Please file and use this service manual together with the service manual for Model No. [SB-PS800AE-M,
Order No. MD0410493C2].
Specification
SB-PC800
Type
Speaker (s)
Woofer
Tweeter
Impedance
Input power (IEC)
Sound pressure level
Crossover frequency
Frequency range
CONTENTS
2 way, 3 speaker system (Bass-
reflex type)
8 cm cone type x 2
2.5 cm semi-dome type x 1
200 W (MAX), 100 W (RATED)
81 dB/W (1.0 m)
2.5 kHz
55 Hz - 50 kHz (-16 dB)
Page
SB-AFC800E
Colour
(M)... Wood Grain Type
Dimensions (W x H x D)
(with stand)
(without stand)
Mass
6Ω
Notes :
1. Specifications are subject to change without notice.
2. Mass and dimensions are approximate.
SB-AFC800E-M consists of : SB-PS800AE-M (x2) and SB-PC800E-
M (x1)
3
3
3
4
5
6
© 2004 Matsushita Electric Industrial Co., Ltd. All
rights
distribution is a violation of law.
ORDER NO. MD0410494C2
Speaker System
60 Hz - 45 kHz (-10 dB)
380 x MAX 174.5 x MAX 230.5 mm
380 x 146 x 205 mm
reserved.
Unauthorized
4.8 kg
Page
6
7
7
8
9
9
copying
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SB-AFC800E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic SB-AFC800E

Summary of Contents for Panasonic SB-AFC800E

  • Page 1: Table Of Contents

    1. Specifications are subject to change without notice. Sound pressure level 81 dB/W (1.0 m) 2. Mass and dimensions are approximate. Crossover frequency 2.5 kHz SB-AFC800E-M consists of : SB-PS800AE-M (x2) and SB-PC800E- Frequency range 55 Hz - 50 kHz (-16 dB) M (x1) CONTENTS Page...
  • Page 2 SB-AFC800E...

  • Page 3: Disassembly Process (Sb-Pc800)

    SB-AFC800E 1 Disassembly Process (SB-PC800) 1.1. Disassembly of Woofer Speakers · Disassembly of Woofer Speaker (1) Step 1: Remove the net frame assembly out from the cabinet 1.2. Disassembly of Tweeter as shown by the arrow. Speaker Follow step (1) of item 1.1 Step 1: Remove 4 screws using an allen key.

  • Page 4: Disassembly Of Network

    SB-AFC800E 1.3. Disassembly of Network Step 1: Remove 4 screws as shown. Step 2: Remove 3 screws as shown. Step 3: Release the indicated nuts. Step 4: Remove the network assembly.

  • Page 5: Connection Of The Speaker Cables

    SB-AFC800E 2 Connection of the Speaker Cables · Be sure to connect speaker cables before connecting the AC power supply cord. · The load impedance of any speaker used with this unit must be 6Ω. · Be sure to connect the cable from the right speaker to the right terminal and the cable from the left speaker to the left terminal.

  • Page 6: Connection Of The Wiring Diagram

    SB-AFC800E 3 Connection of the Wiring Diagram 3.1. SB-PC800...

  • Page 7: Cabinet Parts Location

    SB-AFC800E 4 Cabinet Parts Location 4.1. SB-PC800E...

  • Page 8: Replacement Parts List

    SB-AFC800E 5 Replacement Parts List Ref. Part No. Part Name & Description Remarks Notes : SLCSA471KE CHOKE COIL SLCSA821KE CHOKE COIL · Important safety notice : When replacing any of these components, be sure to use PACKING MATERIALS only manufacturer’s specified parts shown in the parts list.

  • Page 9: Packaging

    SB-AFC800E 6 Packaging 6.1. SB-AFC800E FLE0410M/S...
