- Page 1 User Guide IC-215P-AW1 Touch Computer Version 1.2 2022/02...
- Page 2 MICROTOUCH reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of MICROTOUCH to notify any person of such revisions or changes. Windows is a registered trademark of...
- Page 3 Compliance Information For FCC (USA) This equipment has been tested and fund to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. There limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Renseignements relatifs à la conformité Pour la FCC (États-Unis). Ce matériel a fait l’objet d’essais qui ont déterminé qu’il respectait les limites d’un appareil de classe A selon la partie 15 des règlements de la FCC. Ces limites sont établies pour assurer une protection raisonnable contre les parasites nuisant à...
- Page 5 Usage Notice Warning - To prevent the risk of fire or shock hazards, and do not expose the product to moisture. Warning - Please do not open or disassemble the product as this may cause electric shock. Warning - Power cord shall be connected to a socket-outlet with earth connection.
- Page 6 Avis d’utilisation Mise en garde — Pour prévenir les risques d’incendie ou d’électrocution, ne pas exposer le produit à l’humidité. Mise en garde — Prière de ne pas ouvrir ou démonter le produit, car cela pourrait entraîner l’électrocution. Mise en garde – Le cordon d’alimentation doit être branché à une prise pourvue d’une mise à...
-
Page 7: Table Of Contents
Table of Contents Chapter 1 ........................7 1.1 Overview ........................8 1.2 Feature ........................8 1.3 Specifications ......................8 1.4 Block Diagram......................10 1.5 Interface Connectors ....................11 1.6 Package Overview ....................13 Chapter 2 ........................14 2.1 About VESA Mount ....................15 2.2 Power On / Off Switch .................... -
Page 8: Chapter 1
Chapter 1 Product Introduction... -
Page 9: Overview
1.1 Overview The IC-215P-AW1 is a thin 21.5” touch computer that offers a unique design with expandability and flexibility, making expansion and accessory installation easy. The versatility of IC-215P-AW1 is an exceptional choice for applications in all business sectors, especially in the retail market 1.2 Feature... - Page 10 1 x Power button Internal IO Ports 2 x connector (5V/0.5A) (inside plastic cover) Windows 7 OS Support Windows 10 Operation Temp 0°C~40°C Storage Temp -20°C to 60°C Operation Humidity 20~80%, Non-Condensing Storage Humidity 10~90%, Non-Condensing LCD Touch Panel Size 21.5”...
-
Page 11: Block Diagram
1.4 Block Diagram... -
Page 12: Interface Connectors
1.5 Interface Connectors 12V DC In Pin # Signal Name Pin # Signal Name 12V DC Out Pin # Signal Name Pin # Signal Name USB2.0 Pin # Signal Name Pin # Signal Name USB5V RJ45 for LAN Pin # Signal Name Pin # Signal Name... - Page 13 RJ50 for RS232 Pin # Signal Name Pin # Signal Name 12V / RI / 5V VGA DSUB-15 Pin # Signal Name Pin # Signal Name Green Blue SYNC Pin # Signal Name Pin # Signal Name Line Out Right Link Detect Left...
-
Page 14: Package Overview
12Vdc, 5A minimum. (complied with LPS or PS2) Tma = 40 degree C minimum, and the altitude of operation = 3048m minimum. If it needs further assistance with purchasing the power source, please contact to MICROTOUCH for further information. Mise en garde! Cet appareil est conçu avec une alimentation de courant CA, d’une tension... -
Page 15: Chapter 2
Chapter 2 Product Installation... -
Page 16: About Vesa Mount
The VESA mount is located on the back of this unit. The IC-215P-AW1 may be wall mounted in the horizontal position (output connector facing down) or vertical position (output connector facing left or right). - Page 17 Mise en garde! Sélectionner les vis d’origine de MICROTOUCH! La distance entre la surface du couvercle arrière et le bas de l’orifice de la vis est de 8 mm. Utiliser quatre vis M4 de 8 mm de diamètre pour le montage de votre moniteur.
