- Page 1 User Manual AW5145W Wireless Temperature & Humidity Transmitter AW5145W User Manual - 1 -...
-
Page 2: Product Overview
User Manual AW5145W 1 Product Overview The AW5145W is a new type of temperature and humidity transmitter, using high quality digital capacitive sensor of the company's exclusive research and development. The AW5145W has the special feature of high measurement precision, strong anti-jamming capability, as well as the characteristics of strong stability, which guarantees excellent performance measurement of the products. - Page 3 User Manual AW5145W 2.1 Relative Humidity (%RH) Parameter Condition Typ. Units Resolution Measuring range 99.9 Drift Typical %RH/yr Response time 2.2 Temperature (℃) Parameter Condition Typ. Units Resolution ℃ Operating range ±0.5 ℃ Drift Typical ℃/yr Response time 2.3 Other specifications 1) Power consumption: ≤50mA（24V）...
- Page 4 User Manual AW5145W 3 Dimensions Figure 1 Dimension (Units: mm) 4 Panel Schematic and Product Installation 4.1 Panel Schematic Antenna MENU DOWN Internal probe Figure 2 Panel schematic introduction Note: 1 OK Key: Enter 2 MENU Key: Manual 3 UP Key: UP Selection www.aosong.com...
-
Page 5: System Setup Menu
User Manual AW5145W 4 DOWN Key: Down sDelection 4.2 Installation 1 Paste the plotting sheet in the desired position of the product before installation. 2 Follow the position of the plotting sheet, and drill a fixed hole, then use two M4 screws (supplied in the attachment) to fix on the wall. - Page 6 5.3.1 Router Configure Transmitter can connect to the router when successfully obtained the SSID and password of the router by "AOSONG cloud platform APP". Then the transmitter can connect to the Internet. There are two ways to configure the router, "get IP address automatically" and "set IP address manually".
- Page 7 User Manual AW5145W Figure 6 Configuration 4)After the configuration is successful, the transmitter prompts "Config Success". If the configuration is not successful in 5 minutes, the transmitter will prompt "Config timeout, press OK restart". Press "MENU" to return to the previous menu when configuration is successful.
- Page 8 User Manual AW5145W "192.168.001.010".The value"192" is displayed in highlight state. Press "OK" key, then the value "192" will be twinkling and now you can press the "UP" key or "DOWN" key to change its value. Press the "OK" key to finish setting .Then press the "UP" key or "DOWN" key to change the other three values.
- Page 9 User Manual AW5145W (2)Press "MENU" key to enter the setting menu, select "Net settings", press "OK" key to enter the submenu and select "Server Port" to set. The default Server port is 9002, do not need to modify. 5.4 Alarm Settings The transmitter supports temperature and humidity alarm function, you can set the temperature and humidity alarm value for alarm.
- Page 10 User Manual AW5145W select "Humidity LAR", then press "OK" key to enter "Humidity LAR" interface. (2)Press the "UP" key or "DOWN" key to set the low humidity alarm value and alarm switch. When the monitoring environment value reaches the pre-set temperature and humidity alarm value, the device will automatically alarm.
-
Page 11: System Setting
User Manual AW5145W (3)Record cycle setting Enter the "Record Cycle" submenu and press the "UP" key or "DOWN" key to change the cycle switch. When "Record Cycle" is closed, the device will stop recording when the record point reach 12800 point. When the "Record Cycle" is open, the first record is overwritten when the record is full. - Page 12 User Manual AW5145W 6.4 System Information (1)Long press the "OK" key to unlock the screen. (2)Press "MENU" key to enter setting menu, enter the "System Setting" menu, select "System Information", press "OK" key to enter and view the system information parameters.
- Page 13 User Manual AW5145W 4. The transmitter supports both transit and broadcast modes. Using the transit mode, data is uploaded directly to the server through the internet, then upper monitor software get the data from sever to display. Using the broadcast mode, upper monitor software communicate with the equipment directly in the LAN, not through the internet.
- Page 14 User Manual AW5145W upper monitor start to communicate with transmitter. After communication success, the device name color of upper monitor changed from grey to green, and the top of screen of transmitter display upper monitor connected symbol. 6. Broadcast mode related setting 1) Click on the menu bar, select "system"...
-
Page 15: License Agreement
User Manual AW5145W technical personnel of Aosong company for help. ※Temperature and Humidity Correction The system sometimes has a certain measurement deviation value. The temperature deviation value is ±0.5℃, and the humidity deviation value is ±3%RH, both regard as the normal phenomenon. -
Page 16: Quality Assurance
User Manual AW5145W 10 Quality Assurance The company provides quality assurance for 12 months for the original purchaser of the products (calculated from the date of shipment), in accordance with the technical specifications of the data book of the product published by the company. If the product is proved to have its own quality problems during the warranty period, the company will provide free maintenance or replacement.
