Contents Overview What's in this Guide Features A Quick Look at the Camera Front of the Camera Connector Panel Installation Don’t Void Your Warranty! Before You Install the Camera Cabling Notes Pre-Installation Functional Check Getting the Camera's IP Address If the Camera Is At 169.254.1.1 Status Light Installing the Wall Mount Basic Connections...
Page 3
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Auto-framing Adjustment Quick Reference Managing Audio Other Audio Settings and Adjustments About Echo Cancellation Configuring Streaming Behavior Viewing the USB Stream Configuring USB Streaming Enabling or Disabling IP Streaming Viewing the IP Stream (RTSP) RTSP Streaming Protocol and URL Setting up IP Streaming in Easy Mode Customizing IP Streaming Settings...
Page 4
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Querying for More Information Typographical Conventions Autoframer Commands autoframer enabled autoframer paused autoframer default-wide autoframer buffer-zone autoframer shot-margin autoframer sensitivity autoframer responsiveness autoframer initial-persistence autoframer persistence autoframer max-electronic-zoom autoframer noise-threshold autoframer tri-sync-motion autoframer forced-wait-time Camera and Video Management Commands camera home...
Page 5
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Telnet Information and Session Management Commands history help exit Troubleshooting and Care Power and Control Video and Streaming Audio Status Light Restoring Default Camera Settings Operation, Storage, and Care Glossary Photo Credits Index...
Overview This guide covers: ® ConferenceSHOT ePTZ auto-framing camera: North America – 999-21050-000 Europe and UK – 999-21050-001 Australia and New Zealand – 999-21050-009 What's in this Guide This guide covers Physical features Installation Initial set-up and system administration Performance/behavior configuration System maintenance Operation Telnet API reference...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera A Quick Look at the Camera This section covers the physical features of the camera. Front of the Camera Camera and zoom lens – Up to 5x zoom. Integrated microphone – No external microphone needed in typical installations. Echo-canceling microphone picks up the voices of participants up to 10 ft.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Connector Panel The connectors are on the underside of the camera. PoE+ – RJ-45 connector. Connect to the network and to power via the Power and Data Out port of the mid-span PoE+ power injector. Provides power and network access for IP streaming and camera control via web interface or Telnet.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Installation This section covers: Selecting the location for the camera Verifying that the camera is ready to install Installing the mount Connection diagrams Mounting the camera And a required safety note here: Note PoE type networks connected to this equipment are for intra-building use only and should not be connected to lines that run outside of the building in which this product is located.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Pre-Installation Functional Check If you're installing the camera where it's hard to reach, you may want to verify functionality before you install it. 1. Connect the camera in its minimum functional configuration. 2.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Status Light The light in the camera's head indicates its current state. Purple – Initializing White – Active Red – Audio is muted Blinking red – Video is muted Yellow – Firmware update is in progress Blinking cyan –...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Installing the Camera and Connecting Power Caution Check your cables. Connecting a cable to the wrong port or using the wrong pin-out can result in equipment damage and will void the warranty. 1.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Initial Device Set-Up Vaddio cameras have a web interface for initial device set-up, administrative control, and operation. When any Vaddio product is shipped from the factory, the admin password is not set and the administrative controls are not available.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Initial Device Set-Up Using the Vaddio Deployment Tool The Vaddio Deployment Tool provides an option to do the initial device set-up for unprovisioned devices, and provides a shortcut to each device's web interface for system administration. This tool is available as a free download at https://info.legrandav.com/VaddioDeploymentTool.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Manual Access and Initial Device Set-Up If you do not use a Vaddio Device Controller or the Vaddio Deployment Tool, you will need to complete the initial device set-up manually, by browsing to the device's web interface using its IP address. See Getting the Camera's IP Address.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera System Administration This chapter covers settings for managing the camera as an element of your network. Security – Passwords, guest access, other IT security-related settings Network configuration Time settings Configuring Camera Behavior for information on image adjustments, streaming configuration, and other items related to camera behavior.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Configuring the Camera for Your Network By default, the camera is set to DHCP, and will receive an IP address automatically if your network assigns IP addresses. Work with your network specialist to ensure that the camera is configured to comply with the organization's network policies.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Changing the Camera's Hostname ETWORKING PAGE If your network supports hostname resolution, you can browse to the camera using its hostname. Giving it a simple, easy-to-remember hostname means you don't need to know its IP address. Work with your IT department to ensure that the new hostname conforms to the organization's naming conventions.