Wasp WDT950 Handheld Terminal (38 Keys)
User's Manual
v1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WDT950 and is the answer not in the manual?

Questions and answers

Related Manuals for Wasp WDT950

Summary of Contents for Wasp WDT950

  • Page 1 Wasp WDT950 Handheld Terminal (38 Keys) User's Manual v1.5...

  • Page 2: Preface

    Preface About This Manual This manual explains how to install, operate and maintain our product. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, such as photocopying, recording, or information storage and retrieval systems, without permission in writing from the manufacturer.
  • Page 3 any other antenna or transmitter. This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with FCC RF exposure requirements, avoid direct contact to the transmitting antenna during transmitting. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
  • Page 4 permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p. limits as appropriate; and (iv) where applicable, antenna type(s), antenna models(s), and worst-case tilt angle(s) necessary to remain compliant with the e.i.r.p. elevation mask requirement set forth in section 6.2.2.3 shall be clearly indicated.
  • Page 5 ("SAR") des limites lorsqu'il est utilisé dans des conditions d'exposition portatifs. European Conformity Statement Wasp Barcode Technologies herewith declares that the Wasp product is in compliance with the essential requirements and all other provisions of the RED 2014/53/EU directive.
  • Page 6 Union regulations that set maximum concentration limits on hazardous materials used in electrical and electronic equipment. Waste electrical and electronic equipment (WEEE) Wasp has set up a policy and process to meet the 2012/19/EU concerning electronic waste disposal. For more detailed information of the electronic waste disposal of the products you have purchased from Wasp directly or via Wasp’s resellers, you shall either contact...
  • Page 7 Taiwan NCC Warning Statement 低功率電波輻射性電機管理辦法 第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者 均不得擅自變更頻率、加大功率或變更原設計之特性及功能。 第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有 干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備 之干擾。 SAR標準值2.0W/KG, 送測產品實測值為: 0.395 (W/KG) 注意事項: 1. 使用過度恐傷害視力。 2. 使用30分鐘請休息10分鐘；未滿2歲幼兒不看螢幕，2歲以上每天看螢幕不要超 過 1小時。...
  • Page 8 減少電磁波影響，請妥適使用。 因應各地區/國家開放頻道不同，請依據當地主管機關與電信業者實際公告資訊 為主，如服務細則有所變更，請自行洽詢電信業者，恕不另通知。 無線資訊傳輸設備避免影響附近雷達系統之操作 Note: Within the 5.25-5.35 GHz band, U-NII devices will be restricted to indoor operations to reduce any potential for harmful interference to co-channel MSS operations.
  • Page 9 Laser Information The Wasp product is certified in the U.S. to conform to the requirements of DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 60825-1. Class II and Class 2 products are not considered to be hazardous. The Wasp product contains internally a Visible Laser Diode (VLD) whose emissions do not exceed the maximum limits as set forth in the above regulations.
  • Page 10 Battery Notice To guarantee optimal performance, it is recommended that rechargeable batteries be replaced every year, or after 500 charging cycles are completed. It is normal for the battery to balloon or expand after one year or 500 cycles. Although it does not cause damage, it cannot be used again and must be disposed of according to the location's safe battery disposal procedures.
  • Page 11 It may not be functional anymore. Please only use the original battery from Wasp. Using a third-party battery can damage our products. Please note that when such damage occurs, it is not covered by Wasp’s warranty policy.
  • Page 12 For the products with non-removable batteries / without batteries, please refer to the specification of each product. Product Operation and Storage Notice The Wasp product has applicable operation and storage temperature conditions. Please follow the limitation of suggested temperature conditions to avoid failure, damage or malfunction.
  • Page 13 Wasp product for charging. Please remove the power adapter when the battery is fully recharged. The bundled power adapter that comes with your Wasp product is not meant to be used outdoors. An adapter exposed to water or rain, or a very humid environment can cause damage to both the adapter and the product.
  • Page 14 Hearing Damage Warning To prevent possible hearing damage, do not listen at high volume levels for long periods.
  • Page 15 Technical Support Wasp’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact Wasp technical service. For more information, visit https://support.waspbarcode.com.
  • Page 16 The warranty period is varied from each country. Please consult with your supplier or Wasp local office for actual length of warranty period to your purchased product. Warranty becomes void if equipment is modified, improperly installed or used, damaged by accident or neglect, or if any parts are improperly installed or replaced by the user.

