Millipore Immobilon NOW Quick Start Manual

Quick Start Guide
Immobilon
Catalogue Number IMDISP
For information on using Immobilon
The Immobilon NOW Dispenser facilitates rapid, precise measurement and cutting of transfer
®
membranes to standard mini and midi sizes. It is designed for use with the following Immobilon

transfer membrane products:

Cat. No.
IEVH85R
IPFL85R
IPVH85R
ISEQ85R
NOTE: Assembly drawing does
not depict all graphics
appearing on the dispenser.
1. Lift cover of dispenser. Hold the core and unscrew the black knob.
2. Remove core from dispenser.
3. Remove outer packaging from the roll of membrane, orient roll as shown, and insert the core into
the roll.
CAUTION: The membrane is sandwiched between blue patapar sheets. To avoid damaging it,
leave the patapar in place while dispensing and cutting.
4. Slide the core and membrane roll into place in the side grooves and screw the knob in to secure
the roll in the dispenser.
The life science business of Merck KGaA, Darmstadt, Germany
operates as MilliporeSigma in the U.S. and Canada.
NOW Transfer Membrane Dispenser
®
transfer membrane, go to www.SigmaAldrich.com/Immobilon.
®
Transfer Membrane
Immobilon -E
®
Immobilon -FL
®
Immobilon -P
®
Immobilon -P
®
Membrane
roll
SQ
Core Color
Yellow
Green
Blue
Red
Membrane ID card
Cover
Core
Threaded hole
Slot
Knob
®