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Configuring Camera Behavior This chapter covers settings for defining how the camera performs in your environment: Auto-framing adjustments Streaming Manual-mode settings and adjustments – presets, color and lighting, speed, focus Audio adjustments Other camera settings Note Vaddio products are designed with very similar web interfaces.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera How It Works: Auto-framing Auto-framing uses digital pan, tilt, and zoom to center the source of motion, so the image is almost always zoomed in at least slightly. Vaddio‘s Auto-framing is based on motion detection. It won't mistake pictures for people, it still works if you turn away from the camera, and you don't have to wear a special device.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Basic Auto-framing Adjustments FRAMING PAGE When making adjustments, compare the Visualizer's image to the video output. Auto-framing Presets – Factory configurations. "Conservative" settings are less sensitive and track at lower speeds than "responsive" settings. Select the one closest to the room's requirements, then make other adjustments if needed.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Persistence – How long the camera remembers motion and stays on its source after other trackable motion starts. Typically 25% to 100% for conferencing, below 15% for lecture capture. Shot Margin – Controls how tight or wide the shot will be around the people in the camera's field of view. A high value will result in a wider shot and a low value results in a tighter shot around the person or group of people.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Advanced Auto-framing Adjustments FRAMING PAGE Max Electronic Zoom – Sets the default size of the frame relative to the area defined by Optical Zoom. Default value is 3x for all Auto-framing presets. Initial Persistence –...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Auto-framing Adjustment Quick Reference Set Optical Zoom and select the Auto-framing preset that is most similar to the room's requirements. Then adjust Auto-framing to meet the unique demands of your space. These tables may help. Not Responding Enough To correct this Do this...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Managing Audio UDIO PAGE Controls for individual inputs (audio from your site) and outputs (audio from the far end of the conference) are on separate tabs. To mute all audio inputs together: To stop sending audio, use the audio mute button at the top of any page of the web interface.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera To sync the sound with the video in the IP stream: On the Outputs tab, check the Delay box and enter a delay value in milliseconds. About Echo Cancellation When a microphone picks up the audio from a speaker (far-end audio) during a conference, it sends the far-end audio back to the participants at the far end, creating an echo.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Configuring Streaming Behavior Conferencing applications use USB streaming. After initial device set-up is complete, the camera's USB stream is always enabled. IP streaming is disabled by default. Notes The screen shots in this section are representative, and may differ from what you see. Some may refer to other Vaddio products.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Enabling or Disabling IP Streaming TREAMING PAGE IP streaming is disabled by default. Two IP streaming protocols are available: RTSP streaming delivers an IP stream that people can access from your network using a media player.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera RTSP Streaming Protocol and URL TREAMING PAGE When IP streaming is enabled and RTSP is selected, the RTSP stream is automatically available. Consult your IT department before changing these settings. RTSP port: Vaddio strongly recommends using the default RTSP port number. Path: The portion of the streaming URL that appears after the IP address.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Setting up IP Streaming in Easy Mode TREAMING PAGE Note Consult your network specialist when setting up IP streaming, to be sure that you select settings that are appropriate for the network. If you are not sure about these settings, start with the defaults. 1.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Configuring RTMP Streaming TREAMING PAGE To use RTMP streaming, you must have an account with a streaming service. To configure an RTMP streaming service: 1. Select RTMP streaming, then select Settings. 2. Expand the information box for the service. 3.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Configuring Manual Mode Behaviors Although Auto-framing mode is normally used with this camera, there are times when you need conventional PTZ behaviors. This section covers: Preset shots Speed controls Direction controls These settings are on the Camera page of the web interface. Setting the Home Position and Other Preset Shots AMERA PAGE Although the camera's Auto-framing feature is the simplest way to keep the focus on the presenter, there...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Renaming Presets AMERA PAGE You can rename presets to identify them. This also helps you identify and avoid overwriting them when you store new ones. Right-click the button for the preset or custom scene, and edit the label. Speed Adjustments AMERA PAGE The following speed adjustments are available:...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Adjusting Color, Lighting, and Image Quality Settings AMERA PAGE No two rooms are exactly alike – but a lot of rooms are a lot alike. The technical folks at Vaddio (Scott, to be specific) have already set up adjustments for common lighting scenarios (CCU scenes) –...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Lighting and Image Quality Quick Reference Here are some tips for using the CCU settings for lighting and image quality. What do you need to correct? Make this adjustment: The image is too dark Increase Iris (lower F-stop value) Increase Iris Gain The image looks washed out or faded...