  • Page 17: Table Of Contents

    Table of Contents Preface ......................i Regulatory Compliance Statements .............. i Laser Information ..................vii LED Information ..................vii Battery Notice ....................x Adapter Notice....................x Hearing Damage Warning ................xi Worldwide Support ..................xii Warranty Policy ..................xiii Chapter 1 - Overview ................1 1.1 Package ....................
  • Page 18 Chapter 3 – Introduction to Applications ......... 55 3.1 USS (scan service) ................55 3.2 File Manager ..................59 3.3 Software Update ................... 60 3.4 StageGO ....................61 3.5 MoboLink ....................63...

  • Page 19: Regulatory Compliance Statements

    Wasp WDT950 (38 keys) User’s Manual Chapter 1 - Overview 1.1 Package Please make sure the following items are in the WDT950 box. If something is missing or damaged, please contact your Wasp representative. The basic package contents WDT950 ...

  • Page 20: Product Detail

    Wasp WDT950 (38 keys) User’s Manual 1.2 Product Detail ① ② ⑥ ③ ③ ④ ④ ⑨ ⑩ ⑤ Power Key ⑦ ⑦ ⑧ Scanner Window Receiver 13m Camera & LED Pogo pin Flashlight LED Indicator USB Type C Port...

  • Page 21: Specifications

    Wasp WDT950 (38 keys) User’s Manual 1.3 Specifications System Features Qcta-core 2.3 GHz, Qualcomm 720G (SM7125) Memory 4 GB RAM 64 GB Flash Expanded slot Micro SD/TF x 1 (maximum of 128 GB) Android Languages support English, Simplified Chinese, Traditional Chinese, Japanese, Spanish,...
  • Page 22 Wasp WDT950 (38 keys) User’s Manual Audio One speaker (8 ohm / 2W output), One receiver (32 ohm), MIC and Headset interface connect to Type-C connector Regulatory Approvals CE, RED, FCC, NCC, VCCI, TELEC, CCC, SRRC I/O Interfaces USB Type-C...
  • Page 23 Wasp WDT950 (38 keys) User’s Manual Weight 395g (with battery) Dimension 195 mm x 72 mm x 34 mm Environmental Operating Temperature -4°F to 122°F (-20°C to 50°C) Storage Temperature -22°F to 140°F (-30°C to 60°C) Charging Temperature 32°F to 113°F (0°C to 45°C)

  • Page 24: Getting Started

    Wasp WDT950 (38 keys) User’s Manual 1.4 Getting Started 1.4.1 Install / Remove the Battery Cover ￭ Install the battery pack and the battery cover Slide and position the battery pack, making sure the battery contacts are aligned with the contacts in the battery compartment.
  • Page 25 Wasp WDT950 (38 keys) User’s Manual ￭ Remove the battery cover and the battery There are two ways to remove the battery, the following is the first method. Make sure the battery release latch is in the unlocked position. Grab the battery cover from the two recesses and lift gently upward to remove the battery cover.
  • Page 26 Wasp WDT950 (38 keys) User’s Manual The second way to remove the battery is shown as follows: 1. Make sure the battery release latch is in the unlocked position. 2. Grab the battery cover from the two recesses and gently lift upward, stop when you feel a resistive force.
  • Page 27 It takes within 4 hours to charge the terminal with the cradle to full capacity. Connect the type C USB cable to the USB port on WDT950 and connect the other end of the USB cable to AC power adapter. Then plug into the electrical outlet.
  • Page 28 Wasp WDT950 (38 keys) User’s Manual 1.4.3 Turning on the terminal for the first time It is recommended to fully charge WDT950 before first use. You can now start up your device to set up the languages, WLAN setting, and date and time.
  • Page 29 Wasp WDT950 (38 keys) User’s Manual 1.4.5 Using the Micro SD/ Nano SIM Card The WDT950 has 1 x micro SD and 2 x nano SIM card slots inside the battery compartment. Note: Please TURN OFF the terminal, before inserting or removing micro SD card or nano SIM card.
  • Page 30 Wasp WDT950 (38 keys) User’s Manual SIM 1 Card Slot SIM 2 Card Slot Micro SD Card Slot SIM 1 & 2 Card Slot Push down SIM card holder to unlock and lift the card holder to insert SIM card.
  • Page 31 Storage to check the WDT950 storage. 1.4.6 Battery Status The WDT950 provides battery info for users to check the battery status, history view and also set up user preferences. On the main screen, scroll the screen from down to top to reach the APPS, Settings and then tap BatteryInfo.
  • Page 32 Wasp WDT950 (38 keys) User’s Manual 1.4.7 BatteryInfo Health Service BatteryInfo health service information will display on both WDT950 lock screen and the notification bar. ￭ When the battery health is higher than 80% : ￭ When the battery health is higher than 60%:...
  • Page 33 Wasp WDT950 (38 keys) User’s Manual ￭ When the battery health is lower than 60% : (Battery should be replaced) Note: If the battery is stored for the long term, it might result in accelerated battery health lower. Please try to charge and discharge your batteries several times and check the battery health is at a steady rate.
  • Page 34 Wasp WDT950 (38 keys) User’s Manual 1.4.8 How To Enable Dark Theme Dark mode is a feature that allows you to switch to the dark theme of an app or an entire desktop operating system. On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap Display.
  • Page 35 Wasp WDT950 (38 keys) User’s Manual 1.4.9 How To Enable Night Light Night Light is a feature that allows you to activate night light in order to reduce your eyestrain. On the main screen, scroll the screen from down to top to reach the APPS, and...