-
Page 18: Power On/Off Switch
2.2 Power On / Off Switch Power On/Off Switch Function Description Power on Press the power button. Sleep With OS settings, sleep or shut down choose one. Power off Force Press the power button 4 sec. power off... -
Page 19: Dimension
2.3 Dimension 2.3.1 System Only Front View Side View Rear View Bottom View... -
Page 20: System With Stand Module
2.3.2 System with Stand Module Front View Side View Rear View... -
Page 21: Optional Accessory Installation
Bottom View 2.4 Optional Accessory Installation Note: Please install the accessories when the touch computer is in a powered off state. 2.4.1 Install the Stand Place stand module on back of touch computer and align the screw holes. Install the four M4 screws to fasten the stand. -
Page 22: Remove The Stand Module
2.4.2 Remove the Stand Step 1: Loosen the screws Step 2: Pull it to out from touch computer and remove stand module. Step 1 Step 2 2.4.3 Install the Cables 2.4.3.1 Cable Organizer Step 1: Pull down the cable cover for cables installation. Step 2: To fit the plugs Step 2 Step 1... -
Page 23: Stand Module
Step 3: To assemble the cable cover. Step 4: Driving a screw to fix cable cover (The cable can be fixed above or below the cable cover) Step 4 Step 3 2.4.3.2 Stand... -
Page 24: Install The Camera Module
2.4.4 Install the Camera Module Camera Module W\weight 19g Step 1: Remove the side cover. Step 2: Connect the camera module cable to the touch computer. Step 3: Install the two M3 screws to fasten the camera module. Step 1 Step 3 Step 2 2.4.5 Remove the Camera Module... -
Page 25: Install The Msr Module
2.4.6 Install the MSR Module MSR Module weight. 62g. Step 1: Remove the side cover. Step 2: Connect the MSR module cable to the touch computer. Step 1 Step 2 Step 3: The metal bracket hook into the gap between cover glass and bezel. -
Page 26: Remove The Msr Module
Step 4: Install the two M3 screws to fasten the MSR module. Step 4 2.4.7 Remove the MSR Module Step 1: Loosen the screws. Step 1... - Page 27 Step 2: Remove the MSR module cable from the touch computer. Step 3: To assemble the side cover. Step 3 Step 2...
-
Page 28: Chapter 3
Chapter 3 AMI BIOS Setup... -
Page 29: About Ami Bios Setup
3.1 About AMI BIOS Setup Use the BIOS Setup to update the BIOS or configure settings. The screens include navigation keys and help to guide you in using the BIOS Setup program. To enter BIOS Setup at startup: Press <Delete> during the power-on self-test (POST). If you do not press <Delete>, POST continues with its routine. -
Page 30: Main Menu
3.2 Main Menu The Main menu provides you an overview of the basic system information, and allows you to set the system date and time. 3.3 Advanced Menu The Advanced menu items allow you to change the settings for the CPU and other system devices. -
Page 31: Chipset Menu
3.4 Chipset Menu The Chipset menu items allow you to change the settings for the chipset. 3.5 Security Menu The Security menu items allow you to change the system security settings. -
Page 32: Administrator Password
3.5.1 Administrator Password If you have set an administrator password, we recommend that you use the administrator password for accessing the system. Otherwise, you might only be able to see or change selected fields in the BIOS setup program. To set an administrator password: 1. -
Page 33: Boot Menu
To change a user password: 1. Select the User Password item and press <Enter>. 2. Key in the current password from the Enter Current Password box, and press <Enter>. 3. Key in a new password from the Create New Password box, and press <Enter>. 4. -
Page 34: Save & Exit
3.7 Save & Exit Save Changes and Reset Once you are finished your selections, choose this option from the Exit menu to ensure the values you selected are saved. A confirmation window will appear when you select this option. Select Yes to save changes and reboot system. Discard Changes and Reset This option allows you to exit the setup program without saving your changes. -
Page 35: Appendix
Appendix... -
Page 36: Declaration Of The Presence Condition Of The Restricted Substances Marking
Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：觸控電腦 型號（型式）：IC-215P-AW1 Equipment name: Touch Computer Type designation (Type): IC-215P-AW1 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Hexavalent Polybrominated Polybrominated Lead Mercury...