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Additional Camera Settings YSTEM PAGE ENERAL TAB Additional settings are available on the General tab on the System page. LED On – In most cases, Vaddio recommends leaving the status lights on, to let people in the room know whether the camera is currently sending video.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera System Maintenance This chapter covers tasks for keeping your system up-to-date and operating properly: Rebooting Backing up and restoring the camera configuration Installing firmware updates Getting help Note Vaddio products are designed with very similar web interfaces. Some of the screen shots in this manual may be from other cameras.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Installing a Firmware Update YSTEM PAGE IRMWARE TAB Caution Be sure the camera stays connected to power and to the network during the update. Interrupting the update could make it unusable. 1. Read the release notes and download the firmware update file from the product's web page at www.legrandav.com.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Contacting Vaddio Technical Support and Viewing Diagnostic Logs ELP PAGE IAGNOSTICS PAGE If you can't resolve an issue using your troubleshooting skills (or the Troubleshooting tables in this manual), we are here to help. You’ll find information for contacting Vaddio Technical Support on the Help screen.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Operating the Camera When you need to control the camera in manual mode rather than using Auto-framing, you can use The remote The web interface (accessible from your computer's browser or using a Vaddio Device Controller) A third-party control device When you use the directional controls or stored presets for framing the shot, Auto-framing pauses.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Moving the Camera Use the arrow buttons for camera pan and tilt. The center button moves the camera to the home position. Zooming In or Out Use the Zoom + button to zoom in and the Zoom – button to zoom out. Moving the Camera to a Preset Position Use the Preset buttons (if available) to move the camera to any of its programmed positions.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Using the Remote Control The remote provides basic camera control. Some additional functionality is available from the web interface. Button(s) What do you need to do? Power on or standby Power (green button at top right) Change the speaker volume Volume buttons (center left) Mute the microphone(s)
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Telnet Serial Command API The Vaddio Telnet command API allows an external device such as an AMX or Crestron presentation system to control the camera. It is also used for writing macros. Requirements Telnet must be enabled on the Security page of the device's web interface.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Autoframer Commands Commands to manage and adjust Auto-framing fall roughly into three categories. Status commands: autoframer enabled autoframer paused Shot definition commands: camera optical-zoom autoframer shot-margin autoframer max-electronic-zoom autoframer buffer-zone Auto-framing behavior adjustment commands: autoframer sensitivity autoframer responsiveness autoframer initial-persistence...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera autoframer paused Pause or resume Auto-framing. Auto-framing pauses automatically when the camera receives a pan, tilt, zoom, or preset recall command from any source. Synopsis autoframer paused { get | off | on | toggle } Options Returns the pause state for Auto-framing.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera autoframer buffer-zone Get or set the size of the Auto-framing buffer zone. Synopsis autoframer buffer-zone { get | set <value> } Options Returns the current value for the Auto-framing buffer zone. set <value> Sets the Auto-framing buffer zone.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera autoframer sensitivity Get or set Auto-framing sensitivity. Synopsis autoframer sensitivity { get | set <value> } Options Returns the current value for sensitivity. set <value> Sets Auto-framing sensitivity. >autoframer sensitivity set 95 Examples >...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera autoframer initial-persistence Get or set the initial persistence value. Synopsis autoframer initial-persistence { get | set <value> } Options Returns the current value for initial persistence. set <value> Sets initial persistence. >autoframer initial-persistence set 15 Examples >...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera autoframer max-electronic-zoom Get or set the value for the Auto-framing maximum electronic zoom. This limits how far the camera zooms in for Auto-framing. Synopsis autoframer max-electronic-zoom { get | set <value> } Options Returns the current value for the maximum electronic zoom.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera autoframer tri-sync-motion Enable or disable Tri-Sync Motion. This allows the camera to pan, tilt, and zoom smoothly. When Tri- Sync Motion is off, the camera snaps to the new position. Synopsis autoframer tri-sync-motion { get | off | on | toggle } Options Returns the current state for Tri-Sync Motion.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Camera and Video Management Commands The following camera and video management commands are available: camera home camera pan camera tilt camera zoom camera ptz-position camera preset camera ccu get camera ccu set camera led video mute camera home...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera camera pan Moves the shot horizontally. The amount of pan available depends on the zoom level. (See How It Works: Digital Pan/Tilt/Zoom.) Auto-framing pauses when the camera receives this command. Synopsis camera pan { { left [<speed>] [no_wait] } | { right [<speed>] [no_wait] } | stop | get | { set <position>...