  • Page 36: Keypad Definition

    Wasp WDT950 (38 keys) User’s Manual 1.5 Keypad Definition Description Power key Press the yellow alpha key to access the alternate alpha characters. Toggle between numeric and alphabetic entry modes. The icon appears on the Status bar. Press and release the orange alpha key again to return to the default keypad functions.
  • Page 37 Wasp WDT950 (38 keys) User’s Manual Description Numeric/Alpha keys Press the yellow alpha key to access the alternate alpha characters. Toggle between numeric and alphabetic entry modes. Special function keys CTRL key Backspace key SHIFT key Enter key ALT key...
  • Page 38 Wasp WDT950 (38 keys) User’s Manual Description Produces a period symbol Produces a comma symbol...
  • Page 39 Wasp WDT950 (38 keys) User’s Manual 1.5.1 Using Keypad Combination Press the yellow key, it will appear as symbol in the status bar at the top of the screen. Then you can refer to the following table to execute the desired function or input.
  • Page 40 Wasp WDT950 (38 keys) User’s Manual Yellow Key + Key Left Arrow Up Arrow Down Arrow Right Arrow Space CTRL CTRL...
  • Page 41 Wasp WDT950 (38 keys) User’s Manual Yellow Key + Key...

  • Page 42: Chapter 2 - Installation & Operation

    Wasp WDT950 (38 keys) User’s Manual Chapter 2 – Installation & Operation 2.1 Barcode Setting On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap USS (scan service). Or from the notification bar tap USS (scan service).
  • Page 43 Wasp WDT950 (38 keys) User’s Manual 2.1.1 Settings on the screen to see all the settings of USS. Please tap...
  • Page 44 Wasp WDT950 (38 keys) User’s Manual 2.1.2 Barcode Scan Please tap Start Scan to get ready for barcodes scan service. For Save / Load Settings, and Factory Default, Please tap and then tap Save / Load Settings, and Factory Default.
  • Page 45 Wasp WDT950 (38 keys) User’s Manual To save settings, you can also tap Save on the screen and input path then tap OK. The saved data is stored in File Manager. (Please see 3.2 File Manager...

  • Page 46: Hf Setting

    Wasp WDT950 (38 keys) User’s Manual 2.2 HF Setting On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap Connected devices. Tap Connection Preferences to enable NFC...
  • Page 47 Wasp WDT950 (38 keys) User’s Manual Make sure that both devices are unlocked and have NFC turned on. Also make sure that the NFC antenna area of WDT950 and the other devices' NFC area are close to one another. Slightly moving the phones...

  • Page 48: Wwan Setting

    Wasp WDT950 (38 keys) User’s Manual 2.3 WWAN Setting 1. Turn off the terminal to insert the SIM card. Note : For the instruction, please refer to 1.4.5 Using the Micro SD/ Nano SIM Card. ￭ 2. Turn on the terminal, 4G signal will show at the top of the screen.
  • Page 49 Wasp WDT950 (38 keys) User’s Manual Tap Mobile network for more network settings. To choose different network type, please tap Preferred network type.

