Operation
Formula-X
Low emission external-mix dispense gun for use with polyester resin and gel coat.
For professional use only.
Maximum fluid working pressure:
2000 psi. (14 MPa, 138 bar)
Maximum air pressure:
100 psi. (0.7 MPa, 7 bar)
Important Safety Instructions
Read all warnings and instructions in
this manual. Save these instructions.
GC-1393G
ENG
Advertisement
Table of Contents
Related Manuals for Graco Glascraft Formula-X
Summary of Contents for Graco Glascraft Formula-X
- Page 1 Operation Formula-X Low emission external-mix dispense gun for use with polyester resin and gel coat. For professional use only. Maximum fluid working pressure: 2000 psi. (14 MPa, 138 bar) Maximum air pressure: 100 psi. (0.7 MPa, 7 bar) Important Safety Instructions Read all warnings and instructions in this manual.
-
Page 2: Table Of Contents
Contents Warnings ... 3 Important Safety Information ... 5 Grounding ... 6 Set-Up ... 7 Parts ... 8 Assembly Drawings ... 9 Pressure Relief Procedure ... 12 Maintenance ... 13 Maintenance ... 14 Technical Data ... 17 Graco Ohio Standard Warranty ... 18 Graco Ohio Information ... -
Page 3: Warnings
Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure- specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable. - Page 4 Warnings sions of this section. 1) manual guns, 2) UL-1450 compliant equipment 3) automatic guns,/dispense val tion valves, 4) heated hoses. Since the text contains mostly “Do not” statements, the symbols have lines them. SKIN INJECTION HAZARD SKIN INJECTION HAZARD High-pressure fluid from gun, hose leaks, or ruptured components will pierce skin.
-
Page 5: Important Safety Information
Important Safety Information Methyl Ethyl Ketone Peroxide (MEKP) MEKP is among the more hazardous materials found in commercial channels. Proper handling of the “unstable (reactive)” chemicals presents a definite challenge to the plastics industry. The highly reactive property which makes MEKP valuable to the plastics industry in producing the curing reaction of polyester resins and gel-coats also produces the hazards which require great care... -
Page 6: Grounding
Grounding Some materials may become self-igniting if applied too thickly. Read material manufacturer’s warnings and material MSDS. Moisture Sensitivity of Isocyanites This equipment needs to be grounded. Isocyanites (ISO) are catalysts used in two component Ground the dispense gun through connection to a GlasCraft approved grounded fluid supply hose. -
Page 7: Set-Up
Set-Up Hose Attachment Push in and rotate the trigger lock to stop the trigger from being activated. Attach the (black p/n 21694-25) material hose to the material inlet fitting on the back of the gun. Attach the (red) atomize air tubing to the atomize air inlet fitting on the back of the gun. -
Page 8: Parts
Parts Formula X Dispense Gun 23750-01 Standard Equipment Part Number 23750-01 FORMULA X DISPENSE GUN USER MANUAL GC-1393 Repair Kits Part Number 23792-00 23793-00 23732-00 GUN FLUID VALVE KIT Description Description GUN AIR KIT GUN SEAL KIT GC-1393F... -
Page 9: Assembly Drawings
Assembly Drawings 23750-01 Formula X Dispense Gun GC-1393F... - Page 10 Assembly Drawings 23750-01 Formula X Dispense Gun GC-1393F...
- Page 11 Assembly Drawings 23750-01 Formula X Dispense Gun Part Description Number 13867-05 O-RING O-RING 13867-07 18383-02 BALL 20514-00 FITTING 20588-00 SEAL 20735-05 ELBOW FITTING 20796-00 FITTING 21044-05 O-RING 21614-20F SET SCREW 23515-00 CATALYST RESTRICTOR 23520-00 CATALYST FITTING 23556-01 PTFE WASHER 23589-00 SHIFTER PISTON 23592-00 FRONT HEAD...
-
Page 12: Pressure Relief Procedure
Pressure Relief Procedure To relieve fluid and air pressures: 1. Push down Yellow slide valve, P/N 21402-00 to bleed off air to system. 2. Open P/N 21228-00 on catalyst pump to recirculation position. 3. Open P/N 21192-00 on bottom of material pump. 4. -
Page 13: Maintenance
Maintenance Parts Replacement Procedure Formula Gun Before performing maintenance on the dispense gun, follow Pressure Relief Procedure. Notice Due to the different o-ring materials and lubricants used in the dispense guns, never submerge or soak any dis- pense gun in any type of solvent. Submerging or soak- ing any dispense gun will immediately void the gun war- ranty. -
Page 14: Maintenance
Maintenance Ensure bores are clean before building material valves. Insert bearing, p/n: 23768-01 into gun body. Insert seal, p/n: 23763-00 into gun body. (Ensure holes in seal are aligned with holes in gun body.) Place PTFE washers, p/n: 23721-04 on top and bottom of fluid valve, p/n: 23743-00. - Page 15 Options GC-1393F Dispense Tip Reference Chart Part Orifice Number 23047-J1 .012 .014 .022 .012 .014 .022 .012 .014 .022 .012 .014 .022 Note: Use p/n: LPA2-120G and p/n: LPA2-121G when using LPA2-147-XXXX and 23047-XX series spray tips.
- Page 16 Options Part Number LPA2-147-1525 LPA2-147-XXXX. (Requires Seal, P/N 20333-00 and Retainer, P/N 22274-00.) Dispense Tip Reference Chart Orifice 0.015 1540 0.015 1550 0.015 1565 0.015 1825 0.018 1840 0.018 1850 0.018 1865 0.018 2125 0.021 2140 0.021 Note: 2150 0.021 Use p/n: LPA2-120G and p/n: LPA2-121G 2165 0.021...
-
Page 17: Technical Data
Technical Data Category Maximum Fluid Working Pressure Maximum Air Inlet Pressure Typical Flow Rate of Pattern Guns Maximum Fluid temperature Trigger Air AAC Air Atomize Air A Component (Catalyst) Inlet Size B Component (Resin) Inlet Size Sound Pressure Sound Power, measured per ISO 94 16-2 Dimensions Weight Wetted Parts... -
Page 18: Graco Ohio Standard Warranty
Graco Ohio Standard Warranty Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
