Tools Required:
Screwdriver, plyers, or small wrench.
Parts Included:
A
B
2pcs Large Grids
G
1pc Base Grid
Note:
Plastic clips can be snapped on easily by hand but
pliers may be necessary for removal. Most grid sections
require only 2 clips per side for support. For safety, clips
attached on exterior of cart should be positioned with
flanges facing inward.
Clip Attachment
See reverse side for assembly
Wire Bin Roll File
Assembly Instructions
C
2pcs L-Shaped
1pc Large
Side Grids
Grid Divider
H
4pcs Caster Assemblies
(16 Screws, Nuts)
D
1pc Small
Grid Divider
J
K
45pcs Small
Plastic Clips
For model WRF34
F
E
1pc Outer
Support Frame
L
1pc Dust Protector
3pcs Large
Plastic Clips
Bottom Cover
Assembled Rack
1pc Face Grid
