Operating Instruction
MMO
High Pressure Centrifugal Pump
PT. TORISHIMA GUNA INDONESIA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MMO and is the answer not in the manual?

Questions and answers

Related Manuals for Torishima Pump MMO

Summary of Contents for Torishima Pump MMO

  • Page 1 Operating Instruction High Pressure Centrifugal Pump PT. TORISHIMA GUNA INDONESIA...

  • Page 2: Name Plate

    0. General 0. 1. Before Starting Initial Operation If installed properly and operated correctly, the pump can perform its specific performance in satisfactory condition throughout a long term. Before putting the pump into initial operation, carefully read this Instruction Manual to handle, operate, and maintain the pump properly.
  • Page 3 1. Instalation 1. 1. Mounting Installation and leveling of the pump should be performed by skilled workers. Improper installation and leveling/ centering would cause various troubles during the pump running. In the case of the pump directly coupled to the driver on the common baseplate, the pump set is shipped after completely levelled and centered at our fabrication shop.

  • Page 4: Connecting The Piping

    1. 2. Alignment of pump and driver The pump shaft and the driver shaft ( motor shaft ) must be centered in line. Follow the sequence given below for the leveling and centering work. (1) Centering and leveling can be performed easily by holding a straightedge on the flange top of the coupling set and inserting a wedge gauge between two coupling halves, as illustrated in Fig.

  • Page 5: Startup And Shutdown

    2. Start-up and Shut-down 2. 1. Start-up (1) Before starting the initial operation after installation, observe the following check items and, if anything abnormal is found, take necessary corrective action in accordance with this Manual. Are the pump and the suction pipe filled up with pumping liquid ? Is the driver's rotating direction correct ? (Pump rotates clockwise viewing from the driver's side) No abnormal in the direct coupling ? No abnormal load to the pump by piping ?

  • Page 6: Dismantling And Reassembling

    Are the both suction pipe and pump filled up with pumping liquid or the discharge valve fully opened in the pump running ? Is the bearing temperature normal ? ( no abnormal temperature rise ? ) Is leakage from the gland proper ? Is the pump running with no abnormal noise and no vibration ? 2.
  • Page 7 Also, keep all the overhauled parts in order of overhaul so as to smooth the reassembling work without any error. Remove any small pipings if any. Remove the coupling guard. Remove the coupling bolts and then remove the prime mover from the common baseplate. Pull out the pump side coupling half from the pump shaft.
  • Page 8 (3) Take good care not to damage each O-ring and the sealed contact surface of each parts. (4) When replacing the rotating assembly ( shaft, impeller, sleeve ), determine the dimension ( Y-X ) of the casing side spacer ring in the discharge side bearing housing in accordance with the procedure shown in Fig.

  • Page 9: Spare Parts

    3. 5. Spare Parts 3. 5. 1. Order for spare parts When ordering spare parts, let us have the following information without fail. • Pump type No. and size • Manufacturing No. ( These numbers are identified on the name plate attached to the pump ) •...

  • Page 10: Mechanical Seal

    Part No. Part Designation Part No. Part Designation Part No. Part Designation 1060 Suction casing 4120.2 O-ring 9021 Gland bolt 1070 Discharge casing 4520 Stuffing box gland 9050 Tie bolt 1080 Stage casing 4580 Lantern ring 9200.1 Hex. nut 1711 Final stage diffuser 4610 Stuffing box packing...
  • Page 11 4. 3. Dismantling 4. 3. 1. Dismantling Procedure Refer to paragraph. 3.2 for the pump dismantling procedure. The mechanical seal shall be dismantled from one side and then to other side. The dismantling sequence hereunder is subject to completion of dismantling the bearing housing unit.

  • Page 12: Troubleshooting

    (a) Apply oil coating in small quantity to O-ring ( 4120. 4 ). (b) Pay attention to the coiling direction of spring ( 4770 ). Viewing from the suction side, the right- hand coiled spring is for the suction side use and the left hand coiled one for the discharge side use.
  • Page 13 all the suction line valves are kept fully opened. In addition, inspect the suction pipe to check for poor fluid flow or great flow resistance. Clean well the strainer if provided. 5. Reverse rotational direction. Interchange the wiring connection to the motor terminal. Should the pump rotate reversely, check the packing sleeve and retighten it as necessary.
  • Page 14 5. 4. Leak from pump ( leak from other than gland ) Possible Cause Remedy / Corrective Action 1. Insufficient tightening torque of mounting Retighten them with uniform tightening torque after complete bolts. shutdown internal pressure drop and complete cool-down of the pump.
  • Page 15 MEMO...
  • Page 16 TORISHIMA PUMP MFG.CO.,LTD. Head Office & Works : 1−1−8, Miyata−cho, Takatsuki City, Osaka, Japan. Phone : 0726−95−0551 Telex : 5336568 TORIPUJ Telefax: 0726−93−1288 TORISHIMA SINGAPORE TORISHIMA SINGAPORE PTE.LTD. 30 Ubi Crescent # 01 ˘ 02 Ubi Tech Park Singapore 408566 Phone : (65)67790123 Fax : (65) 67796900...
