Car Seat/Booster Seat Owner’s Manual Model 8488 READ THIS MANUAL. Do not install or use this car seat until you read and understand the instructions in this manual. FAILURE TO PROPERLY USE THIS CAR SEAT INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN A SUDDEN STOP OR CRASH.
Your child’s safety depends on you installing and using this car seat correctly. Even if using this car seat seems easy to figure out on your own, it is very important to READ THE OWNER’S MANUAL and the vehicle owner’s manual.
Purchase Date: 2.1 Register Your Car Seat Please fill in the above information. The model number can be found on a label underneath your car seat. Fill out the prepaid registration postcard attached to the seat cover and mail it today.
Page 6
**Vehicles are now (or can be) equipped with tether anchor points behind some seats. A tether anchors the top of the car seat to the body of the vehicle. When used properly with the vehicle seat belt, a tether helps reduce injury in a sudden stop or crash.
CRASH. Your child can be injured in a vehicle even if you are not in a crash. Sudden braking and sharp turns can injure your child if the car seat is not properly installed or if your child is not properly secured in the car seat.
Page 8
• STOP USING CAR SEAT AND THROW IT AWAY after the date molded into the back of the car seat. • DO NOT MODIFY YOUR CAR SEAT or use any accessories or parts supplied by other manufacturers. • NEVER USE CAR SEAT IF IT HAS DAMAGED OR MISSING PARTS.
APPROPRIATE FOR YOUR CHILD’S SIZE MAY INCREASE THE RISK OF SERIOUS INJURY OR DEATH. Instructions for the use of this car seat and your vehicle’s seat belt differ greatly depending on the size of your child. Be sure you are using the car seat in the correct mode and with the correct features for your child.
4.2.1 WITH Built in Harness Your child MUST meet all requirements: • WEIGHT: 20 to 40 lbs. (9 to 18 kg) • HEIGHT: 27 to 43 inches (69 to 109 cm) • At least one year old and can sit upright unassisted •...
If you are not sure where to place the car seat in your vehicle, consult your vehicle owner’s manual or Graco Children's Products Inc., 1-888-224-6549. • Children are safer when properly restrained in rear vehicle seating positions.
Pay careful attention to these systems; some of the seat belts that are not safe to use look very much like seat belts that are safe to use. If you are unsure, consult your vehicle owner’s manual or Graco Children's Products Inc., 1-888-224-6549. 5.2.1 UNSAFE Systems DO NOT USE ANY OF THE FOLLOWING SYSTEMS TO SECURE THE CAR SEAT.
Page 13
• Passive Restraint - Lap or Shoulder Belt Mounted on Door • Passive Restraint - Lap Belt with Motorized Shoulder Belt DO NOT use vehicle belts that are attached to the door in any way or that move along a track to automatically surround the passenger when the door is closed.
5.2.2 SAFE Vehicle Belt Systems THE FOLLOWING BELT SYSTEMS CAN BE USED WITH YOUR CAR SEAT, IF the seat location meets all other requirements of these instructions and those in your vehicle owner's manual. For Built-in Harness Only • Lap Belts - Manually Adjusted When buckled, the belt is tightened manually by pulling on the excess belt.
Page 15
You must use the locking clip provided with the car seat, unless your vehicle's seat belt can be converted in another way as described in your vehicle owner's manual.
Page 16
To Install Locking Clip: 1. Tighten the buckled belt by pushing down hard on the car seat and pulling hard on the shoulder belt. 2. While pushing down on seat, pinch the two straps together behind the the buckle tongue. Unbuckle ½...
6.0 Using Car Seat WITH Built-in Harness 6.1 Positioning the Harness Straps FAILURE TO PROPERLY ADJUST THE HARNESS STRAPS FOR YOUR CHILD INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN THE EVENT OF A SHARP TURN, SUDDEN STOP OR CRASH.
Page 18
4. Check the crotch strap. Choose the position that is closest to but not under your child. To move the strap: Reach under seat and push the metal retainer up through the slot sideways . Place the retainer in the appropriate slot.