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera camera tilt Moves the shot vertically. The amount of tilt available depends on the zoom level. (See How It Works: Digital Pan/Tilt/Zoom.) Auto-framing pauses when the camera receives this command. Synopsis camera tilt { { up [<speed>] [no_wait] } | {down [<speed>] [no_wait] } | stop | get | { set <position>...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera camera zoom Moves the camera in toward the subject or out away from the subject. Auto-framing pauses when the camera receives this command. Synopsis camera zoom { in [<speed>] | out [<speed>] | stop | get | set <position> [<speed>] [no_ wait] } Options Zooms the camera in.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera camera ptz-position Specifies a shot by zoom and pan/tilt coordinates. The amount of pan and tilt available depend on the zoom level. (See How It Works: Digital Pan/Tilt/Zoom.) Pan, tilt, and zoom may be specified in any order. Auto-framing pauses when the camera receives this command.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera camera preset Moves the camera to the specified preset, or stores the current camera position and type of motion to use, optionally including color and lighting information. Synopsis camera preset { recall <1 - 16> | store <1 - 16> [tri-sync <1 - 24>] [save-ccu] } Options recall <1 - 16>] Moves the camera to the specified preset.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera camera ccu set Sets the specified CCU (lighting) information. Synopsis camera ccu set <param> <value> auto_white_balance Options Sets auto white balance on or off. red_gain Sets the red gain value (integer). blue_gain Sets the blue gain value (integer).
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera video mute Gets or sets the camera's video mute status. When video is muted, the camera sends blue or black video with an on-screen message stating that video mute is on. This can be desirable when preparing the room, or when privacy is needed.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Audio Commands The following audio commands are available: audio volume audio mute audio echo-cancel audio volume Gets or sets the volume of the specified audio channel. Synopsis audio < channel > volume { get | up | down } internal_mic Channels The built-in microphone.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera audio mute Gets or sets the mute status of the specified audio channel. Synopsis audio < channel > mute { get | on | off | toggle } master Channels Applies the command to all audio channels. internal_mic The built-in microphone.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera audio echo-cancel Gets or sets the echo cancellation status of the specified audio channel. On this camera, echo cancellation is available for the internal microphone only. Synopsis audio < channel > echo-cancel { get | on | off | toggle } internal_mic Channels The built-in microphone.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Network and Communication Commands The following communication-related commands are available: network settings get streaming ip enable streaming settings get network settings get Returns the camera's current network settings and MAC address. The default hostname includes the model name of the camera;...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera streaming settings get Returns current IP and USB streaming settings. The default RTSP URL includes the model name of the camera; the example is from an IntelliSHOT camera. Synopsis streaming settings get USB Active Parameters True if a USB stream is present.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Maintenance and Troubleshooting Commands The following commands are available for maintenance and troubleshooting: version network ping system reboot system factory-reset version Returns the current firmware version. "System version" may show a product family name or more than one product name, as multiple products sometimes use the same firmware.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera system reboot Reboots the system either immediately or after the specified delay. Note that a reboot is required when resetting the system to factory defaults (system factory-reset). The reboot message includes the model name of the camera;...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Telnet Information and Session Management Commands The following commands are available for Telnet help and session management: history help exit history Returns the most recently issued commands from the current Telnet session. Since many of the programs read user input a line at a time, the command history is used to keep track of these lines and recall historic information.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Troubleshooting and Care When the camera doesn't behave as you expect, check the status lights on the front before you do anything else. See Status Lights. Note If the symptoms suggest even the smallest possibility of a bad cable, please try a known good cable. Factory-made cables can be defective.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Video and Streaming What is it doing? Possible causes Check and correct No IP stream. IP streaming is not enabled. Enable IP streaming: Streaming page in the web interface. No USB stream. The USB cable is not Connect the USB cable.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Status Light The light in the camera's head indicates its current state. Purple – Initializing White – Active Red – Audio is muted Blinking red – Video is muted Yellow – Firmware update is in progress Blinking cyan –...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Operation, Storage, and Care For smears or smudges on the product, wipe with a clean, soft cloth. Use a lens cleaner on the lens. Do not use any abrasive chemicals. Keep this device away from food and liquids. Do not operate or store the device under any of the following conditions: Temperatures above 104°...
