Page 45
Clear data under {storage}/philips/folder of the internal and external storage. (1). All Use the time picker to set auto restart time. Clear the folder “Philips” from the internal storage, USB and SD card. (2). Internal Storage Clear the folder “Philips” from the internal storage only.
Page 46
Source is internal storage Check if there is CMS file on the FTP server. 6.1.2.6. Misc. If there is no CMS file on the FTP server, check philips/ TeamViewer Support folder in source storage Click the checkbox to enable or disable TeamViewer support.
32BDL3651T/43BDL3651T 6.1.3. Apps Once the file is selected from the list, the system starts rebooting and updating. Display installed APKs information. Please note that: (1). Do not turn off the power or remove the power adapter until the update is complete. (2).
32BDL3651T/43BDL3651T 6.1.4. Display 6.1.6.1. Keyboard & input Settings -> System -> Keyboard & input Change the font size of your display. User can change IME and keyboard settings. 6.1.4.1. Font Size Virtual keyboard Drag the slide to adjust system font size. Default setting is “Largest”.
Page 49
32BDL3651T/43BDL3651T 6.1.6.3. About Settings -> System -> About View the following information about the system. (1). Status (2). Legal information (3). Model (model name of this device) (4). Android version (5). Android security patch level (6). Kernel version (7). Build number (release version) Status Display device serial number and total time for the device to boot up.
32BDL3651T/43BDL3651T OSD Menu 7.2. OSD Menu Overview An overview of the On-Screen Display (OSD) structure is shown 7.2.1. Picture menu below. You can use it as a reference for further adjustment of your display. Picture Brightness 7.1. Navigating the OSD Menu Screen Contrast Audio...
32BDL3651T/43BDL3651T Color temperature Note: VGA input only. Adjust the color temperature. Clock The image becomes reddish as the color temperature decreases, Press + button to expand the width of the image on the screen and becomes bluish as the color temperature increases. to the right.
32BDL3651T/43BDL3651T Audio Out Sync V position Line out volume sync with internal speaker Volume. Moves the vertical position of the image {On}: Enable the function and gray out Audio Out (line out) up or down. Volume. {Off}: Disable the function. Auto adjust Speaker Setting Press “Set”...
32BDL3651T/43BDL3651T Note: This function only works in power mode 1 and mode 2. • {User} – Static Philips logo will not be shown, only user- selected boot animation will be shown in Android settings. Light sensor Note: Logo will not be rotated even thought rotation setting is Choose to turn on or off the light sensor function of CRD41.
Page 54
32BDL3651T/43BDL3651T Off timer • {Secondary} - Designate this display as the secondary display. This display cannot be operated by the remote control, and Set automatic power off time (in hours). will only receive the control signal from the primary display Date and time via RS232 connection.
32BDL3651T/43BDL3651T HDMI One Wire Power Off Power mode Mode 1, Mode 2 Mode 3, Mode 4 DC off System shutdown 1. Media Player, Browser, PDF Allow user to set multiple devices to standby mode by Player and SmartCMS will pressing the power button. This function is only available close.
32BDL3651T/43BDL3651T Supported Media Formats USB Multimedia Codec Formats Video Decode Type Video Codec Container Decode Encode Channel Remark MPEG program stream (.DAT, .VOB, .MPG, .MPEG) MPEG transport stream (.ts) Max Resolution: 1080P@60fps MPEG1/2 MPEG1/2 MP4 (.mp4) Max Bit Rats : 40Mbps AVI (.avi) MKV (.mkv) MP4 (.mp4)
Page 57
32BDL3651T/43BDL3651T Type Image Codec Photo Decode Encode Channel Remark Max Resolution: 7000 x 7000 JPEG JFIF file format 1.02 File Format: JPG, JPEG The limitation of max resolution depends on DRAM Max Resolution: 15360 x 8640 File Format: BMP The limitation of max resolution depends on DRAM Max Resolution: 15360 x 8640 File Format: PNG...
However, pixel or sub-pixel defects on the PDP / TFT panels used in Plasma- & LCD- displays are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but Philips guarantees that any Plasma- &...
10.6. Pixel Defect Tolerances In order to qualify for repair due to pixel defects during the warranty period, a PDP / TFT panel in a Philips Plasma / LCD- display must have pixel or sub-pixel defects exceeding the tolerances listed in the following table.
32BDL3651T/43BDL3651T 11. Cleaning and Troubleshooting 11.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes. Burns or personal injuries may occur if any body parts are brought too close.
32BDL3651T/43BDL3651T 11.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back of 2. Make sure that the power switch is the display is not switched on.
Page 64
32BDL3651T/43BDL3651T How to setup the settings in the menu to Daisy chained by RS232 and no IR cable 1. The first display sets as “Primary” on control all the monitors at the same time OSD (Advanced option/IR control item), and individually via RC? others set as “Secondary”.
32BDL3651T/43BDL3651T Technical Specifications Display: 32BDL3651T Item Specifications Screen Size (Active Area) 80 cm / 31.5 inches Aspect Ratio 16:9 Number of pixels 1920 (H) x 1080 (V) Pixel pitch 0.36375(H) x 0.36375 (V) [mm] Displayable colors 8 bits (16.7 million) Brightness (typical) 350 cd/m Contrast ratio (typical)
Page 66
32BDL3651T/43BDL3651T General: Item Specifications Power Input 100 - 240V~, 50/60Hz Power Consumption (Max) 80 W Power Consumption (typ.) 50 W Power Consumption (Standby mode & Off <0.5 W mode) Dimensions (Without Stand) [W x H x D] 749.1x 443.6 x 74.4 mm Weight (Without Stand) 8.0 Kg Gross Weight (Without Stand)
Page 67
32BDL3651T/43BDL3651T Display: 43BDL3651T Item Specifications Screen Size (Active Area) 108 cm / 42.5 inches Aspect Ratio 16:9 Number of pixels 3840 (H) x 2160 (V) Pixel pitch 0.2451(H) x 0.2451 (V) [mm] Displayable colors 1.07G (8Bits +FRC) Brightness (typical) 350 cd/m Contrast ratio (typical) 1200:1 Viewing angle...
Page 68
32BDL3651T/43BDL3651T General: Item Specifications Power Input 100 - 240V~, 50/60Hz Power Consumption (Max) 220 W Power Consumption (typ.) 100 W Power Consumption (Standby mode & Off <0.5 W mode) Dimensions (Without Stand) [W x H x D] 990.0 x 578.2x 102.7 mm Weight (Without Stand) 17.9 Kg Gross Weight (Without Stand)
LIMITED WARRANTY In the unlikely event the product requires service, we will arrange for your Philips product to be serviced free-of-charge within the warranty period, provided that the product was used in accordance with the user manual (e.g. in the intended environment).
Page 70
Warranty period for PHILIPS signage display is listed as below, for areas not covered in this table, please follow their warranty statement. Standard warranty period for PHILIPS signage display is listed as below, for areas not covered in this table, please follow the local warranty statement.
Connecting External Equipment (DVD/VCR/VCD) 23 Connecting Multiple Displays in a Daisy-chain Configuration 25 Control Panel 13 Warranty policy for Philips Professional Display Solutions Watch the Connected Video Source 29 Handling the remote control 16 Input Mode 56 Input/Output Terminals 14...
Page 72
This product has been manufactured by and is sold under the responsibility of Top Victory Investments Ltd., and Top Victory Investments Ltd. is the warrantor in relation to this product. Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are used under license.