  • Page 50: Wlan Setting

    Wasp WDT950 (38 keys) User’s Manual 2.4 WLAN Setting On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap Network & internet. To see available networks, turn WLAN ON. And tap to choose the...
  • Page 51 Wasp WDT950 (38 keys) User’s Manual Choose the available networks, and enter the Password and tap Connect. If the wireless network that you want is not listed, tap + Add network to manually add it. When enabled, the icon is displayed on the status bar.
  • Page 52 Wasp WDT950 (38 keys) User’s Manual 2.5.1 WLAN Advanced WLAN advanced can enhance the roaming behavior when the device is in areas of particularly low coverage or losing its connection to the network infrastructure and provides the power save mode to control the power consumption setting.
  • Page 53 Wasp WDT950 (38 keys) User’s Manual ● Power Save Mode Tap to enable the power save mode to set the WLAN module to its optimum power consumption setting. ● Roaming Trigger (Default : -76 dBm, Range : -10 dBm ~ - 120 dBm) Roaming trigger will help users to look for a better and stronger signal strength (in dBm) by scanning many access points.
  • Page 54 Wasp WDT950 (38 keys) User’s Manual 2.5.1.1 Other options for more options to import / export the current data from the device. Initialize can restore the default settings.

  • Page 55: Pan Setting

    Wasp WDT950 (38 keys) User’s Manual 2.6 PAN Setting On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap Connected devices. Tap Connection Preferences to enable Bluetooth Tap ON / OFF to enable / disable Bluetooth ®...

  • Page 56: Gps Setting

    Wasp WDT950 (38 keys) User’s Manual 2.7 GPS Setting On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap Location. Tap the bar for the permission to use your location information.

  • Page 57: Pc Setting

    Wasp WDT950 (38 keys) User’s Manual 2.8 PC Setting Connect WDT950 to your computer with the USB type C cable. Your computer will recognize it is USB charging. Slide down from top, the system will show the following picture, then you can...

  • Page 58: Camera Setting

    Wasp WDT950 (38 keys) User’s Manual 2.9 Camera Setting Scroll the screen from down to top to reach the APPS, and tap Camera. 13m Camera & LED Flashlight 2.9.1 Camera Settings For the first time turn on, the screen will show a brief introduction about...
  • Page 59 Wasp WDT950 (38 keys) User’s Manual 2.9.2 Scene Mode Setting 2.9.3 Camera filter effects...
  • Page 60 Wasp WDT950 (38 keys) User’s Manual 2.9.4 Settings Please tap to enter the settings section.
  • Page 61 Wasp WDT950 (38 keys) User’s Manual 2.9.5 Record Videos Once tap the record button, it will start recording.

  • Page 62: Performing A Hardware Reset

    Wasp WDT950 (38 keys) User’s Manual 2.10 Performing a Hardware Reset You may have to perform a reset if the device freezes (i.e., the terminal no longer responds to the buttons or tapping on the screen). Long press and hold the Power button around 10 seconds to shut down the...

  • Page 63: Performing Factory Data Reset

    Wasp WDT950 (38 keys) User’s Manual 2.11 Performing Factory data reset 1. On the main screen, scroll the screen from down to top to reach the APPS, Settings and then tap System. and tap 2. Tap Advanced for more options, and then tap Reset options.
  • Page 64 Wasp WDT950 (38 keys) User’s Manual 3. You can reset the system on Reset options. When you select Erase all data (factory reset), it will erase all folders.

  • Page 65: Keyremap

    Wasp WDT950 (38 keys) User’s Manual 2.12 KeyRemap The WDT950’s keys can be programmed for users to be able to perform different functions or applications. Six options to use key remap functions: SCAN_LEFT, SCAN_RIGHT, SCAN_KEY, PROG_1, PROG_2 and TRIGGER_GUN 2.12.1 Remap a key On the main screen, scroll the screen from down to top to reach the APPS, and KeyRemap.
  • Page 66 Wasp WDT950 (38 keys) User’s Manual 2.12.2 Export / Import a remap Key Configuration file ￭ Export file 1. Tap 2. Select Export The remap Key configuration can be exported to a text file or imported into WDT950. Note: The configuration file (keys_config.txt)
  • Page 67 Wasp WDT950 (38 keys) User’s Manual ￭ Import file Before importing the file, please make sure the configuration file (keys_config.txt) is in File Manager. 1. Tap 2. Select Import ￭ Reset all settings 1. Tap 2. Select Reset all settings...