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Glossary Acoustic echo cancellation. Audio processing that subtracts the far-end (speaker) audio from the sound that your microphone picks up. auto white balance A setting that allows the camera to manage color adjustments automatically. Autoframing Vaddio's motion-based technology for automatically keeping the camera on the action.
Page 72
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Field of View (FOV) How wide the video image is. Vaddio measures horizontal field of view. Some manufacturers use diagonal field of view, which yields a bigger number for the same actual image area. Tilt your head to one side and diagonal FOV will make sense.
Page 73
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Microphone. Pronounced "mike" because the etymology matters more than English pronunciation rules, which are inconsistent anyway. Maximum Transmission Unit. The largest number of bytes allowed in a packet. If you don't know what that means, don't change MTU size.
Page 74
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera SSL certificate A file used with HTTPS proving that a web page really originates from its purported source. If you enable or require HTTPS on a camera or other device without installing an SSL certificate, your browser will pop up security warnings when you try to browse to the device's web interface.
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Photo Credits This guide may include some of these photos. European Space Agency (ESA) astronaut Samantha Cristoforetti, a Flight Engineer with Expedition 42, photographs the Earth through a window in the Cupola on the International Space Station By NASA - https://blogs.nasa.gov/ISS_Science_Blog/2015/03/06/women-in-space-part-two-whats- gender-got-to-do-with-it/, Public Domain, https://commons.wikimedia.org/w/index.php?curid=38834990 Carl Sagan, Bruce Murray, Louis Friedman (founders) and Harry Ashmore (advisor), on the occasion of...
camera mount 4, 6 camera placement 4 Index camera select 37 camera standby position 36 capabilities 1 CCU scenes 28 admin password 10-11 custom 28 changing 11 CCU settings 27, 29-30, 51-52 initial 10 adjusting 30 AEC 6, 20-21 in the web interface 29 anatomy of the camera 2 storing with a preset 27, 51 audio 20-21, 37, 54-56...
Page 77
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera internal microphone 56 inverted installation 7 IP address 5, 12, 37 factory defaults, restoring 60, 64 default 5, 12-13 fault isolation 59, 62 static, configuring 12 firmware update 33 IP streaming 22-26, 57-58 firmware version 59 enabling/disabling 23 Forced Wait Time (Autoframing setting) 18,...
Page 78
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera Networking page (web) 13 quick reference 30, 37 Noise Threshold (Autoframing setting) 16, remote control 37 NTP server 13 ready state 36, 53 rebooting 33, 60 One Push White Balance 30 red gain 29-30, 51-52 operating environment 4, 65 remote control 37 Optical Zoom (Autoframing setting) 16...
Page 79
Complete Manual for the ConferenceSHOT ePTZ Auto-Framing Camera standby (low-power) state 36, 52-53 USB streaming 22, 58 static IP address 12 configuring 22 status light 6, 31, 52, 64 settings 58 behavior 31, 52 user password 11 meanings of colors 6, 64 storage environment 65 Vaddio Deployment Tool 8-9 storing a configuration 32...
Page 80
Fax +1.763.971.4464 · Email av.vaddio.support@legrand.com Vaddio is a registered trademark of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending.