Page 19
8. Pull strap ends through slots and reinsert them in the correct slots as determined in step 5. 9. Reassemble straps onto metal junction plate exactly as shown Check that straps are completely within the slots. 10. Check that the straps are inserted at the same level and that they are not twisted.
Page 20
(See also Section 6.3, Securing Your Child in the Car Seat, page 23.) REMEMBER to check the shoulder and crotch straps as your child grows and move them to the next position...
OF A SHARP TURN, SUDDEN STOP OR CRASH. Carefully follow these instructions and those in your vehicle owner’s manual to be sure your car seat is properly located, positioned, and held tightly at all times. 1. Place the car seat firmly...
Page 22
. Vehicle belt must stay tight. Car seat must be very tight. If car seat is not secure or loose, repeat procedure OR find another location for the seat, see Section 5.0 Car Seat Location, pp. 11-16.
IN THE CAR SEAT INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN THE EVENT OF A SHARP TURN, SUDDEN STOP OR CRASH. In a crash, the car seat provides NO protection for your child unless the harness straps are properly secured. Follow these instructions carefully to properly secure your child.
Page 24
3. Pull the adjustment strap to securely tighten the harness 4. Fasten harness clip Position harness clip at middle of child’s chest, level with armpits. 5. Make sure straps are flat and tight against child’s shoulders. You should not be able to insert more than one finger between harness and child’s shoulder...
7.0 Using Car Seat WITH- OUT Built-in Harness FAILURE TO PROPERLY SECURE YOUR CHILD AND THE BOOSTER SEAT IN YOUR VEHICLE INCREASES THE RISK OF SERIOUS INJURY OR DEATH IN THE EVENT OF A SHARP TURN, SUDDEN STOP OR CRASH.
7.1 Harness Removal 1. Remove harness straps from metal junction plate. See figure 3 on page 18 for more help. Pull the straps through harness slots. Do not remove buckles or harness clip from straps Push straps, buckles and harness clip through bottom of seat.
2. If you want to use tether to hold seat in place, secure it now. See Section 8.1 Using the Tether, page 28. 3. Place child in car seat with child’s back flat against back of car seat. 4. Position lap/shoulder belt as shown...
Contact your vehicle dealership for the proper anchor location and installation. You may purchase tether anchor parts kit by calling Graco Customer Service at 1-888-224-6549. 1. Check that tether is securely attached to car seat.
1. Airlines have some restrictions about the use of car seats. 2. Install your car seat on an airplane in the same way it is installed in an automobile with a lap belt (see Section 6.2, Securing the Car Seat in Your Vehicle, pp.
If you cannot get the harness to remain tight with the buckle securely locked, do not use this car seat. Call Graco at 1-888-224-6549 to purchase a replacement harness or buckle. • SEAT COVER: clean with a damp sponge using mild soap and cool water.
. It will be a tight fit so be careful not to tear the seat cover. 5. Lift cover off seat, pushing harness straps, crotch strap and hardware through slots in cover. DO NOT USE car seat without the seat cover.
Page 32
6. Machine wash cover in cold water on delicate cycle and drip-dry. DO NOT USE BLEACH. 7. To put the seat cover back on, reverse preceding instructions. Push the adjustment plate and strap through the hole in the seat cover. Be careful not to tear the seat cover.
Page 33
10.Thread the harness straps through the appropriate holes in the seat cover. See the illustration at right and section 6.1, “Positioning the Harness Straps” (page 17) to properly secure the harness straps back on the seat 11. Secure the seat cover to the seat by reattaching the elastic loops and hooks to...
Seat cover Crotch strap w/buckle Tether strap Harness Clip Cupholder Check or money order enclosed (payable to Graco Children’s Products Inc.) Charge to credit card Visa Account # Expiration date Signature SHIP TO: Name Address...
Page 36
Keep this manual in the storage compartment on the back of the car seat. Graco Children’s Products Inc. Elverson, PA 19520 1-888-224-6549...