  • Page 68: Split Screen

    Wasp WDT950 (38 keys) User’s Manual 2.13 Split Screen Split screen function allows you to have two apps work side by side on the same screen. Please follow the steps to enable split screen multitasking. Note: Some apps may not work with split-screen.
  • Page 69 Wasp WDT950 (38 keys) User’s Manual 2. Tap and hold the thumbnail and then select “Split screen.” First APP “Split screen” will be on top of the screen. For another APP to show on the bottom half of the screen, simply tap on the APP thumbnail.

  • Page 70: Network Time Protocol (Ntp) Server

    Wasp WDT950 (38 keys) User’s Manual 2.14 Network Time Protocol (NTP) Server The Network Time Protocol is used to synchronize the clocks over the Internet. Allow the users to set the clock by using NTP Server. 1. On the main screen, scroll the screen from down to top to reach the APPS,...
  • Page 71 Wasp WDT950 (38 keys) User’s Manual 2. On NTP Server, choose the system preferences to set up network time.

  • Page 72: Battery Swap

    Wasp WDT950 (38 keys) User’s Manual 2.15 Battery Swap Please follow the steps for the battery swap. When the battery release latch switches to the unlocked position, the screen will show the countdown window (within 59 secs) for the users to change the battery.

  • Page 73: Chapter 3 - Introduction To Applications

    Wasp WDT950 (38 keys) User’s Manual Chapter 3 – Introduction to Applications 3.1 USS (scan service) On the main screen, scroll the screen from down to top to reach the APPS, and tap Settings and then tap USS (scan service).
  • Page 74 Wasp WDT950 (38 keys) User’s Manual 3.1.1 How to scan There are 3 ways to scan the barcodes: Trigger keys on the sides, Scan key on the keyboard or tap Start Scan on this App. Aim the Barcode Scan Engine to the barcode.
  • Page 75 Wasp WDT950 (38 keys) User’s Manual 3.1.2 Multi Decode Scan Mode Multi decode scan function allows users to scan multiple barcodes at once. , Choose Scanner Settings 2. Enable Multi Decode Mode, and input the barcode decode count (up to 10...
  • Page 76 Wasp WDT950 (38 keys) User’s Manual 3.1.3 Picklist Mode Picklist mode enables WDT950 to decode only barcodes that are aligned under the laser crosshair or LED aiming dot. For picklist mode demonstration, please click on the this YouTube channel for more information: https://www.youtube.com/watch?v=QjT2E6hxD_k...

  • Page 77: File Manager

    Wasp WDT950 (38 keys) User’s Manual 3.2 File Manager On the main screen, scroll the screen from down to top to reach the APPS, and File Manager. : Settings : Return to the previous page : Main page : Refresh...

  • Page 78: Software Update

    Wasp WDT950 (38 keys) User’s Manual 3.3 Software Update On the main screen, scroll the screen from down to top to reach the APPS, and tap Software Update. To update or check the latest version of each application, please tap CHECK UPDATE.

  • Page 79: Stagego

    Wasp WDT950 (38 keys) User’s Manual 3.4 StageGO StageGO is a configuration staging solution for Wasp mobile devices. StageGO helps IT admins use the 1-click auto configure feature to set up and initialize a device quickly. Devices configure themselves by using configuration scripts and barcodes prepared by the IT admins, the StageGO app, currently available for Android devices, uses Wasp devices’...
  • Page 80 Wasp WDT950 (38 keys) User’s Manual Step 3. Scan Barcodes: When device users receive the barcode printouts (or the script file) from the IT admins, they can then run the StageGO app on the terminals, scan all the barcodes on the printouts (or load the script file). When all barcodes are scanned, StageGO is ready to begin self-configuration.

  • Page 81: Mobolink

    Wasp WDT950 (38 keys) User’s Manual 3.5 MoboLink MoboLink is a software platform that helps customers to remote manage their purchased devices and applications. The core of the MoboLink platform provides functionalities in the MDM (Mobile Device Management) and MAM...
